Summary of Contents for Air-On AKLKK-900
- Page 1 Operating Instructions ® Air-On Individual room air conditioner AKLKK-900 www.air-on.ch Item no. 002061_00/03.2014...
-
Page 5: Table Of Contents
Setting the nominal temperature value................. 29 Operating the modes........................30 Comparison of the operation modes ..................31 Status displays ..........................32 Care and Cleaning ................35 Clean the device surfaces with a moist cloth............... 35 AKLKK-900 Air-On AG – Table of contents... - Page 6 Error code ............................49 Vent the water circuit in the device..................50 10 Technical Data..................51 10.1 General data ............................. 51 10.2 Type plate ............................54 Index of key words ................55 Imprint ..................... 59 Air-On AG – Table of contents AKLKK-900...
-
Page 7: General Information
Disposal Device and replacement parts must be disposed of correctly according to applicable national legislations. The active carbon filter must be packed in a plastic bag and disposed of with the normal rub- bish. AKLKK-900 Air-On AG – General Information... - Page 8 Air-On AG – General Information AKLKK-900...
-
Page 9: Safety Instructions
Signal word Impacts and measures Meaning and use The safety instructions in this document are classified as follows: Designates a potentially hazardous situation Not avoided this may lead to mortal or severe injuries. Warning AKLKK-900 Air-On AG – Safety Instructions... - Page 10 Designates a potentially harmful situation If not avoided, the device or something in its vicinity will be damaged. Note Additional notes Support The "Hint" designates additional information that assist you in using the device. Hint Air-On AG – Safety Instructions AKLKK-900...
-
Page 11: Information On Safe Use
Warning and/or knowledge unless they are supervised by a person who is responsible for their safety and have received instructions from this supervising person in how the device should be used. AKLKK-900 Air-On AG – Safety Instructions... - Page 12 LED illuminates on the status display. If the LEDs do not illuminate, an error is at hand. Then you have to close the doors/covers and contact your service partner (see page 47). Example: service doors open Air-On AG – Safety Instructions AKLKK-900...
-
Page 13: Installation
If the mains connection line of this device is damaged, it must be replaced by the service partner. 2.4 Commissioning Incorrect commissioning Incorrect commissioning may damage the device. The device must only be commissioned by a trained fitter. Note AKLKK-900 Air-On AG – Safety Instructions... -
Page 14: Operation
2.6 Warranty terms and liability exclusion ® The warranty terms and liability exclusion for the Air-On device are subject to the general terms of business of Air-On AG. You can find this on our homepage at: http://www.air-on.ch/agb Air-On AG – Safety Instructions AKLKK-900... -
Page 15: Your Air-On
12 Water tank (optional) Blade outlet 13 Humidification module (optional) Service display 14 Secondary air blade inlet Outdoor air electric filter 15 Room air coarse filter Outdoor air coarse filter 16 Room air electric filter ® AKLKK-900 Air-On AG – Your Air-On... - Page 16 ® Air-On AG – Your Air-On AKLKK-900...
-
Page 17: Functions
Relative air humidity [%] The area of comfort in which the temperature and humidity is perceived as being pleasant. AKLKK-900 Air-On AG – Functions... -
Page 18: Functional Principle
Supply air (cleans, conditions the air with Heating water supply/return lines outdoor air quantity) Condensation Exhaust air Sensors (temperature, CO , humidity) Outdoor air Thermoelectric heat pump Secondary air 10 Humidification and dehumidification Radiant heat Air-On AG – Functions AKLKK-900... -
Page 19: Separate Functions
® Using convection, the Air-On device brings the room to the desired temper- ature quickly and efficiently. At the same time, the radiating surface on the front side ensures for a pleasant warmth. - Page 20 , temperature and humidity controlled. This is pre-heated or pre-cooled by the exhaust air via a heat exchanger. A possible icing of the heat exchanger by unfavourable temperature condi- ® tions indoors and outdoors is prevented effectively by the Air-On device. Outdoor air Cleaned and odour-neutralised supply air Exhaust air Air-On AG –...
- Page 21 Cleaning the air ® Outdoor air and indoor air are cleaned by the Air-On device effectively in three filter levels (coarse filter, electrostatic filter and active carbon filter). In this manner, the room air and the outdoor air supplied are cleaned from fine particles, in particular also ultrafine particles, allergens, pollen and unpleasant odours.
- Page 22 This supports the cooling function as the perception of temperature is associated with the humidity. In heating mode, the room is dried by air supplied from outside. Thermoelectric heat pump Air flow in dehumidification mode Air-On AG – Functions AKLKK-900...
- Page 23 An additional humidification of the room air may make sense for an optimum ® room climate depending on demand and season. For this purpose, Air-On devices are available with and without humidification module; this can be ret- rofitted as an option at any time.
-
Page 24: Your Air-On ® In The Course Of The Year
Only active in summer and partially in the tran- and partially in the tran- sitional period. sitional period. Ventilation In some cases Active throughout the Possible in the transi- year. tional period but only necessary in some cases. Air-On AG – Functions AKLKK-900... -
Page 25: Operation
(CO content, temperature, humidity, ® fan level) are evaluated and the individual functions are controlled by the intelligent Air-On regulation that a pleasant room climate desired by the user is always created. AKLKK-900... -
Page 26: Overview Of The Operating Elements
5.2 Overview of the operating elements DOOR WATER SERVICE FAULT Standby indicator Operation modes control panel Status displays Control panel temperature specification Mini view of the device with status localisation Air-On AG – Operation AKLKK-900... -
Page 27: Operating Element, Standby
In order to switch on the device, move the rocker switch to 1, and to 0 for switching off. Avoid the formation of mould in the room In order to prevent the accumulation of mould during longer periods of ® absence, we recommend that the Air-On is never switched off. Hint Device drying during longer standstill periods Residual moisture can lead to the formation of mould. -
Page 28: Device Drying Mode
Now it can be switched off manually using the main switch (see page 27). The device is dried out hygienically perfectly and can be switched off for longer periods with- out problem. Air-On AG – Operation AKLKK-900... -
Page 29: Setting The Nominal Temperature Value
When changing the temperature, different device-internal factors are adapted. This takes a little time. For this reason, the temperature should only Hint be adjusted in small steps: switch maximum one to two levels higher or lower each time. AKLKK-900 Air-On AG – Operation... -
Page 30: Operating The Modes
In doing so, the device regulates the room climate depending on the season, humidity and temperature. When tapping on the arrow buttons, you can change the operating mode step by step from the left to the right or vice-versa. Air-On AG – Operation AKLKK-900... -
Page 31: Comparison Of The Operation Modes
5.8 Comparison of the operation modes Operating mode «Absent» ® This operation of the Air-On is optimised for a low energy consumption (power and water) at the cost of a higher noise level. Ideal for uninhabited premises. Operating mode «Quite»... -
Page 32: Status Displays
Three levels of messages are shown in the status display: Messages for the user (open doors, water tank empty, etc.). Service messages for maintaining the device ( see page 37 Error messages for troubleshooting for the service partner (see page Air-On AG – Operation AKLKK-900... - Page 33 Blade for the room air Mount the blade inlet is missing or not correctly. mounted correctly. DOOR Humidification Fill up the water res- module water reser- ervoir in the voir is empty. humidification WATER module. AKLKK-900 Air-On AG – Operation...
- Page 34 Air-On AG – Operation AKLKK-900...
-
Page 35: Care And Cleaning
Wipe over the surface of the device with a moist cloth. Incorrect cleaning agent may damage the surfaces of the device Never clean the device with aggressive and scouring cleaning agents. Note Clean the device only with a moist cloth. AKLKK-900 Air-On AG – Care and Cleaning... - Page 36 Air-On AG – Care and Cleaning AKLKK-900...
-
Page 37: Maintenance
SERVICE The service notification goes out automatically after replacement. Maintenance necessary: Read off the error code from the service display ERROR (see page 38). Contact your service partner (see page 47). AKLKK-900 Air-On AG – Maintenance... -
Page 38: Read Code
Service and error messages that the user cannot rectify themselves are designated with a code. The code for the service partner is read as follows. Description Remove service doors (1). Remove the water tank (2) (only if your device is equipped with this option). Read code. Air-On AG – Maintenance AKLKK-900... -
Page 39: Error Codes
Push the blades (3) to the right and remove. Pull out the room air electric filter module (4) parallel to the front on both tabs (5). Clean the electric filter in a non-trade dishwasher with the filter attachment pointing upwards. AKLKK-900 Air-On AG – Maintenance... - Page 40 Residual moisture may still be at hand, in particular, in the struts of the plastic parts as well as in the coarse filter net. The drying can, if required, be sped up by using an absorbent lint-free cloth without applying mechanical pressure (external dabbing). Air-On AG – Maintenance AKLKK-900...
- Page 41 (1) to the right, hang out and remove. Pull the outgoing air coarse filter (3) to the front. Clean the filter in a non-commercial dishwasher or rinse under a tap with lukewarm water and then dry well. AKLKK-900 Air-On AG – Maintenance...
- Page 42 Clean the electric filter module in the dishwasher Place the electric filter with coarse filter in the dishwasher pointing wards to ensure that no contamination can accumulate in the filter. Hint Air-On AG – Maintenance AKLKK-900...
-
Page 43: Filter, Replace
The active carbon filter and the filter attachments must be replaced at least once a year. The device outputs a respective message. Spare filter set, ordering The spare filter set can be ordered from your service partner. The instructions for changing the filter is enclosed in the FS-AKLKK-900 filter Note set. AKLKK-900... - Page 44 Air-On AG – Maintenance AKLKK-900...
-
Page 45: Options
47) and also be installed by them. A more detailed installation and operating instruction is enclosed in the packaging. Ordering the humidification module The humidification module can be ordered from your service partner. The installation instruction is enclosed with the module. Note AKLKK-900 Air-On AG – Options... -
Page 46: Knx-Tp Interface Card
KNX can be used to control the heating, lighting, roller blinds, ventilation and security technol- ogies across buildings and demand-oriented. A separate installation manual is available on out homepage (www.air-on.ch/knx) for the instal- lation of the KNX interface card as well as for commissioning and programming. -
Page 47: Troubleshooting
You have to contact the service partner to assist with troubleshooting. You can find the contact data behind the service doors on the cover of the outdoor air electric filter. Contact address in the device Remove service doors (1). The contact address (2) is located on the electric filter cover. AKLKK-900 Air-On AG – Troubleshooting... -
Page 48: Faults According To Symptoms (Without Error Message)
• • Standby indicator illumi- One or more covers are open Close all doors and covers. nates, no function of the (status display "Door" is device illuminated) Air-On AG – Troubleshooting AKLKK-900... -
Page 49: Error Code
• • Service has not been carried Clean the electric filter out on the room air electric immediately (see page 39). filter. • • 25...99 Device error. Contact your service part- (see page 47). AKLKK-900 Air-On AG – Troubleshooting... -
Page 50: Vent The Water Circuit In The Device
Turn the venting screw (3) open by a half a turn counter-clockwise. Collect the water running out with a container or cloth. Close the venting screw (3) again. Re-insert the water tank and mount the service doors. Air-On AG – Troubleshooting AKLKK-900... -
Page 51: Technical Data
Tapping drill hole Ø 160 mm, air passage Ø approx. 125 mm, air duct and associated insulation to be provided by the customer. On request, ventilation flaps provided by the customer can be controlled by the optionally available Air-On KNX interface. AKLKK-900 Air-On AG – Technical Data... - Page 52 Insulation Insulation module A special module is available for simplifying the outdoor and ® exhaust air ducts of the Air-On device. The air ducts for optimum flow conduction - with the lowest possible flow Insulation module (individu- resistance - are integrated into this module. The module can...
- Page 53 Deposition rate for particles 0.3 ... 10 µm > 80 % (filter class F7) ondary air Active carbon filter for Reduced odours supply air Humidity Room air Max. 300 ml/h dehumidification Room air humidification Max. 200 ml/h Water reservoir Removable tank, approx. 2 litres AKLKK-900 Air-On AG – Technical Data...
-
Page 54: Type Plate
0 - 60 m³/h Outdoor air/exhaust air Weight S/N A2013001420 001523-05 Type plate sample Type plate in the device Remove service doors (1). The type plate (2) is located at the bottom on the rear wall. Air-On AG – Technical Data AKLKK-900... -
Page 55: Index Of Key Words
Dehumidification Heating Humidification Ventilation Meaning of the error codes Operating mode Comfort Party Quite Window opening Operating mode «Absent» Outdoor air coarse filter Outdoor air electric filter module Outgoing air coarse filter AKLKK-900 Air-On AG – Index of key words... - Page 56 Packaging Read code Requirements Room air coarse filter Room air electric filter Venting screw Water tank Air-On AG – Index of key words AKLKK-900...
-
Page 59: Imprint
Imprint Article number: 002061 Index: Issue: 24. July 2014 Prepared: Florian Christen, ZetaVision Classification: Approved Feedback: info@air-on.ch Original language: German AKLKK-900 Air-On AG – Imprint... - Page 60 Head Office Switzerland Gewerbestrasse 11 6330 Cham Switzerland Tel.: +41 (0)41 743 14 14 Fax: +41 (0)41 743 14 16 info@air-on.ch www.air-on.ch...
