GSM TELEPHONE
GSM TELEPHONE
GT-C3330
2. Specification
3. Product Function
6. Level 1 Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice. Samsung reserves the right to alter this doc
-ument or the product described herein at anytime,
without obligation to provide notification of such
changes.
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT-C3330 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung GT-C3330

Summary of Contents for Samsung GT-C3330

  • Page 1: Table Of Contents

    -es of the product are subject to change without notice. Samsung reserves the right to alter this doc -ument or the product described herein at anytime, without obligation to provide notification of such...
  • Page 2 This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. ⓒ Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2011. 09. Rev.1.0...

  • Page 3: Gsm General Specification

    -100dBm TDMA Mux Cell Radius 35Km 35Km Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 4: Gsm Tx Power Class

    2±5 dBm 5±3 dBm 0±5 dBm 0±5 dBm Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 5: Operation Instruction And Installation

    － BB: Infineon CatFish X-Gold215 － RF: Skyworks SKY77548 － 1-Speaker Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 6 1) Execute the downloader - Execute the ‘FlashTool_E2_XMM2150.zip\FlashTool_E2.exe’ program. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 7 These can be added via “Drag & Drop" Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 8 [ Resource File ] - C3330OXXKXX_CSC.dffs (Type : Cust) Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 9 You can change quantity as "#Channels" (Max 8) f. Click "NEXT" button Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 10 - The download process is automatically executed. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 11 - You can check the version as pushing [*#1234#] after booting. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 12 ―RS: Reed-Solomon ―SI: ServiceInformation ―TDM: TimeDivisionMultiplexing ―TS: TransportStream Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 13: Safety Precautions

    Always use the replacement parts that are registered in the SEC system. Third-party replac ement parts may not function properly. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 14 Increase the airflow to the working area to decrease the chance of accidental static electricity discharges. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 15: Exploded View And Parts List

    QCK02 QCK01 QST01 QRF06 QRE01 QCR67 QBC00 Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 16: Cellular Phone Parts List

    PMO COVER-USB_V2 GH72-65582A QST01 PMO ACCE-STYLUS PEN_V2 GH72-65583A Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 17: Main Electrical Parts List

    R-CHIP 2007-000148 R201,R205,R303,R304 R-CHIP 2007-000148 R500,R503,R504,R505 R-CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 18: Main Electrical Parts List

    C-CERAMIC,CHIP 2203-000812 C422,C426,C501,C502 C-CERAMIC,CHIP 2203-000812 C503,C508 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 19 C-CERAMIC,CHIP 2203-007342 C408,C409 C-CERAMIC,CHIP 2203-007449 C209,C238,C302,C304 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 20 BEAD-SMD 3301-002065 L402,L403,L404,L405 BEAD-SMD 3301-002065 L406,L407,L408,L409 BEAD-SMD Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 21 P l e a s e c o n s u l t t h e G S P N w e b s i t e ( S a m s u n g P o r t a l ) f o r t h e m o s t r e c e n t v e r s i o n o f t h e p r o d u c t ' s p a r t l i s t . Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 22: Level 2 Repair

    1) Be care of damage to PBA. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 23 2) Be care of damage to MOTOR FPCB. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 24 1) 1) Be care of damage the LCD,TSP connector. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 25 1) Be care of damage to Intenna Pattern. Confidential and proprietary-the contents in this service guide subject to change without prior notice. Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 26: Level 3 Repair

    8. Level 3 Repair 8-1.Block Diagram SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 Level 3 Repair 8-2. PCB Diagrams 8-2-1. Top SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 28 Level 3 Repair 8-2-2. Bottom SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 8-3. Flow Chart of Troubleshooting Equipments  Oscilloscope á Digital Multimeter á Power Supply á + driver, ESD Safe Tweezer  8960 & Spectrum Analyzer á Soldering iron SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 VBAT >= 3.45? Check the voltage Check the Main Chip (UCP201) VDD_1.8V(C232) Lookover the Chip damage = 1.8V? Check the clock at Resolder OSC201 OSC201 = 26MHz SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 Level 3 Repair SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 32 Initial Failure CN200 Resolder UCP201 (RST_BB_J=Pin5) RST_BB_J must be higher than > 1.7V? 1.7V using the oscilloscope GND & SHORT PAD. Check the 16bit data signals. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 33 Check C300, D301 Check the voltage (Short to GND or Damage) VBUS_5V_IN(C300) Change C300, D301 >= 5V? Check the U300 Change the U300 (SMD or Damage) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 34 Level 3 Repair SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 Check C605 = 1.8V C605, C611 C611 = 2.85V Resolder Screen error F600,F601,F602 - Break out line Resolder LCD Replace 8-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 36 Level 3 Repair R309 R410 R411 R308 R414 C408 C410 8-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 37 TSP dose not work Check the TSP on correctly connect Main PBA? Check R517,R513,C511 R517,R513,C511 = Resolder 1.8V TSP dose Change the U502 not work? TSP Replace 8-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 38 Level 3 Repair 8-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 39 Operate speaker Check Resolder ANT102,ANT103 ANT102,ANT103 Soldering Speaker break Change Speaker down? Resolder Signal on in L400, L401, L400, L401 SPK ASSY Change main PBA 8-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 40 Level 3 Repair 8-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 41 Check Resolder Receiver FPCB RCV FPCB Soldering Receiver FPCB Change Receiver break down? Resolder Signal on in R412,R413, R412,R413? RCV ASSY Change main PBA 8-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 MIC hole Check C424. Check Check MIC 4th pin C418 = Anal (V_MIC_2.2V) og Signal = 2.2 ? Change main PBA Change MIC Change MIC 8-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 43 SIM card SIM Connector Change SIM500 Break down? C508 Check U202 = 2.85V Check SIM_RST (C501) Change main chip SIM_CLK(C502) Check SIM500 & Neighboring Circuits 8-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 44 Level 3 Repair 8-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 45 Check U600 (VCAM_A_2.8A,VCAM_IO_1.8A) C601 = 2.8V, C602 = 1.8V U601 (VCAM_D_1.8A) C604 = 1.8V Check UCP201 Change the main PBA CAMERA Replace 8-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 46 Level 3 Repair 8-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 47 RF Input : 190 CH Amplitude : -50dBm Normal condition Check Antenna contact Catch the channel? Check L100,L104>=-55dBm? Replace PAM100 Resolder UCP201 or Change The End 8-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 48 RF Input : 62 CH Amplitude : -50dBm Normal Condition Check Antenna Contact Catch the channel? Check L100,L104>=-55 dBm? Replace PAM100 Resolder UCP201 or Change The End 8-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 49 Amplitude : -50dBm Normal Condition Check Antenna Contact Catch the channel? Check L106, L112 Replace PAM100 >= -55 dBm? Resolder UCP201 or Change The End 8-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 50 Level 3 Repair 8-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 REF LEV. : 10dBm ATT. : 20dB Check The UCP201 Check C129 >= 13dBm? Check PAM100 PIN17 OUTPUT(RF CONN.) Replace PAM100 With HP8960 >= 33dBm? The End 8-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 52 REF LEV. : 10dBm ATT. : 20dB Check L115 >= 11dBm? Check The UCP201 Replace PAM100 Check PAM100 PIN17 OUTPUT(RF CONN.) With HP8960 >= 30dBm? The End 8-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 53 Level 3 Repair 8-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 54 Check the connection each terminal C118,F101 2. Replace C118, F101 @ C111=1.8V? Replace U101 @ C113=1.8V? Can it Bluetooth Back to activating & previous step searching? 8-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 55 Level 3 Repair 8-30 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 56 Replace Q100 @C116=2.9V? Check the Put more lead solder connection C230, each terminal L201 Can you turn on and search Replace UCP201 channel? 8-31 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 57 Level 3 Repair 8-32 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 58 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 8-33 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 59 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 8-34 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
