- Page 1 UniBox-3210 Industrial Fanless Computer with Intel® E38xx Atom User’s Manual Ver. 0.1...
-
Page 2: Table Of Contents
UniBox-3210 User’s Manual Contents Safety Information ..................3 About this guide ..................... 5 Conventions used in this guide ..............6 Charter 1. System Introduction ..............7 1.1 Overview ........................7 1.2 Specification ......................... 7 1.3 Features ........................8 1.4 Packing List ........................8 Charter 2. -
Page 3: Safety Information
UniBox-3210 User’s Manual Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. - Page 4 UniBox-3210 User’s Manual Safety Declaration This device complies with the requirements in Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: About This Guide
UniBox-3210 User’s Manual About this guide This user guide contains the information you need when installing and configuring the motherboard. How this guide is organized This manual contains the following parts: Chapter 1: Product introduction This chapter describes the features of the motherboard and the new technology it supports. -
Page 6: Conventions Used In This Guide
UniBox-3210 User’s Manual Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. -
Page 7: Charter 1. System Introduction
Charter 1. System Introduction 1.1 Overview The UniBox-3210 is a fanless system that base on Intel® Baytrail-I platform with one DDR3L SO-DIMM, VGA & HDMI display output, one 2.5" Non-Removable Drive Bay, two Mini-PCIe slot, four RS232 ports, four RS232/422/485 ports, two GbE RJ45 ports, two USB2.0 ports, two USB3.0 ports, and 9~36Vdc Power input features. -
Page 8: Features
1.4 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped with system: 1 x UNIBOX-3210 system 1 x CD/DVD disk contains user manual & drivers 1 x Power Adapter ... -
Page 9: Charter 2. Mother Board Information
UniBox-3210 User’s Manual Charter 2. Mother Board Information 2.1 Specifications Specifications System Intel® Atom E3845 Quad Core 1.9GHz Processor or Intel® Atom E3826 Dual Core 1.46GHz Processor BIOS UEFI One 204-pin SODIMM supports single channel DDR3L 1333 SDRAM, Non-ECC, up to Memory 256 segments, 0,1,2…255sec/min... -
Page 10: Central Processing Unit (Cpu)
UniBox-3210 User’s Manual Power Requirement 9~36Vdc Input Power Connector 1 x 4-pin ATX Power Connector Operating Temperature 0°C to 60°C (32°F to 140°F) Operating Humidity 0% to 90% relative humidity, non-condensing * Specifications are subject to change without notice. 2.2 Central Processing Unit (CPU) The motherboard comes with a surface mount Intel®... - Page 11 UniBox-3210 User’s Manual 2.3.2 Installing a SO-DIMM 1. Align a SO-DIMM on the slot such that the notch on the SO-DIMM matches the break on the slot. 2. Firmly insert the SO-DIMM into the slot until the retaining clips at both ends fully snap back in place and the SO-DIMM is properly seated.
- Page 12 UniBox-3210 User’s Manual 2.3.3 Removing a SO-DIMM 1. Simultaneously press the retaining clips downward to unlock the DIMM. 2. Remove the DIMM from the socket. Unlocked retaining clip Support the SO-DIMM lightly with your fingers when pressing the retaining clips. The SO-DIMM might get damaged when it flips out with extra force.
-
Page 13: Mini Pci Express Card
UniBox-3210 User’s Manual 2.4 Mini PCI Express Card There are 1 mini-PCIe slot and 1 mini-PCIe/mini-SATA slot on this motherboard. mini-PCIe slot: MINI_PCIE1 (mini-PCIe slot; half size) is used for PCI Express mini cards. mini-PCIe/mini-SATA slot: MINI_PCIE2 (mini-PCIe/mini-SATA slot; full size) is used for PCI Express mini cards or mSATA cards. -
Page 14: Motherboard Overview
UniBox-3210 User’s Manual 2.5 Motherboard Overview 2.5.1 Motherboard Layout http://www.unitedlink.com.tw... - Page 15 UniBox-3210 User’s Manual 2.5.2 Internal Connector List Please Refer Chapter 2.7 Label Function Note ATX12V1 ATX Power Connector Refer CH2.7.1 USB0_1, USB2.0 Headers USB2_3, Refer CH2.7.2 USB4_5 BLT_PWR1 Inverter Power Control Wafer Refer CH2.7.3 SATAII_1, SATA2 Connectors Refer CH2.7.4 SATAII_2 BLT_VOL1 Backlight &...
-
Page 16: Rear Io Connectors
UniBox-3210 User’s Manual 2.5.3 Jumper Please refer Chapter 2.8 for detail Label Function Note PNL_PWR1 Panel Power Selection Refer CH2.8.1 BKT_PWR1 Backlight Power Selection Refer CH2.8.2 mSATA_SEL1 mSATA Selection Refer CH2.8.3 BLT_PWM1 Backlight Control Level Refer CH2.8.4 JGPIO_SET1 GPIO Default Setting Refer CH2.8.5... -
Page 17: Connectors
UniBox-3210 User’s Manual 2.7 Connectors 2.7.1 ATX Power Connector (4-pin ATX12V1) Page 14, No. 2 Please connect a DC power supply to this connector. 1-4 : GND 2-3 : DC Input 2.7.2 USB2.0 Headers (9-pin USB0_1, USB2_3, USB4_5) Page 14, No. 4 There are three USB2.0 headers on this... - Page 18 UniBox-3210 User’s Manual 2.7.5 Backlight & Amp Volume Control (7-pin BLT_VOL1) Page 14, No. 8 2.7.6 Chassis Fan Connector (3-pin CHA_FAN1) Page 14, No. 10 Please connect the fan cable to the connector and match the black wire to the ground pin.
- Page 19 UniBox-3210 User’s Manual 2.7.9 Digital Input/Output Pin Header (10-pin JGPIO1) Page 14, No. 15 2.7.10 COM Port Headers (10-pin COM1, COM2, COM3, COM4) Page 14, No. 17(COM4), No. 19(COM3), No. 21(COM2), No. 23(COM1), This motherboard supports RS232/422/485 on COM1 port. Please refer to below table for the pin definition.
- Page 20 UniBox-3210 User’s Manual 2.7.11 TPM Header (17-pin TPM1) Page 14, No. 20 This connector supports Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
- Page 21 UniBox-3210 User’s Manual 2.7.15 Buzzer Header (2-pin BUZZ1) Page 14, No. 27 Pin Assignment as drawing. 2.7.16 LVDS Connector (40-pin LVDS1) Page 14, No. 28 http://www.unitedlink.com.tw...
-
Page 22: Jumpers
UniBox-3210 User’s Manual 2.7.17 CPU Fan Connector (4-pin CPU_FAN1) Page 14, No. 29 Please connect the CPU fan cable to the connector and match the black wire to the ground pin. Pin Assignment as drawing. 2.8 Jumpers The illustration shows how jumpers are setup. - Page 23 UniBox-3210 User’s Manual 2.8.3 mSATA Function (mSATA_SEL1) Page 14, No. 5 2.8.4 Back Light power selection (BLT_PWM1) Page 14, No. 9 2.8.5 GPIO Default Setting (JGPIO_SET1) Page 14, No. 13 2.8.6 Clear CMOS (CLRCMOS1) Page 14, No. 14 This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data.
- Page 24 UniBox-3210 User’s Manual 4. Re-install the battery. 5. Plug the power cord and turn ON the computer. 6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position.
-
Page 25: Charter 3. Bios Setup
UniBox-3210 User’s Manual Charter 3. BIOS SETUP 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del>... -
Page 26: Main Screen
UniBox-3210 User’s Manual 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / -... -
Page 27: Advanced Screen
UniBox-3210 User’s Manual 3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, Intel® Smart Connect Technology, Super IO Configuration, ACPI Configuration and USB Configuration. Setting wrong values in this section may cause the system to malfunction. - Page 28 UniBox-3210 User’s Manual 3.3.1 CPU Configuration Intel® SpeedStep Technology Intel® SpeedStep technology is Intel’s new power saving technology. Processors can switch between multiple frequencies and voltage points to enable power saving. The default value is [Disabled]. Configuration options: [Enabled] and [Disabled]. If you install Windows 7 / 8 and want to enable this function, please set this item to [Enabled].
- Page 29 UniBox-3210 User’s Manual some power supplies. Please set this item to [Disabled] if above issues occur. Adjacent Cache Line Prefetch Use this item to turn on/off prefetching of adjacent cache lines. Intel Virtualization Technology When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can utilize the additional hardware capabilities provided by Vanderpool Technology.
-
Page 30: Chipset Configuration
UniBox-3210 User’s Manual 3.3.2 Chipset Configuration Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. Active LVDS Use this to enable or disable the LVDS. The default value is [Enabled]. - Page 31 UniBox-3210 User’s Manual 3.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. Configuration options: [IDE Mode] and [AHCI Mode]. The default value is [AHCI Mode].
- Page 32 UniBox-3210 User’s Manual 3.3.4 Intel® Smart Connect Technology Intel® Smart Connect Technology Use this item to enable or disable Intel® Smart Connect Technology. Intel® Smart Connect Technology keeps your e-mail and social networks, such as Twitter, Facebook, etc. updated automatically while the computer is in sleep mode. The default is [Disabled].
- Page 33 UniBox-3210 User’s Manual 3.3.5 Super IO Configuration COM1 Configuration Use this to set parameters of COM1. Select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Configuration Use this to set parameters of COM2. COM3 Configuration Use this to set parameters of COM3.
-
Page 34: Acpi Configuration
UniBox-3210 User’s Manual 3.3.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto detect or disable the Suspend-to-RAM feature. Select [Auto] will enable this feature if the OS supports it. ACPI HPET Table Use this item to enable or disable ACPI HPET Table. The default value is [Enabled]. -
Page 35: Usb Configuration
UniBox-3210 User’s Manual 3.3.7 USB Configuration USB Controller Use this item to enable or disable the use of USB controller. USB 3.0 Controller Use this item to enable or disable the use of USB 3.0 controller. Legacy USB Support Use this option to select legacy support for USB devices. There are four Configuration options: [Enabled], [Auto] and [UEFI Setup Only]. -
Page 36: Hardware Health Event Monitoring Screen
UniBox-3210 User’s Manual 3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. -
Page 37: Security Screen
UniBox-3210 User’s Manual 3.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. -
Page 38: Boot Screen
UniBox-3210 User’s Manual 3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. - Page 39 UniBox-3210 User’s Manual CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows 8 64-bit and all of your devices support UEFI, you may also disable CSM for faster boot speed.
-
Page 40: Exit Screen
UniBox-3210 User’s Manual Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save Configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and... -
Page 41: Charter 4. Software Support
Please install the necessary drivers to activate the devices. 4.2.3 Contact Information If you need to contact United Link or want to know more about United Link, you’re welcome to visit United Link’s website at http://www.UnitedLink.com.tw; or you may contact your dealer for further information. http://www.unitedlink.com.tw... -
Page 42: Revision History
UniBox-3210 User’s Manual Revision History Revision Revision History Date V 0.1 First release version May 2016 http://www.unitedlink.com.tw...
