QUICK GUIDE

Go to www.CTSmall.eu if you want the Quick Guide in your language.
1
Buy a SIM card (normal size) and use
your phone to unlock the PIN. Make
sure there is money on the SIM card.
Push the SIM card in the slot on
the side of CTSmall until it clicks.
SYS LED will start to flash.
2
Connect the power adapter
to CTSmall and a wall outlet.
3
The GSM signal must be stable with
minimum 2 flash in signal strength. The
signal is flashed out on the SYS LED every
10 second. This only happens the first
10 minutes after powering up the unit.
The SYS LED are flashing green fast
when sending and receiving a SMS. If
there are any problems when sending
a SMS SYS LED will flash red.
IR
GSM
SYS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTSmall and is the answer not in the manual?

Questions and answers

Related Manuals for Climatech CTSmall

Summary of Contents for Climatech CTSmall

  • Page 1: Quick Guide

    QUICK GUIDE Go to www.CTSmall.eu if you want the Quick Guide in your language. Buy a SIM card (normal size) and use your phone to unlock the PIN. Make sure there is money on the SIM card. Push the SIM card in the slot on the side of CTSmall until it clicks.
  • Page 2 Give CTSmall a name Enter your mobile number for returning alarm message Press “Add” … that’s it. Mount CTSmall on the wall with the IR LEDs pointing directly towards the heat pump / air condition. The two LEDs has a combined 45° viewing angle.

  • Page 3: Get Support

    Relay box (not included) If you have purchased the Climatech relay box, connect it to CTSmall with the cable and connect the power supply in the power outlet of the relay. SMS command: 1234,Out1,0 or 1234,Out2,1 (see SMS command list).
  • Page 4 1234,Status (general status) 1234,StatusPhN (get a list with all entered emergency numbers) 1234,IRTest (help function when mounting your CTSmall) 1234,TLog (return the log – every hour the temperature is saved to a log. There is a backlog of 35 hours)
  • Page 5 Feature overview Petite, suitable everywhere (L70 x B40 x H20) Integrated antenna Warning for temperatures below +5° Warning for temperatures over +45° Warning for low self-selected temperature between 1-30° Warning for high self­selected temperature between 1­45° Power alarm – you will be notified so that you can prevent fridge, freezer etc.
