CECILIA semplice – Romantic:
instructions for use
Description
MIDI expander with 11 true stops containing real sound samples of romantic organ. The registers are divided into two
groups: manual and pedalboard. The choice of registers is carried out by means of illuminated push buttons; all
functions and settings are accessible via display and cursor buttons.
Disposition:
The stops consist of the top quality samples of Sonus Paradisi project, disposition is inspired by French romantic style:
Pedal
• Soubasse 16'
• Contre-basse 16'
• Accouplement (couple)
Technical parameters:
Supply: adapter 12 V/1 A.
•
Extra galvanic isolation.
•
Input USB MIDI IN: 5-pin DIN connector available via MIDI/USB converter.
•
Stereo audio output: 6.3 mm JACK.
•
Manual range: 60 tones (C-c4).
•
Pedal range: 30 tones.
•
Adjustable additional prolongation of reverberation.
•
Polyphony: 250 parallel samples.
•
Latency: <15 ms.
•
Dimensions: 220x103x53 mm.
•
Weight: 0.7 Kg
•
Manual
• Bourdon 16'
• Prestant 8'
• Bourdon8'
• Flûte Harmonique 8'
• Voix Céleste 8'
• Prestant 4'
• Octavin 2'
• Carillon
• Basson-Hautbois 8'
Advertisement
Table of Contents
Summary of Contents for Mlnarik Organ Cecilia Semplice Romantic
- Page 1 CECILIA semplice – Romantic: instructions for use Description MIDI expander with 11 true stops containing real sound samples of romantic organ. The registers are divided into two groups: manual and pedalboard. The choice of registers is carried out by means of illuminated push buttons; all functions and settings are accessible via display and cursor buttons.
- Page 2 Module functions: Four memories for stop combinations. • Loudness level indication in the real time, limitation indicator. • Safe limitation – the exceeding limitation results gradually in the decreasing sound quality, but no sudden • disturbing effects (cracking…) occur. Setting of the total loudness, setting of individual registers' loudness. •...
- Page 3 arrows, the chosen item is set; its value is set by means of vertical arrows. A rapid change of the value can be carried out by holding the vertical arrow. Particular sub-menu (when present) is accessible by “OK” button. For return to the basic level, “esc“...
-
Page 4: Switching Off
Switching off The module is switched off using “OFF“ button. Press an hold the button for several seconds, the inscription “Unplug device“ appears. Then, unplug the module from the power supply. In principle, do not disconnect the equipment from the power supply without previous safe switching off by the button (the equipment shall not be unplugged from the power supply without previous safe switching off by the button).
