Summary of Contents for SECTORMAXX WK-2
- Page 1 QUICK START GUIDE WK-2x Access Point WK-2, WK-2-B, WK-2-C / 802.11ac Dual Band Access Version 1.1...
-
Page 2: Table Of Contents
Contents Package Contents Package Contents Contents depend on your WK-2x model. Please refer to the installation manual of your product. WK-2 Mounting Options WK-2-C Mounting WK-2x Powering Up the Access Point • 802.11ac Dual Band Access Point Configuring the Access Point •... -
Page 3: Wk-2 Mounting Options
WK-2 Mounting Options Vertical mount: Secure the wall bracket to the wall anchors using the included hardware. Using the Provided Wall Mount Bracket. Double-gang electrical box, wall Single-gang electrical box, european outlet box us 4” round junction box, us 3.5” round juction box... - Page 4 Horizontal mount: Line up the slots and secure the wall bracket to the wall anchors using the Attach the recommended plastic cable clip. Route cables along the channel on the back of the included hardware. WAP and secure cables to the plastic clip by pressing the cable to the clip. ROUTE CABLES RECOMMENDED CABLE CLIP PLACEMENT...
- Page 5 Place the WAP firmly against the wall bracket, ensuring the cables are tucked in the channel on the back of the WAP and/or behind the wall bracket.
- Page 6 Slide the WAP downward until the top two tabs on the Wall Bracket are locked into place Secure the WAP to the wall bracket’s bottom tab with the included security screw. SLIDE WAP DOWN TO LOCK TORX SECURITY SCREW SUPPLIED TORX SCREWDRIVER(OPTIONAL) TORX SECURITY SCREW INSTALLATION...
- Page 7 Using provided T-bar Bracket Rotate the WAP counter-clockwise until the T-bar bracket is secured to the T-bar. Place the appropriate sized T-bar bracket into the slots on the back of the WAP and line up the two holes on the T-bar bracket with the two mounting points on the back of the WAP. Using the supplied hardware, mount the T-bar bracket to the WAP.
-
Page 8: Wk-2-C Mounting
WK-2-C Mounting Swing WAP down. Open the release latch and push on the back of WK-2-C to swing the WAP out from ceiling/wall bracket. - Page 9 Use a Phillips screwdriver to tighten the mounting ears. Use a clockwise rotation. ter circle at the desired mounting location for your WK-2-C. Route an in-wall Ethernet cable through the opening on the back of WK-2-C housing. Insert the WK-2-C into the ceiling/wall. NOTE: Do not use excessive force when tightening the mounting-ears.
- Page 10 Plug Ethernet cable into WK-2-C. Route Ethernet cable as shown. Use optional cable clip if Swing WAP back into WK-2-C housing. necessary.
- Page 11 WK-2-C installation with optional pre-construction bracket Pre-construction bracket sold separately. 1. Place the pre-construction bracket against the bottom of the ceiling studs at the desired mounting location. 2. Mark locations for mounting screws. Drill 1/16” pilot holes at marked locations. Secure pre-construction bracket to ceiling studs using the provided hardware.
-
Page 12: Powering Up The Access Point
Powering Up the Access Point Power using a PoE+ Switch The access point can be powered via PoE+ or by the included power adapter. Please see below for examples: Power Using a PoE+ Injector Laptop Laptop WK-2 Laptop Laptop WK-2 Tablet Panel Ethernet Cable... -
Page 13: Configuring The Access Point
Connect a computer to the WK-2x with an Ethernet cable. Enter 192.168.1.250 into the address bar of your web browser. You should see a login page. In the username box, type pakedge. In the password box, type pakedgea and click Login. Laptop Laptop WK-2 Tablet Panel AC Adapter Power... - Page 14 Using Windows 7 Following page will display when logged in: 1. Under Control Panel – Network and Internet, click on View Network Status and Tasks. 2. On the left panel, click on Change Adapter Settings and right-click on Local Area Connection.
- Page 15 Option 2 Once you are logged in to the AP, hover over Network and click on LAN. You can use the Where’s My WAP (WMW) software, which is free to download from the Dealer Portal section of the Pakedge website This application will automatically scan the network for any Pakedge access point.
-
Page 16: Step 2: Radio
2.4 or the 5 GHz band. The available modes for the WK-2x are: support 802.11 ac. Access Point, WDS Root Access Point, WDS Repeater and WDS Bridge. Laptop Laptop WK-2 Tablet Panel Smartphone That once you apply a country code, you cannot change it unless you reset the WK-2x to... -
Page 17: Wds Bridge Mode
A separate WK-2x must be in WDS Root Access Point mode for this the client. A separate WK-2x must be in WDS Root Access Point mode for this setting to operate. setting to operate. WK-2 WK-2 Laptop... -
Page 18: Step 3: Security Profiles
Step 3: Security Profiles The most secure and common mode is WPA2-PSK. The next tab over is the Security Profiles. You can change security settings for 2.4 GHz and 5 GHz. This setting is known to be the most secure and is compatible with all the latest devices. NOTE: When choosing the security settings, consider your client devices. -
Page 19: Step 4: Configuration
Step 4: Configuration In this section, you can change the SSID name and apply the security profile that was set up in step 4. By default, the SSID is Pakedge2.4-1 and Pakedge5-1. You will have the option to change the name and add security profiles by selecting the options from the drop-down menu. -
Page 20: Guest Network
Guest Network This will allow you to set up a guest network. Please see manual for further details. pakedgedevice&software 3847 Breakwater Avenue, Hayward,CA 94545-3606 Main: 650-385-8700 Fax: 650.685.5520 www.pakedge.com sales@Pakedge.com...
