Summary of Contents for MIMO TL-ANT2415MS
- Page 1 Installation Guide 2x2 MIMO Sector Antenna Model: TL-ANT2415MS & TL-ANT5819MS...
-
Page 3: Table Of Contents
CONTENTS Introduction Specifications Safety Notice Package Contents Installation Requirements Hardware Overview Hardware Installation... -
Page 4: Introduction
Introduction The TL-ANT2415MS, 2.4GHz 15dBi 2x2 MIMO Sector Antenna, is for use with the outdoor wireless Base Station WBS210 and achieve a stable long-distance signal transmission. The TL-ANT5819MS, 5GHz 19dBi 2x2 MIMO Sector Antenna, is for use with the outdoor wireless Base Station WBS510 and achieve a stable long-distance signal transmission. -
Page 5: Safety Notice
For your own safety, please seek a qualified service technician for assistance. Package Contents Antenna Mount Bracket Adjustable Pole-mount Bracket Installation Guide 2x2 MIMO Sector Antenna Model: TL-ANT2415MS & TL-ANT5819MS Protective Shroud Installation Guide Pole-mount Clamps RF Cables (Qty.2) (Qty.2) -
Page 6: Installation Requirements
Installation Requirements Outdoor Wireless Base Station (sold separately) Wrenches Hardware Overview Bubble Level Adjustable Pole-mount Bracket Antenna Mount Bracket RF Connectors Protective Shroud Base Station Mount Bracket Base Station/ Shroud Lock Release Lever Assembled Side View Back View... -
Page 7: Hardware Installation
Hardware Installation 1. Attach the RF Cables to the Base Station. 2. Attach the Base Station to the Base Station Mount Bracket as follows: a. Align the mounting tabs on the back of the Base Station with the four mounting slots on the Base Station Mount Bracket. b. - Page 8 3. Connect the other ends of the RF Cables to the RF Connectors on the antenna. 4. Slide the Protective Shroud down over the Base Station until it locks onto the Base Station Mount Bracket.
- Page 9 5. Attach the Antenna Mount Bracket to the four studs located on the antenna using the Flat Washers, Spring Washers, and Hex Nuts. 6. Attach the Adjustable Pole-mount Bracket and Pole-mount Clamps to the pole using four M8x85 Bolts with Nut and Lock Washer Assemblies. Note: Pole diameter ranges from 40mm to 80mm.
- Page 10 7. Mount the Antenna Mount Bracket to the Adjustable Pole-mount Bracket using two M6x35 Bolts with Nut and Lock Washer Assemblies. Note: Do not over-tighten these bolts and nuts to allow angle adjustment later. 8. Adjust the desired elevation angle of the antenna using the scale marked on the Antenna Mount Bracket, and then tighten the bolt and nut assemblies.
- Page 12 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
