Aplex APC-3220 User Manual

12.1”, 19”, 24” intel 4th core i3/i5/i7
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APC-3X20
th
12.1", 19", 24" Intel 4
Core i3/i5/i7 Marine PC
User Manual
Release Date
Revision
Oct. 2015
V1.0
®2015 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplextec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APC-3220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aplex APC-3220

  • Page 1 Core i3/i5/i7 Marine PC User Manual Release Date Revision Oct. 2015 V1.0 ®2015 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 2: Revision History

    Revision History Reversion Date Description 2015/10/23 Official Version APC-3X20 User Manual...

  • Page 3: Warning

    Warning!________________________ This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.

  • Page 4: Caution/Disclaimer

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 5: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) APC-3X20 User Manual...

  • Page 6: Safety Precautions

    Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆ Prevent electric shock. Don‘t touch any components of this card when the card is power-on. Always disconnect power when the system is not in use.

  • Page 7: Table Of Contents

    Table of Contents Revision History…………………………………………………………………………………………………….1 Warning!.............…………………………….……………………2 Caution/Disclaimer……..……………………..…………………………………………………………………3 Packing List…………………………………….…………………………………………………....4 Safety Precautions…………………………………….…………….…..……………………....5 Chapter 1 Getting Started 1.1 Features………………………..………………………...…………………………..8 1.2 Specifications…………………...………………………………………………….8 1.3 Dimensions………………………..…………………………………………….11 1.4 Brief Description of APC-3X20………..….………………………….……14 1.5 Mounting of APC-3X20……………………………………………………….17 Chapter 2 Hardware 2.1 Mainboard Introduction……………………...…………………………..18 2.2 Specifications…………………………..…………………………………………18 2.3 Jumpers and Connectors Location……………………………………...22 2.4 Jumpers Setting and Connectors…………………………………..……23 Chapter 3 BIOS Setup...
  • Page 8 Figures Figure 1.1: Dimensions of APC-3220…..……………………………………11 Figure 1.2: Dimensions of APC-3920…………………………………………12 Figure 1.3: Dimensions of APC-3420…..……………………………………13 Figure 1.4: Front View of APC-3220……………….…………………………14 Figure 1.5: Rear View of APC-3220…..……………..……………………….14 Figure 1.6: Front View of APC-3920………………………………………….15 Figure 1.7: Rear View of APC-3920…..……………..……………………….15 Figure 1.8: Front View of APC-3420…….…………………………………...16...

  • Page 9: Getting Started

    9~36V DC Power Input with isolated  CE/FCC Class A/IEC 60945 Certificated  Marine application 1.2 Specifications APC-3220 APC-3920 APC-3420 System Intel Core i3-4010U Processor (3M Cache, 1.7 GHz) / TDP: 15W Intel Core i5-4310U Processor (3M Cache, 2.0 GHz) / TDP: 15W...
  • Page 10 2 x LED light for power and HDD indication (19”/24” default, optional for 12.1”) 1 x USB Port with Waterproof Cover Design (19”/24” default, optional for 12.1”) Option TB-528C1U2 only for 19”and 24” 2 x USB, 1 x RS-232 Storage Space Storage Default: 1 x 2.5”...
  • Page 11 Mounting Panel Mount and Front Access Mount Mounting Bracket (option) IP Rating IP65 Front Panel Dimensions 337.2 x 293.2 x 65 mm 484 x 400 x 60 mm 647 x 414 x 65 mm Net Weight 4.4 Kg 9.5 Kg 11.7 Kg Operating System Support OS Support...

  • Page 12: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of APC-3220 APC-3X20 User Manual...

  • Page 13: Figure 1.2: Dimensions Of Apc-3920

    Figure 1.2: Dimensions of APC-3920 APC-3X20 User Manual...

  • Page 14: Figure 1.3: Dimensions Of Apc-3420

    Figure 1.3: Dimensions of APC-3420 APC-3X20 User Manual...

  • Page 15: Brief Description Of Apc-3X20

    Industrial SSD), 1 x SD slot onboard, 1 x CF slot for option, and so on. It is CE, FCC Class A, IEC 60945 certificated, and meets IACS E10 and DNV Standard, and the model is designed for marine application. Figure 1.4: Front View of APC-3220 Figure 1.5: Rear View of APC-3220 APC-3X20 User Manual...

  • Page 16: Figure 1.6: Front View Of Apc-3920

    Figure 1.6: Front View of APC-3920 Figure 1.7: Rear View of APC-3920 APC-3X20 User Manual...

  • Page 17: Figure 1.8: Front View Of Apc-3420

    Figure 1.8: Front View of APC-3420 Figure 1.9: Rear View of APC-3420 APC-3X20 User Manual...

  • Page 18: Mounting Of Apc-3X20

    1.5 Mounting of of APC-3X20 Figure 1.10: Panel Mounting of APC-3X20 Figure 1.11: Adjustable Mounting Bracket of APC-3X20 APC-3X20 User Manual...

  • Page 19: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Mainboard Introduction SBC-7110 is a 4" industrial motherboard developed on the basis of Intel Haswell-U Processors, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual GbE ports, 5-COM ports and one Mini PCIE configuration, one eDP port, one HDMI port, one LVDS interface.
  • Page 20 Storage 1 x SATAIII Connector (7P) 1 x SATAIII Connector (7P+15P) 1 x SD Slot Ethernet 2 x PCIe Gbe LAN by Intel 82574L 2 x USB 3.0 (type A)stack ports (USB3) (USB 3.0: USB3-1/USB3-2, USB 2.0: USB1/USB2) 2 x USB 2.0 Pin header for CN3 (USB3/USB4) 1 x USB 2.0 Pin header for CN2 (USB5) 1 x USB 2.0 Pin header for CN1 (USB7 or Touch, option) 1 x USB 2.0 for MPCIE1 (USB8)
  • Page 21 Management 1 x 3-pin power input connector Switches and 1 x Power on/off switch (BT1/BT2/CN2/CN3) LED Indicators 1 x Reset (CN2) 1 x HDD LED status (CN2) 1 x Power LED status (CN1) 1 x Buzzer External I/O port 2 x COM Ports (COM1/COM2) 2 x USB 3.0 Ports (stack) 2 x RJ45 GbE LAN Ports 1 x HDMI Port...

  • Page 22: Figure 2.1: Mainboard Dimensions

    (units :mm) Figure 2.1: Mainboard Dimensions APC-3X20 User Manual...

  • Page 23: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top Figure 2.3: Jumpers and Connectors Location- Board Bottom APC-3X20 User Manual...

  • Page 24: Jumpers Setting And Connectors

    2.4 Jumpers Setting and Connectors 1. CPU1: (FCBGA1168), onboard Intel Haswell-U Processors. Model Processor Number Cores/Threads Remarks SBC-7110-i34010-4G I3-4010U 1.7GHz 2 / 4 SBC-7110-i34010P-4G i3-4010U 1.7GHz 2 / 4 Option SBC-7110-i54310-4G i5-4310U 2.0 up to 3.0GHz 2 / 4 Option SBC-7110-i54310P-4G i5-4310U 2.0 up to 3.0GHz...
  • Page 25 Model Memory SBC-7110-i34010-4G SBC-7110-i34010P-4G 4GB (option) SBC-7110-i54310-4G 4GB (option) SBC-7110-i54310P-4G 4GB (option) SBC-7110-i74510-4G 4GB (option) SBC-7110-i74510P-4G 4GB (option) 5. S-422 (PIN6): (Switch), ATX Power and Auto Power on jumper setting. S-422(Switch) Mode Pin6 (Off) ATX Power Pin6 (On) Auto Power on (Default) 6.
  • Page 26 Procedures of CMOS clear: a) Turn off the system and unplug the power cord from the power outlet. b) To clear the CMOS settings, use the jumper cap to close pins 1 and 2 for about 3 seconds then reinstall the jumper clip back to pins open. c) Power on the system again.
  • Page 27 Pin2 BAT2_LED- Pin3 Ground Pin4 RST_EC 11. DC_IN1: (5.08mm Pitch 1x3 Pin Connector), DC9V~36V System power input connector. Pin# Signal Name Pin1 DC+9V~36V Pin2 Ground Pin3 Model DC_IN1 SBC-7110-i34010U-4G 180°Connector SBC-7110-I54310U-4G 180°Connector SBC-7110-I74510U-4G 180°Connector SBC-7110-I34010UP-4G 45°Connector SBC-7110-I54310UP-4G 45°Connector SBC-7110-I74510UP-4G 45°Connector 12.
  • Page 28 15. JP6: (2.0mm Pitch 2x2 Pin Header),LVDS jumper setting. Function (CN1) Pin1-Pin2 (Close) Signal channel LVDS Pin1-Pin2 (Open) Dual channel LVDS (Default) Pin3-Pin4 (Close) 8/24 bit (Default) Pin3-Pin4 (Open) 6/18 bit 16. U22: AT24C02-DIP8,The EEPROM IC（U22）is the set of LVDS resolution. If you need other resolution settings, please upgrade U22 data.
  • Page 29 18. CN1: (1.25mm Pitch 2x20 Connector, DF13-40P), For 18/24-bit LVDS output connector, Fully supported by Parad PS8625(DP to LVDS), the interface features dual channel 24-bit output. Low Voltage Differential Signaling, A high speed, low power data transmission standard used for display connections to LCD panels.
  • Page 30 Ground Ground EDP_BKLT_EN EDP_TXN_1 EDP_BKLT_CTRL EDP_TXP_1 EDP_VDD_EN Ground EDP_TXN_2 EDP_TXN_0 EDP_TXP_2 EDP_TXP_0 Ground Ground EDP_TXN_3 EDP_AUX_N EDP_TXP_3 EDP_AUX_P EDP_DISP_UTIL 12C1_SCL EDP_HP_CN 12C1_SDA Ground Ground USB7 (option) USB7 USB7_P USB7_N (option) 5V_S5_USB 5V_S5_USB Power LED PWR_LED+ Ground Power LED 20. JP4: (2.0mm Pitch 2x2 wafer Pin Header), USB3(CN1) or Touch jumper setting.
  • Page 31 22. LED1: LED1: LED STATUS. Green LED for Touch Power status. 23. JP1: (2.0mm Pitch 2x3 Pin Header), COM1 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM1 port. JP1 Pin# Function Close 1-2 COM1 RI (Ring Indicator) (default) Close 3-4 COM1 Pin9: DC+5V...
  • Page 32 26. COM1 (Type DB9M), Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. COM1 port is controlled by pins No. 1~6 of JP1, select output Signal RI or 5V or 12V, For details, please refer to description of JP1 and S_232 and S_422 setting.
  • Page 33 RS485 (option) Pin# Signal Name 485- 485+ Ground BIOS Setup: Advanced/F81216 Super IO Configuration/Serial Port 0 Configuration 【RS-485】 27. JP2: (2.0mm Pitch 2x3 Pin Header), COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port. JP2 Pin# Function Close 1-2...
  • Page 34 RTS (Request To Send) CTS (Clear To Send) JP2 select Setting (RI/5V/12V) 29. SATA_P: (2.5mm Pitch 1x2 box Pin Header), One onboard 5V output connector are reserved to provide power for SATA devices. Pin# Signal Name +DC5V Ground Note: Output current of the connector must not be above 1A. 30.
  • Page 35 connected to headphone or amplifier. Line In is used for the connection of external audio source via a Line in cable. MIC is the port for microphone input audio. Signal Name Pin# Pin# Signal Name GND_AUD LINE-OUT-L LINE-OUT-R FRONT_JD LINE1_JD LINE-IN-L LINE-IN-R MIC-IN-L...
  • Page 36 39. BUZ1: Onboard buzzer. 40. CN2: (DF13-30P Connector), For expand output connector, It provides eight GPIO, one RS422 or RS485, one USB2.0, one Power on/off, one Reset. Function Signal Name Pin# Pin# Signal Name Function 5V_S5 5V_S5 PCH_GPIO49 GPIO_IN2 GPIO_IN1 PCH_GPIO48 PCH_GPIO51 GPIO_IN4...
  • Page 37 Pin# Signal Name Ground EC_GPIO1 EC_GPIO2 EC_GPIO3 EC_GPIO4 EC_GPIO5 EC_GPIO6 EC_GPIO7 EC_GPIO8 3.3V_ALLS_EC 42. CN3: (1.27mm Pitch 2X30 Female Header), For expand output connector,It provides four GPIO, two USB 2.0,one PS/2 mouse, one PS/2 keyboard, two uart, one PCIex1, one SMbus. It’s connected to the TB-528 riser Card Function Signal Name Pin#...
  • Page 38 Ground Ground PCIE1_TX_N0 PE1_TX_P0 PCIE1_RX_N0 PE1_RX_P0 PCIE PCIE Ground Ground CLK_100M_PE1_N CLK_100M_PE1_P PCIE1_WAKE_N PLT_RST_BUF2- SMB_CLK_S5 SMB_DATA_S5 SMBUS SMBUS CLKREQ_PE1- Ground PCIE 3P3V_S5 PWRBTN_ON- Power Auto on 3P3V_S5 3P3V_S5 12V_S0 12V_S0 43. TB-528C2ME1 (option): SBC-7110 Riser Card, TB-528C2ME1 CN3 connect to SBC-7110 CN3 pin Header. TB-528C2ME1 Top: CN3: (1.27mm Pitch 2x30 Pin Header), connect to SBC-7110 CN3 pin Header.
  • Page 39 Signal Name Function support PCIe 1X USB2.0 (USB2) SMBus H1/H2: MPCIE1 SCREW HOLES, H2 for mini PCIE card (30mm x 30mm) assemble. H1 for mini PCIE card (30mm x 50.95mm) assemble. LED1: Mini PCIe devices LED Status. SIM1: (SIM Socket 6 Pin), Support SIM Card devices. PS2: (2.0mm Pitch 1x6 Pin Wafer), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard or mouse via a dedicated cable for direct used.
  • Page 40 USB_23: (2.0mm Pitch 2x5 Pin Header), Front USB connector, it provides one USB port via a dedicated USB cable, speed up to 480Mb/s. Signal Name Pin# Pin# Signal Name 5V_USB23 5V_USB23 USB4_N USB3_N (option, NC) USB4_P USB3_P (option, NC) Ground Ground Ground Note:...
  • Page 41 DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP5 Setting: Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) JP6: (2.0mm Pitch 2x3 Pin Header), COM6 setting jumper, pin 1~6 are used to select signal out of pin 9 of COM6 port.
  • Page 42 Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) COM_6 (option, SBC-7110/COM4): (2.0mm Pitch 2x5 Pin Header), COM6 Port, up to one standard RS232 port are provided. They can be used directly via COM cable connection. Signal Name Pin# Pin#...
  • Page 43 PS2: (2.0mm Pitch 1x6 Pin Wafer), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard or mouse via a dedicated cable for direct used. Pin# Signal Name KBDATA MSDATA Ground KBCLK MSCLK GPIO1: (2.0mm Pitch 2x5 Pin Header), General-purpose input/output port, it provides a group of self-programming interfaces to customers for flexible use.
  • Page 44 even hardware damages. JP5: (2.0mm Pitch 2x3 Pin Header), COM5 setting jumper, pin 1~6 are used to select signal out of pin 9 of COM5 port. JP6 Pin# Function Close 1-2 RI (Ring Indicator) (default) Close 3-4 COM5 Pin9=+5V (option) Close 5-6 COM5 Pin9=+12V (option)
  • Page 45 Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP6 Setting: Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) COM_6 (option, SBC-7110/COM3): (2.0mm Pitch 2X5 Pin Header), COM6 Port, up to one standard RS232 port are...
  • Page 46 CN3: (1.27mm Pitch 2X30 Pin Header),connect to SBC-7110 CN3 pin Header. M-PCIE1： (Socket 52Pin), mini PCIe socket, it is located at the top, it supports mini PCIe devices with Smbus, SIM and PCIe signal. MPCIe card size is 30x30mm or 30x50.95mm.
  • Page 47 PS_ON1： (2.0mm Pitch 1X2 Pin Wafer), ATX Power and Auto Power on jumper setting. PS_ON Mode Close 1-2 Auto Power on (Default) Open 1-2 ATX Power PS_ON2（option）： (2.0mm Pitch 1X2 Pin Wafer). PS2： (2.0mm Pitch 1X6 Pin Wafer), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard or mouse via a dedicated cable for direct used.
  • Page 48 USB_23（option）： (2.0mm Pitch 2x5 Pin Header), Front USB connector, it provides one USB port via a dedicated USB cable, speed up to 480Mb/s. Signal Name Pin# Pin# Signal Name 5V_USB23 5V_USB23 USB4_N USB3_N USB4_P USB3_P Ground Ground Ground Note: Before connection, make sure that pinout of the USB Cable is in accordance with that of the said tables.
  • Page 49 Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP5 Setting: Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) JP6：...
  • Page 50 TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP6 Setting: Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) S1： PWR BT: POWER on/off Button, They are used to connect power switch button.
  • Page 51 CN3： (1.27mm Pitch 2X30 Pin Header), connect to SBC-7110 CN3 pin Header. M-PCIE1： (Socket 52Pin), mini PCIe socket, it is located at the top, it supports mini PCIe devices with Smbus, USB2.0,SIM and PCIe signal. MPCIe card size is 30x30mm or 30x50.95mm.
  • Page 52 USB_IN（option）： (2.0mm Pitch 2x5 Pin Header) ,Front USB connector, it provides two USB port via a dedicated USB cable, speed up to 480Mb/s. Signal Name Pin# Pin# Signal Name 5V_USB34 5V_USB34 NC (USB4_N) NC (USB3_N) NC (USB4_P) NC (USB3_P) Ground Ground Ground Note:...
  • Page 53 Signal Name Pin# Pin# Signal Name Ground JP6 Setting: RI/5V/12V COM5(SBC-7110/COM3)： (2.0mm Pitch 2X5 Pin Header), COM5 Port, up to one standard RS232 port are provided. They can be used directly via COM cable connection. Signal Name Pin# Pin# Signal Name Ground GPIO1：...
  • Page 54 Pin# Channel Signal Name Function CANL2 CAN bus Signal L Terminal resistor R-(internally connected to CANL2) CAN2 Shield cable (FG) Terminal resistor R+(internally connected to CANH2) CANH2 CAN bus Signal H CANL1 CAN bus Signal L Terminal resistor R-(internally connected to CANL1) CAN1 Shield cable (FG) Terminal resistor R+(internally connected to CANH1)

  • Page 55: Bios Setup

    Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation, press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices.

  • Page 56: Main Settings

    3.3 Main Settings System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date. Month: 01 to 12 Date: 01 to 31...

  • Page 57: Advanced Settings

    3.4 Advanced Settings 3.4.1 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled] Enable Hibernation: [Enabled] [Disabled] ACPI Sleep State: [S1 only (CPU Stop Clock) ] [S3 (Suspend to RAM)] [Suspend Disabled] [Both S1 and S3 available for OS to choose from] Lock Legacy Resources: [Disabled] [Enabled]...
  • Page 58 S3 Video Repost: [Disabled] [Enabled] ACPI Low Power SO Idle: [Disabled] [Enabled] 3.4.2 CPU Configuration Intel(R) Core(TM) i5-4310U @ 2.00GHz CPU Signature 40651 Processor Family Microcode Patch FSB Speed 100 MHz Max CPU Speed 2000 MHz Mix CPU Speed 800 MHz CPU Speed 2400 MHz Processor Cores...
  • Page 59 EIST [Enabled] Turbo Mode [Enabled] …… 3.4.3 SATA Configuration SATA Configuration(S) [Enabled] [Disabled] SATA Mode Selection [AHCI] [RAID] SATA Test Mode [Disabled] [Enabled] Aggressive LPM Support [Enabled] [Disabled] SATA Controller Speed [Default] [Gen1] [Gen2] [Gen3] Software Feature Mask Configuration Serial ATA Port 0 Empty Software Preserve Unknown Serial ATA Port 1...
  • Page 60 [Enabled] [Disabled] XHCI Hand-off: [Enabled] [Disabled] EHCI Hand-off: [Disabled] [Enabled] USB Mass Storage Driver Support [Enabled] [Disabled] USB hardware delays and time-outs: USB transfer time-out: [20 sec] [10 sec] [5 sec] [1 sec] Device reset time-out: [20 sec] [10 sec] [30 sec] [40 sec] Device power-up delay...

  • Page 61: Chipset Settings

    3.4.6 F81216 Second Super IO Configuration Super IO chip F81216 Second IO Serial Port 0 Configuration UART1 Mode Selection: [RS-232] [RS-485] [RS-422] Serial Port 1 Configuration Change Settings [Auto] Serial Port 2 Configuration Change Settings [Auto] Serial Port 3 Configuration Change Settings [Auto] 3.4.7 Intel (R) 82574L Gigabit Network Configuration-70:B3:D5:E7...
  • Page 62 3.5.1 PCH-IO Configuration Intel PCH RC Version 1.8.0.0 Intel PCH SKU Name Premium SKU Intel PCH Rev ID 04/B2 PCH Express Configuration PCI Express Clock Gating [Enabled] DMI Link ASPM Control [Enabled] DMI Link Extended Synch Control [Disabled] PCIe-USB Glitch W/A [Disabled] PCIE Root Port Function Swapping [Disabled]...

  • Page 63: Boot Settings

    3.6 Boot Settings 3.6.1 Administrator Password 3.6.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all previously typed CMOS passwords. You will be requested to confirm the password. Type the password again and press Enter key.

  • Page 64: Security Settings

    up. A confirmation message will be shown on the screen as to whether the password will be disabled. You will have direct access to BIOS setup without typing any password after system reboot once the password is disabled. Once the password feature is used, you will be requested to type the password each time you enter BIOS setup.

  • Page 65: Save & Exit Settings

    [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Disabled] [Enabled] Boot Option Priorities Boot Option #1 Sets the system boot order Hard Drive BBS Priorities [SATA PM:*** … ] Boot Option #1 SATA PM:***… ****** Disabled 3.8 Save & Exit Settings APC-3X20 User Manual...
  • Page 66 Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save & reset Save Configuration and reset? [Yes] [No] Discard Changes and Reset Reset Without Saving Reset without saving? [Yes]...

  • Page 67: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 7. The software and drivers are included with the motherboard. The contents include Intel CORE TM SoC chipset driver, VGA driver, LAN drivers, Audio driver, USB 3.0 Driver, Intel®...

  • Page 68: Intel (R) Core Amt Driver

    4.1 Intel(R) CORE TM SoC Chipset To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) CORE TM SoC Chipset from the list Step 2. Click Next to setup program. APC-3X20 User Manual...
  • Page 69 Step 3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step 4. Click Install to begin the installation. APC-3X20 User Manual...

  • Page 70: Intel(R) Vga Chipset

    Step 5. Click Finish to complete the setup process. 4.2 Intel(R) VGA Chipset To install the VGA drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) VGA Chipset from the list. APC-3X20 User Manual...
  • Page 71 Step 2. Click Automatically run WinSAT and enable the Windows Aero desktop theme(if supported). Click Next. Step 3. Read license agreement. Click Yes. APC-3X20 User Manual...
  • Page 72 Step 4. Click Next to continue. Step 5. Click Next to continue. APC-3X20 User Manual...

  • Page 73: Intel(R) Lan Driver

    Step 6. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. 4.3 Intel(R) LAN Driver To install the Intel (R) LAN driver, please follow the steps below. Step 1. Select Intel(R) 82574L LAN Driver from the list. APC-3X20 User Manual...
  • Page 74 Step 2. . Click Next. Step 3. Read license agreement. Click I accept the terms in the license agreement. Click Next. APC-3X20 User Manual...
  • Page 75 Step 4. Click Next to continue. Step 5. Click Install to begin the installation. APC-3X20 User Manual...

  • Page 76: Realtek Alc662 Hd Audio Driver

    Step 6. Click Finish to exit the wizard. 4.4 Realtek ALC662 HD Audio Driver To install the Realtek ALC662 HD Audio Driver, please follow the steps below. Step 1. Select Realtek AL662 HD Audio Driver from the list APC-3X20 User Manual...
  • Page 77 Step 2. Click Next to continue. Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. APC-3X20 User Manual...

  • Page 78: Usb 3.0 Driver

    4.5 USB 3.0 Driver To install the USB 3.0 Driver, please follow the steps below. Step 1. Select USB 3.0 Driver from the list Step 2. Click Next to continue. APC-3X20 User Manual...
  • Page 79 Step 3. Read the license agreement. Then click Yes to continue. Step 4. Click Next to continue. APC-3X20 User Manual...
  • Page 80 Step 5. Click Next to continue. Step 6. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. APC-3X20 User Manual...

  • Page 81: Intel(R) Mei Driver

    4.6 Intel(R) MEI Driver To install the Intel(R) MEI Driver, please follow the steps below. Step 1. Select Intel(R) MEI Driver from the list. Step 2. Click Next to continue. APC-3X20 User Manual...
  • Page 82 Step 3. Read the License Agreement and then click Yes to continue. Step 4. Click Next to continue. APC-3X20 User Manual...
  • Page 83 Step 5. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. APC-3X20 User Manual...

  • Page 84: Chapter 5 Touch Screen Installation

    Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your touch screen work with different operating systems. 5.1 Windows 7/8/8.1 Universal Driver Installation for PenMount 6000 Series Before installing the Windows 7/8/8.1 driver software, you must have the Windows 7/8/8.1 system installed and running on your computer.
  • Page 85 Step 2. Click Next to continue. Step 3. Read the license agreement. Click I Agree to agree the license agreement. APC-3X20 User Manual...
  • Page 86 Step 4. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. Step 5. Wait for installation. Then click Next to continue. APC-3X20 User Manual...
  • Page 87 Step 6. Click Continue Anyway. Step 7. Click Finish to complete installation. APC-3X20 User Manual...

  • Page 88: Software Functions

    5.2 Software Functions 5.2.1 Software Functions Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. 1. After installation, click the PenMount Monitor icon “PM” in the menu bar. 2.
  • Page 89 Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ESC’. Step 1. Please select a device then click “Configure”. You can also double click the device too.
  • Page 90 NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: Step 3.Come back to “PenMount Control Panel” and select Tools then click Advanced Calibration.
  • Page 91 NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. Plot Calibration Data Check this function and a touch panel linearity comparison graph appears when you have finished Advanced Calibration. The blue lines show linearity before calibration and black lines show linearity after calibration.
  • Page 92 Setting Touch Mode This mode enables and disables the mouse’s ability to drag on-screen icons – useful for configuring POS terminals. Mouse Emulation – Select this mode and the mouse functions as normal and allows dragging of icons. Click on Touch – Select this mode and mouse only provides a click function, and dragging is disables.
  • Page 93 About This panel displays information about the PenMount controller and driver version. Multiple Monitors Multiple Monitors support from two to six touch screen displays for one system. The PenMount drivers for Windows 7/8/8.1 support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 94 2. When the mapping screen message appears, click OK. 3. Touch each screen as it displays “Please touch this monitor”. Following this sequence and touching each screen is called mapping the touch screens. APC-3X20 User Manual...
  • Page 95 4. Touching all screens completes the mapping and the desktop reappears on the monitors. 5. Select a display and execute the “Calibration” function. A message to start calibration appears. Click OK. 6. “Touch this screen to start its calibration” appears on one of the screens. Touch the screen.
  • Page 96 About This panel displays information about the PenMount controller and this driver version. PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 7/8/8.1 system when you turn on PenMount Monitor in PenMount Utilities. PenMount Monitor has the following function Control Panel Open Control Panel Windows...
  • Page 97 Configuring the Rotate Function 1. Install the rotation software package. 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically. Touch this point and rotation is mapped. NOTE: The Rotate function is disabled if you use Monitor Mapping APC-3X20 User Manual...
