- Page 1 USB 3.0 4K Mini Docking Station...
-
Page 2: Table Of Contents
Table of Contents .......... 1 AFETY NSTRUCTIONS ............1 OPYRIGHT ............1 RADEMARKS REGULATORY COMPLIANCE ......2 FCC C ..........2 ONDITIONS CE ..............2 WEEE I ........... 2 NFORMATION INTRODUCTION ..........3 ............4 EATURES ..........4 ACKAGE ONTENTS ........ - Page 3 DISPLAY CONFIGURATION ......14 ..........14 TILITY SETTINGS ......15 ESCRIPTION OF THE SETTINGS ......17 ULTI MONITOR CONFIGURATION ..........18 XTENDED MODE ..........19 IRROR MODE ......... 20 ET THE PRIMARY MONITOR ......... 20 INDOWS SHORTCUT ........21 UPPORTED RESOLUTION AUDIO CONFIGURATION .........
-
Page 4: Safety Instructions
Before attempting to connect, operate or adjust this product, please save and read the User's Manual completely. The style of the product shown in this User's Manual may be different from the actual unit due to various models. Safety Instructions Always read the safety instructions carefully: Keep this User’s Manual for future reference Keep this equipment away from humidity... -
Page 5: Regulatory Compliance
Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received and include interference that may cause undesired operation. -
Page 6: Introduction
Introduction The USB 3.0 4K Mini Docking Station is designed for extra connectivity demands. You can extend the connection of a computer to extra USB peripherals, Ethernet network and the audio output/input through one single USB cable. With the built-in USB 3.0 ports, the docking station enables you to enjoy the super speed data transmission between USB peripherals. -
Page 7: Features
Features Ultra slim size design USB 3.0 downstream port x4 - Downward compatible with USB 2.0/1.1 - Support BC 1.2 charging x2 (Self-powered mode) Display Port - HDMI: resolution up to 3840x2160 pixels * - DVI: resolution up to 2048x1152 pixels Support Bus-powered mode ** Support audio 2.1 channel (Audio combo jack) Support Gigabit Ethernet... -
Page 8: System Requirements
System Requirements Operating Systems: ® ® - Microsoft: Windows 7 SP1 or later/ Windows ® ® Windows 8.1/ Windows... -
Page 9: Product Overview
Product Overview Front ITEM DESCRIPTION Indicate Power ON/OFF 1 Power LED Connect to a microphone, speaker or 2 Audio Port earphone (Combo jack) Connect to USB 3.0 devices 3 USB 3.0 Port * With BC 1.2 charging... -
Page 10: Rear
Rear ITEM DESCRIPTION 4 DVI connector Connect to a DVI monitor Connect to USB 3.0 devices 5 USB 3.0 Port * 6 HDMI connector ** Connect to a HDMI monitor Connect to a computer 7 USB 3.0 Port (Type B) Connect to the power adapter 8 Power jack Connect to an Ethernet. -
Page 11: Connection
Connection To connect the USB peripherals, Ethernet, speaker and microphone, follow the illustrations below to connect the corresponding connectors. NOTE: Please note that when using the HDMI and the DVI connector simultaneously, the HDMI connector will not be able to reach 4K resolutions. -
Page 12: Installation
Installation Caution: DO NOT connect the docking station to a computer before installing the provided driver Note that the strings of the driver and the screenshots on this user's manual may vary slightly from each operating system. ® Windows 1. Insert the provided CD into your disc drive. 2. - Page 13 3. Click I Accept for the next step, and then wait for the program to install the driver. 4. Click Finish to complete the installation if prompted. NOTE: a. If the AutoPlay does not start automatically, locate and double-click on the Setup.exe file in the driver folder to launch the setup.
- Page 14 c. For some Windows Operating Systems, the driver will automatically be installed. If the driver installation doesn’t start automatically, please install the provided driver as instructed above. 5. Connect the Docking Station to a computer after the driver installation is completed. For connection details, refer to the chapter of Connection.
-
Page 15: Verifying The Installation
Verifying the installation To verify the driver of the adapter, follow the step below. 1. Access the device manager ® Windows Settings\Devices\Connected devices ® ® Windows 8/ Windows Settings\ Control Panel\ System and Security\ System\ Device manager ® Windows Control Panel\ System and Security\ Systems\ Device manager 2. - Page 16 ® * The screen shots are from Windows 8 and might vary slightly from each operating system. NOTE: If you cannot find the driver in the list, the driver may not be properly installed. Please delete the item, unplug the adapter and repeat the installation steps.
-
Page 17: Display Configuration
Display configuration NOTE: The following screenshots in this section are ® from Windows 7 operating system. It may vary slightly from each operating system. Utility settings The supplied utility allows configuring the display mode, screen rotation, screen resolution, and physical arrangement of your monitors. -
Page 18: Description Of The Settings
Description of the settings Options Description DisplayLink Enable the Windows screen resolution Manager page Check for Check the latest driver and download updates… if available Display Setting Submenu Screen Resolution Click to select an available resolution. Note that this function is invalid in mirror mode, as the resolution is defined as the resolution of the primary monitor... - Page 19 Mirror Duplicate the primary monitor to the monitor which connects with the adapter Turn off the monitor Fit to TV Adjust the size of Windows Desktop on the TV NOTE: This function works only when one add-on monitor is connected. Besides, this option will also only work in extended mode.
-
Page 20: Multi-Monitor Configuration
Multi-monitor configuration The DP, HDMI and DVI monitors can be connected through the Docking Station if monitors are already connected to the PC. Once extra monitors are connected, it can be configured to use either “mirror mode”, “extended mode” or be the primary display. NOTE: The DP and HDMI connectors can only be used one at a time. -
Page 21: Extended Mode
Extended mode Refer to the Multi-monitor configuration section to bring up the configuration window. In the Display drop-down menu, select the preferred monitor. Select Multiple Displays > Extend these displays. Click OK to confirm and exit. Once the setting is completed, simply drag and drop the application icons or the opened windows to the add-on monitor. -
Page 22: Mirror Mode
Cursor disappeared If the status remains in the extended mode but the adapter is disconnected, the desktop will still be panned to the add-on monitor. The cursor may not be found on the primary monitor in such a case. If it happens, connect the add-on monitor through the adapter again or keep moving the mouse. -
Page 23: Set The Primary Monitor
Set the primary monitor Refer to the Multi-monitor configuration section to bring up the configuration window. In the Display drop-down menu, select the preferred monitor. Check the box of Make this my main display. NOTE: For some computers, you may need to disable the main display by unchecking the box of Extend the desktop onto this monitor or Extend my Windows desktop onto this... -
Page 24: Supported Resolution
Supported resolution Before adjusting the resolution, refer to the table below for the supported resolution. Refresh rate Refresh rate 16 bit 32 bit 640x480 60 72 75 85 60 72 75 85 800x600 SVGA 56 60 72 75 56 60 72 75 85 1024x768 60 70 75 85 60 70 75 85... -
Page 25: Audio Configuration
Audio configuration By default, when the docking station is connected to a computer, the audio configuration may be changed to USB (Multimedia) Audio Device automatically (this setting depends on models). If it does not work, follow the steps below to setup. ®... -
Page 26: Uninstalling The Driver
Uninstalling the driver 1. Follow the instructions to find the driver path, and then right-click on DisplayLink Graphics to uninstall the driver. ® ® 7/ / / / Widnows Widnows Control Panel > Programs > Programs and Features > Uninstall or change the program ®... - Page 27 3. Click Yes to restart your computer. You can also disconnect the video connection now.
-
Page 28: Specification
Specification HDMI Female Connector * Connector Video Output DVI Female Connector USB B Type Female Connector Host Upstream Link USB A Type Female Connector HUB Downstream (USB 3.0 x4, with BC1.2 x2) Link 3.5mm stereo combo jack Audio Port RJ45 Connector Ethernet Port DC power jack Power... -
Page 29: Technical Support
If you have any technical or application issues about our products, please contact us through Good Way FAQ website: http://www.goodway.com.tw/faq.asp Simply fill in the required information on the website and submit your question to us. We will reply to you... - Page 30 USB 3.0 4K Mini Docking Station User's Manual V1.1...
