SERVICE MANUAL
Ver. 1.0 2004.11
Compact disc player
Laser
Frequency response
Dynamic range
Harmonic distortion
Outputs
Jack
type
ANALOG
Phono
OUT
jacks
DIGITAL
Optical
OUT
output
(OPTICAL)
connector
PHONES
Stereo
phone
jack
Sony Corporation
9-879-248-01
Audio Group
2004K1678-1
Published by Sony Engineering Corporation
© 2004.11
SPECIFICATIONS
Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
2 Hz to 20 kHz ± 0 5 dB
More than 93 dB
Less than 0.0045%
Maximum
Load
output level
impedance
2 V
Over 10
(at 50 kilohms)
kilohms
–18 dBm
Wave
length:
660 nm
10 mW
32 ohms
CDP-C5CS
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Pick-up Name
General
Power requirements
120 V AC, 60 Hz
Power consumption
11 W
Dimensions (approx.)
430 x 110 x 400 mm
(w/h/d)
(17 x 4 3/8 x 15 3/4 in.)
incl. projecting parts
Mass (approx.)
5 kg (11 lbs 1 oz)
Supplied accessories
Audio cord (2 phono plugs – 2 phono plugs) (1)
Remote commander (remote) (1)
R6 (size AA) batteries (2)
Design and specifications are subject to change
without notice.
COMPACT DISC PLAYER
US Model
Canadian Model
CDP-CE375
CDM59-5BD27
BU-5BD27
PXR-104X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDP-C5CS and is the answer not in the manual?

Questions and answers

Related Manuals for Sony CDP-C5CS

Summary of Contents for Sony CDP-C5CS

  • Page 1 (at 50 kilohms) kilohms DIGITAL Optical –18 dBm Wave output length: (OPTICAL) connector 660 nm PHONES Stereo 10 mW 32 ohms phone jack COMPACT DISC PLAYER Sony Corporation 9-879-248-01 Audio Group 2004K1678-1 Published by Sony Engineering Corporation © 2004.11...

  • Page 2: Table Of Contents

    LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.

  • Page 3: Servicing Notes

    CDP-C5CS SECTION 1 SERVICING NOTES HOW TO OPEN THE DISC TABLE WHEN POWER NOTES ON HANDLING THE OPTICAL PICK-UP SWITCH TURNS OFF BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic Insert a tapering driver into the aperture of the unit bottom, and turn break-down because of the potential difference generated by the it in the direction of the arrow (to OUT direction).

  • Page 4: General

    CDP-C5CS SECTION 2 GENERAL This section is extracted from instruction manual. Front Panel The items are arranged in alphabetical order. Refer to the pages indicated in parentheses ( ) for details. CDP-C5CS CHECK w; (11, 12) BUTTON DESCRIPTIONS PHONES jack wa (8)

  • Page 5: Disassembly

    CDP-C5CS SECTION 3 DISASSEMBLY 3-1. DISASSEMBLY FLOW • The equipment can be removed using the following procedure. 3-2.CASE (Page 6) 3-3.FRONT PANEL ASSY, IR-IN BOARD (Page 6) 3-4.CD MECHANISM BLOCK (CDM59-5BD27) (Page 7) 3-5.BASE UNIT (BU-5BD27) 3-6.TRAY ,TABLE ASSY (Page 7) (Page 8) 3-8.JUNCTION BOARD,...

  • Page 6: Case

    CDP-C5CS Note: Follow the disassembly procedure in the numerical order given. 3-2. CASE 2 two screws 3 two screws (case 3TP2) 3 × 8 (BVTP 4 case 7 panel, loading 1 two screws (case 3TP2) 3-3. FRONT PANEL ASSY, IR-IN BOARD...

  • Page 7: Cd Mechanism Block (Cdm59-5Bd27)

    CDP-C5CS 3-4. CD MECHANISM BLOCK (CDM59-5BD27) 6 two screws 4 two screws × 8 (BVTP 3 3 × 8 (BVTP 7 CDM59-5BD27 3 three screws × 8 (BVTP 3 5 tray 2 CN311 1 CN302 3-5. BASE UNIT (BU-5BD27) 3 two screws (+PTPWHM 2.6),...

  • Page 8: Tray, Table Assy

    CDP-C5CS 3-6. TRAY, TABLE ASSY 8 screw (+PTPWHM 2.6), floating 9 tray 7 table assy 2 bracket (guide) 6 CN15 3 three screws 1 three screws (M 2.6), +BTTP (M 2.6), +BTTP 4 bracket (guide) 3-7. SENSOR BOARD 1 belt (rotary)

  • Page 9: Junction Board, Loading Motor Board

    CDP-C5CS 3-8. JUNCTION BOARD, LOADING MOTOR BOARD 6 two screws (M 2.6), +BTTP 4 JUNCTION board 2 CN13 7 LOADING MOTOR board 5 belt (loading) 1 CN14 3 three screws (M 2.6), +BTTP 3-9. OPTICAL PICK-UP 4 connector 3 optical pick-up...

  • Page 10: Test Mode

    CDP-C5CS SECTION 4 TEST MODE ADJ MODE Connecting Location: – MAIN BOARD (Component Side) – NOTE: This mode cannot be performed without a general remote com- mander. 1. Chuck the CD first, and then turn OFF the power. 2. Short-circuit the test point TP1 (ADJ) of the MAIN board and ground with a lead wire.
  • Page 11 CDP-C5CS Buttons and Corresponding Button Numbers All lit Button Button Number or Display ALL1DISCS DISC1 PROGRAM REPEAT 1 SHUFFLE 9 10 DISC2 EDIT DISC TRACK PEAK STEP TIME 11 12 13 14 15 DISC3 FADE 16 17 18 19 20...
  • Page 12 CDP-C5CS AGING MODE For the aging mode, three modes of all mode, disc table mode, and loading mode are available. This set has the Aging mode for operation check of the mechanism deck. • If a failure occurred The aging operation stops and a faulty status is displayed on the fluorescent indicator tube.

  • Page 13: Electrical Adjustment

    CDP-C5CS SECTION 5 ELECTRICAL ADJUSTMENTS NOTE: Procedure: 1. CD Block is basically designed to operate without adjustment. 1. Set the test disc (PATD-012). Disc chucking operation is Therefore, check each item in order given. complete, then press the [POWER] button to turn the power 2.
  • Page 14 CDP-C5CS E-F Balance Check Checking Location: Connection: – BD BOARD (Conductor Side) – oscilloscope BD board TP (TE1) TP (VC) – Procedure: 1. Set the test disc (PATD-012). Disc chucking operation is complete, then press the [POWER] button to turn the power off.

  • Page 15: Diagrams

    CDP-C5CS SECTION 6 DIAGRAMS • Circuit Boards Location THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) SENSOR board For Schematic Diagrams. For Printed Wiring Boards.

  • Page 16: Block Diagram - Bd Section

    CDP-C5CS 6-1. BLOCK DIAGRAM — BD SECTION — IC101 OPTICAL PICK-UP IC131 DIGITAL SERVO RF AMP BLOCK DIGITAL SIGNAL PROCSSOR FOCUS/TRACKIG DIGITAL FILTER (PXR-104X) IC351 J881 D/A CONVERTER ERROR AMP IC303 HEADPHONE AMP DIGITAL OPTICAL R-CH RF AC RFAC D OUT...

  • Page 17: Display Section

    CDP-C5CS — DISPLAY SECTION — IC301(2/2) SYSTEM CONTROLLER FL801 FLUORESCENT INDICATOR TUBE Q301 BUFFER XTAL X301 10MHz EXTAL T601 IC802 J1001 POWER REMOTE IR REMOTE TRANSFORMER CONTROL IR IN RMIN S812-816 RECEIVER FUNCTION KEY3 Q1001 INVERTER S817-821 D605 FUNCTION Q601...

  • Page 18: Printed Wiring Board - Bd Section

    CDP-C5CS • See page 15 for Circuit Boards Location. 6-2. PRINTED WIRING BOARD — BD SECTION — (SPINDLE) (LIMIT IN) (SLED) IC150 (VC) IC131 IC101 (FE1) MAIN (TE1) BOARD (Page 22) TP (RFDC) TP (RFAC) • Semiconductor Location Ref. No.

  • Page 19: Schematic Diagram - Bd Section

    CDP-C5CS • See page 26 for Waveforms. • See page 26, 27 for IC Block Diagrams. 6-3. SCHEMATIC DIAGRAM — BD SECTION — (RFAC) 120k (RFDC) OPTICAL PICK UP BLOCK PXR-104X (TE1) (VC) CONVERTER (FE1) (SE1) X191 16MHz M101 (SPINDLE)

  • Page 20: Printed Wiring Board - Cdm59 Comb Section

    CDP-C5CS • See page 15 for Circuit Boards Location. 6-4. PRINTED WIRING BOARD — CDM59 COMB SECTION — MAIN BOARD (Page 22) IC11 CDP-C5CS...

  • Page 21: Schematic Diagram - Cdm59 Comb Section

    CDP-C5CS • See page 27 for IC Block Diagram. 6-5. SCHEMATIC DIAGRAM — CDM59 COMB SECTION — MAIN BOARD (Page 23) No mark:CD PLAY CDP-C5CS...

  • Page 22: Printed Wiring Board - Main Section

    CDP-C5CS • See page 15 for Circuit Boards Location. 6-6. PRINTED WIRING BOARD — MAIN SECTION — (CHASSIS) (CHASSIS) HP BOARD DISPLAY (Page 24) BOARD (Page 24) IR REMOTE IR IN CN1102 IC603 IC601 TP1 (ADJ) IC602 TP2 (AFDJ) POWER SW...

  • Page 23: Schematic Diagram - Main Section

    CDP-C5CS • See page 26 for Waveform. • See page 28 for IC Pin Function Description. 6-7. SCHEMATIC DIAGRAM — MAIN SECTION — DISPLAY BOARD BD BOARD (Page 25) (Page 19) GP1FA550TZ CN1101 R507 100 1/4W HP BOARD (Page 25)

  • Page 24: Printed Wiring Board - Panel Section

    CDP-C5CS • See page 15 for Circuit Boards Location. 6-8. PRINTED WIRING BOARD — PANEL SECTION — PUSH ENTER IC802 (FLUORESCENT INDICATOR TUBE) MAIN TIME EDIT BOARD (Page 22) PHONES MAIN BOARD (Page 22) POWER MAIN BOARD (Page 22) CDP-C5CS...

  • Page 25: Schematic Diagram - Panel Section

    CDP-C5CS 6-9. SCHEMATIC DIAGRAM — PANEL SECTION — REMOTE CONTROL POWER RECEIVER (FLUORESCENT INDICATOR TUBE) MAIN BOARD (Page 23) PUSH ENTER TIME EDIT MAIN BOARD (Page 23) PHONES MAIN BOARD (Page 23) No mark:CD PLAY CDP-C5CS...
  • Page 26 CDP-C5CS • Waveforms • IC Block Diagrams – BD Board – – MAIN Board – – BD Board – IC101 CXD2587Q IC301 es (XTAL) IC101 yj (XTAO) IC101 ra (TE) (CD Play Mode) 4.2 Vp-p 3.1 Vp-p 0.2 Vp-p ERROR...
  • Page 27 CDP-C5CS IC131 CXA2581N DC_OFST RW/ROM RFDCI DVCC 11 RFDCO EQ IN 26 RFC 25 VFC 24 BST AC SUM ON/OFF 23 RFG VOFST 22 VCC RW/ROM VOFST RW/ROM RW/ROM 19 TE_BAL DVCC RW/ROM 18 TE APC-OFF(Hi-Z) RW/ROM SW 12 RW/ROM...
  • Page 28 CDP-C5CS • IC Pin Function Description MAIN BOARD IC301 CXP82532-013Q (SYSTEM CONTROLLER) Pin No. Pin Name Description BUSIN Sircs remote control signal input terminal Not used (pull up) RMIN Remote control signal input from the remote control receiver (IC802) Not used (pull up)
  • Page 29 CDP-C5CS Pin No. Pin Name Description 38 to 57 P1 to P20 Segment drive signal output to the fluorescent indicator tube (FL801) 58 to 62 Not used (open) 63 to 70 G1 to G8 Grid drive signal output to the fluorescent indicator tube (FL801) —...

  • Page 30: Exploded Views

    CDP-C5CS SECTION 7 EXPLODED VIEWS NOTE: • -XX and -X mean standardized parts, so they • Items marked “*” are not stocked since they The components identified by mark 0 or may have some difference from the original are seldom required for routine service.

  • Page 31: Front Panel Section

    CDP-C5CS 7-2. FRONT PANEL SECTION FL801 not supplied supplied with J881 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark X-2024-234-1 PANEL ASSY, FRONT 3-087-053-01 +BVTP2.6 (3CR) 3-354-981-11 SPRING (SUS), RING 4-231-690-01 HOLDER (FL A) 4-231-928-11 KNOB (AMS)

  • Page 32: Cd Mechanism Section (1) (Cdm59-5Bd27)

    CDP-C5CS 7-3. CD MECHANISM SECTION (1) (CDM59-5BD27) not supplied supplied not supplied BU-5BD27 not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-224-619-01 BRACKET (GUIDE) 4-224-603-06 TRAY 4-218-253-32 SCREW (M2.6), +BTTP 1-791-930-11 WIRE (FLAT TYPE) (6 CORE)

  • Page 33: Cd Mechanism Section (2) (Cdm59-5Bd27)

    CDP-C5CS 7-4. CD MECHANISM SECTION (2) (CDM59-5BD27) not supplied supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark X-4952-019-4 PULLEY (A) ASSY, CHUCKING 4-224-609-01 GEAR (LOADING C) 1-676-246-11 JUNCTION BOARD 4-224-608-01 COLLAR, SWING 4-218-253-32 SCREW (M2.6), +BTTP...

  • Page 34: Base Unit Section (Bu-5Bd27)

    CDP-C5CS 7-5. BASE UNIT SECTION (BU-5BD27) M101 supplied supplied M102 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 0 201 1-796-033-11 OPTICAL PICK-UP (PXR-104X) A-4725-568-A BD BOARD, COMPLETE 1-782-817-11 WIRE (FLAT TYPE) (16 CORE) 3-087-053-01 +BVTP2.6 (3CR)

  • Page 35: Electrical Parts List

    CDP-C5CS SECTION 8 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • Items marked “*” are not stocked since they When indicating parts by reference number, parts list may be different from the parts are seldom required for routine service.
  • Page 36 CDP-C5CS DISPLAY IR-IN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R143 1-216-855-11 METAL CHIP 680K 1/10W R816 1-249-427-11 CARBON 6.8K 1/4W R144 1-216-846-11 METAL CHIP 120K 1/10W R817 1-249-415-11 CARBON 1/4W R818 1-247-831-91 CARBON 1/4W...

  • Page 37: Components Identified By Mark 0 Or Dotted Line

    CDP-C5CS IR-IN JUNCTION LOADING MOTOR MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < RESISTOR > S817 1-771-349-21 SWITCH, KEYBOARD (TIME) S818 1-771-349-21 SWITCH, KEYBOARD (REPEAT) R1001 1-216-864-11 SHORT CHIP S819 1-771-349-21 SWITCH, KEYBOARD (FADER)

  • Page 38: Components Identified By Mark 0 Or Dotted Line

    CDP-C5CS MAIN POWER SW Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark D602 6-500-522-11 DIODE 10EDB40-TA2B5 R329 1-247-847-91 CARBON 4.7K 1/4W D603 6-500-522-11 DIODE 10EDB40-TA2B5 R350 1-247-807-31 CARBON 1/4W D604 6-500-522-11 DIODE 10EDB40-TA2B5 R351 1-247-807-31 CARBON...

  • Page 39: Components Identified By Mark 0 Or Dotted Line

    CDP-C5CS POWER SW SENSOR Ref. No. Part No. Description Remark < SWITCH > 0 S601 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY) (POWER) ************************************************************ 1-676-245-11 SENSOR BOARD ************** < CONNECTOR > CN10 1-750-243-11 SOCKET, CONNECTOR 6P < DIODE > 8-749-924-18 PHOTO INTERRUPTER RPI-1391 8-749-017-45 SENSOR, PHONT RPR-220C1N <...

  • Page 40: Revision History

    CDP-C5CS REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision...
