Summary of Contents for Smart-M MXWall
- Page 1 MXWall Multi-Format Video Wall Processor 32x32 HD Video Wall Controller HDMI, VGA, Composite, S-Video and Y/Pb/Pr Inputs Integrated USB Media Player Installation & User Guide...
- Page 2 USING ON-SCREEN DISPLAY / IR REMOTE CONTROL / OSD USING FRONT PANEL USING RS-232 CONTROL 9-11 FIRMWARE UPDATE LIMITED WARRANTY STATEMENT What’s in the Box? PART NO. QTY DESCRIPTION MXWALL-32x32-S MXWall: 32x32 Video Wall Controller. Power supply cord (CCPWR06) Manual User Guide...
-
Page 3: Technical Specifications
Technical Specifications VIDEO Video Amplifier Bandwidth 3.2G Input Video Signal Video (TMDS) 0.5~1.0Vpp Input DDC Signal 5 volts Compliances HDMI 1.4 and HDCP Pixel Rates Clock frequency beyond 165Mpix/second Format 4:4:4 and 4:2:2 data input formats Resolution 480p, 720p, 1080i, 1080p Input Card Format HDMI Output Card Format... - Page 4 In this guide, you will learn how to install and optimize your experience with MXWall using basic steps. We will cover setting the hardware up, activating and connecting your systems, and offer helpful tips on how to best use MXWall’s excellent selection of picture modes to enhance your video wall.
- Page 5 • Control Rooms • Shopping Centers • Security • Point-of-Sale • Entertainment Venues • Corporate Lobbies • Restaurants Operational Diagram Up to 32 Screens MXWall-Pro HDMI Input HDMI Output RS-232 Computer Gaming Console Rack Servers Blu-ray Player Video Camera Signage Player...
-
Page 6: Hardware Installation
3. Connect any input to their corresponding signal source (Blu-Ray player, computer, etc) 4. Connect the IR receiver to the IR input jack at the back of the MXWall. 5. Optionally connect an RS-232 cable from PC to the RS-232 port of the unit for additional control. - Page 7 Control Using the Front Panel Front Panel Buttons • For Menu, press the PIP and WIN buttons simultaneously. • To switch to Video Wall mode, press the WALL button. To switch to Individual mode, press the INDV button. • To switch to Quad mode, press the QUAD button. •...
-
Page 8: Ir Remote Control
IR Remote Control and through the Front Panel Buttons. IR Remote Control The MXWall will only respond to the remote control unit provided in the box. Below is the list of commands on how to control using the... - Page 9 Establish a connection to MXWall: 1. Connect a straight-through male-to-female RS-232 cable to the RS-232 connector on the PC. 2. Connect the other end of the cable to the RS-232 port of the MXWall. 3. Power on the device. Setting up the Terminal Application: 1.
- Page 10 There are two primary modes of operation for MXWall: Command Mode and CLI Mode. When connecting to the MXWall via RS-232, it will start in Command Mode. CLI Mode is a more user- friendly way of operating the StretcherPro HD and includes instructional menus. The following section details the use of the CLI Mode.
- Page 11 RS-232 Operation (continued) MODE CONSOLE COMMAND DESCRIPTION & EXAMPLE Video Wall Mode //V<CR> Stretch the input across four screens (32x32). Clone Mode //F<CR> Clone the input into the four screens Dual Horizontal //DH<CR> Stretch the input over two horizontally ar- ranged two times over Dual Vertical //DV<CR>...
-
Page 12: Firmware Update
Below are instructions on how to upgrade the firmware of your MXWall: 1. Power OFF the MXWall. 2. Connect the RS-232 cable from computer to the RS-232 port of the MXWall. 3. Download and install the chip45boot2 GUI. 4. Open the chip45boot2 GUI.
