Vizio VX32L Service Manual

Vizio VX32L Service Manual

Hdtv20a
Hide thumbs Also See for VX32L:

Advertisement

Quick Links

Download this manual See also: Service Manual, User Manual

Service Manual

Model #: VIZIO VX32L/VW32L
HDTV20A
(AUO/LPL/Samsung Panel)
V, Inc
320A Kalmus Drive Costa Mesa, CA 92626
TEL : +714-668-0588 FAX :+714-668-9099
Top Confidential

Advertisement

loading
Need help?

Need help?

Do you have a question about the VX32L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vizio VX32L

Summary of Contents for Vizio VX32L

  • Page 1: Service Manual

    Service Manual Model #: VIZIO VX32L/VW32L HDTV20A (AUO/LPL/Samsung Panel) V, Inc 320A Kalmus Drive Costa Mesa, CA 92626 TEL : +714-668-0588 FAX :+714-668-9099 Top Confidential...
  • Page 2 8. Waveforms 9. Trouble Shooting 10. Block Diagram 10-1 11. Spare parts list 11-1 12. Complete Parts List 12-1 Appendix 1. Main Board Circuit Diagram 2. Main Board PCB Layout 3. Assembly Explosion Drawing Block Diagram VIZIO VX32L/VW32L HDTV10A Service Manual...
  • Page 3 Use a power cable that is properly grounded. Always use the AC cords as follows – USA (UL); Canada (CSA); Germany (VDE); Switzerland (SEV); Britain (BASEC/BS); Japan (Electric Appliance Control Act); or an AC cord that meets the local safety standards. VIZIO VX32L/VW32L HDTV10A Service Manual...
  • Page 4 Chapter 1 Features 1. Built in TV channel selector for TV viewing. 2. Simulatnueous display of PC and TV images. 3. Connectable to PC’s analog RGB port. 4. Built in S-video, HDTV, composite video, HDMI and TV out. 5. Built in auto adjust function for automatic adjument of screen display. 6.
  • Page 5 Chapter 2 Specification 1. TFT-LCD CHARACTERISTICS LPL LC320WX3-SLC1 Item Specification Display Pixels 1,366 (H) x 768 (V) pixels Pixel Pitch 170.25 um(H) x 510.75 um(V) x RGB Color Depth 8 bits 16.7 million colors Active Display Area 697.685 mm(H)X392.256 mm(V) Brightness (panel spec) 400cd/m (typ)
  • Page 6 White x=0.28±0.03, y=0.29±0.03 x=0.64±0.03, y=0.33±0.03 Green x=0.29±0.03, y=0.60±0.03 Blue x=0.15±0.03, y=0.06±0.03 Samsung LTA320WT-L05 Item Specification Display Pixels 1,366 (H) x 768 (V) pixels Pixel Pitch 0.51075(H)X0.17025(W)*3 Color Depth 8 bits 16.7 million colors Active Display Area 697.6845(H)X392.256(V) Brightness (panel spec) 450cd/m (typ) Contrast ratio (panel spec)
  • Page 7 3. Input Connectors 1 x RF Connector for internal ATSC/QAM/NTSC Hybrid Tune 2x HDMI with HDCP plus Stereo Audio (RCA) 2x Component YPbPr plus Stereo Audio 1x RGB PC(WXGA) plus Stereo Audio 1x Composite Video plus stereo Audio 1x S-VIDEO Connect 4.
  • Page 8 Precaution Please pay attention to the followings when you use this TFT LCD module. 1. OPERATING PRECAUTIONS (1) The spike noise causes the mis-operation of circuits. It should be lower than following voltage : V=±200mV(Over and under shoot voltage) (2) Response time depends on the temperature. (In lower temperature, it becomes longer.) (3) Brightness depends on the temperature.
  • Page 9 Chapter 3 On Screen Display On Screen Display (OSD) is a friendly interface providing the function adjusting in our system. Customers could operate it only by few buttons. There is the introduction of the OSD. Main unit button MENU CH ▲ ↑...
  • Page 10 CONFIDENTIAL DO NOT COPY Page 3-2 – File No. SG-0241...
  • Page 11 B. Audio：(Bold: Default) a. Volume (0~100, 25) b. Bass (0~100, 50) c. Treble (0~100, 50) d. Balance (-50~50, 0) e. Surround (ON/OFF) f. Digital Audio Out (PCM/OFF/Dolby Digital) g. Speaker (ON/OFF) h. Lip Sync (0~5 , 0) CONFIDENTIAL DO NOT COPY Page 3-3 –...
  • Page 12 C. TV：(Bold: Default) a. Tuner Mode (Cable/Antenna) b. Auto Search c. Skip Channel d. MTS (Stereo/SAP/Mono) e. Time Zone (Eastern/Indiana/Central/Mountain/Arizona/Pacific/Alaska/Hawaii) f. Daylight Saving (ON/OFF) CONFIDENTIAL DO NOT COPY Page 3-4 – File No. SG-0241...
  • Page 13 D. Setup：(Bold: Default) a. Language (English/ Français / Espaňol) b. Minuterie de veille (OFF/30Min/60Min/90Min/120Min) c. Wide (Wide/Panoramic/Normal) d. Input Naming (AV1/AV2/COMP1/COMP2/RGB/HDMI1/HDMI2) e. CC (OFF/CC1~4) f. CC On Mute (OFF/ON) g. Style de Sous-titre h. H/V Position i. Valeurs par defaut CONFIDENTIAL DO NOT COPY Page 3-5...
  • Page 14 E. Parental：(Bold: Default) Password (Default => 0000) a. Cannel Block b. TV Rating c. Move Rating d. Check for New DTV Rating d. Block TV Unrated TV (NO/Yes) e. Access Code Edit CONFIDENTIAL DO NOT COPY Page 3-6 – File No. SG-0241...

  • Page 15: Rgb Mode

    RGB Mode A. Picture Adjust：(Bold: Default) a. Auto Adjust b. Backlight (0~100, 90) c. Brightness (0~100, 50) d. Contrast (0~100, 50) e. Color Temperature (9300/Custom/6500) f. H-Size (0~255, 127) g. H-Position (0~100, 48) h. V-Position (0~100, 47) i. Fine Tune (0~31, 29) CONFIDENTIAL DO NOT COPY Page 3-7...
  • Page 16 B. Audio：(Bold: Default) a. Volume (0~100, 25) b. Bass (0~100, 50) c. Treble (0~100, 50) d. Balance (-50~50, 0) e. Surround (ON/OFF) f. Digital Audio Out(PCM/OFF/Dolby Digital) g. Speakers (ON/OFF) h. Lip Sync (0~5 , 0) CONFIDENTIAL DO NOT COPY Page 3-8 –...
  • Page 17 C. Setup：(Bold: Default) a. Language (English/ Français / Espaňol) b. Sleep Timer (OFF/30Min/60Min/90Min/120Min) c. Wide (Wide/Normal) d. Input naming (AV1/AV2/COMP1/COMP2/HDMI1/HDMI2) e. Rest All Setting (OK/Cancel) CONFIDENTIAL DO NOT COPY Page 3-9 – File No. SG-0241...
  • Page 18 AV / COMPONENT MODE A. Picture：(Bold: Default) a. Picture Mode (Custom/Standard/Movie /Game / Custom) b. Backlight (0~100, 90) c. Brightness (0~100, 50) d. Contrast (0~100, 50) e. Color (saturation)(0~100, 50) f. Tint (hue) (-32~32, 0) g. Sharpness (0~7, 4) h. Color Temperature (Cool/Normal/Warm/Custom) i.
  • Page 19 B. Audio：(Bold: Default) a. Volume (0~100, 25) b. Bass (0~100, 50) c. Treble (0~100, 50) d. Balance (-50~50, 0) e. Surround (ON/OFF) f. Digital Audio Out (PCM/OFF/Dolby Digital) g. Speakers (ON/OFF) h. Lip Sync (0~5) CONFIDENTIAL DO NOT COPY Page 3-11 –...
  • Page 20 C. Setup：(Bold: Default) a. Language (English/ Français / Espaňol) b. Sleep Timer (OFF/30Min/60Min/90Min/120Min) c. Wide (Wide/Normal) d. Input Naming (AV1/AV2/COMP1/COMP2/HDMI1/HDMI2) e. CC(OFF/CC1-4) f. CC On Mute (OFF/ON) g. H/V Position h. Reset All Setting (OK/Cancel) CONFIDENTIAL DO NOT COPY Page 3-12 –...
  • Page 21 D. Parental：(Bold: Default) Password (Default => 0000) a. Cannel Block b. TV Rating c. Move Rating d. Block Unrated TV (NO/Yes) e. Access Code Edit CONFIDENTIAL DO NOT COPY Page 3-13 – File No. SG-0241...

  • Page 22: Hdmi Mode

    HDMI MODE A. Picture：(Bold: Default) a. Picture Mode (Custom/Movie/Game/Standard Custom) b. Backlight (0~100, 90) c. Brightness (0~100, 50) d. Contrast (0~100, 50) e. Color (saturation)(0~100, 50) f. Tint (hue) (-32~32, 0) g. Sharpness (0~7, 4) h. Color Temperature (Cool/Normal/Warm/Custom) i. Advanced Video 1.
  • Page 23 B. Audio：(Bold: Default) a. Volume (0~100, 25) b. Bass (0~100, 50) c. Treble (0~100, 50) d. Balance (-50~50, 0) e. Surround (ON/OFF) f. Digital Audio Out g. Speakers (ON/OFF) h. Lin Sync (0~5 , 0) CONFIDENTIAL DO NOT COPY Page 3-15 –...
  • Page 24 C. Setup：(Bold: Default) a. Language (English/ Français / Espaňol) b. Sleep Timer (OFF/30Min/60Min/90Min/120Min) g. Rest All Setting (OK/Cancel) CONFIDENTIAL DO NOT COPY Page 3-16 – File No. SG-0241...
  • Page 25 [INPUT] “INPUT” could supply an interface providing a list. The list shows input sources and provides the choices of different sources. The list includes items as below: A. TV: Analog TV or digital TV B. AV1, AV2: Composite (AV) signal C.
  • Page 26 Chapter 9 Trouble shooting MONITOR DISPLAY NOTHING (PC MODE) Start Is Power board output +5VSB (F1)? Is J1 connector of MB good? LED is lighted Is DC-DC OK? (Orange green) Is U22 pin2 (+3V3SB) working ok? It is in power saving 1.
  • Page 27 (TV, COMPOSITE VIDEO1, 2, S-VIDEO) IS NOT DISPLAY CORRECTLY Start 1. Check video Input signal good? 2. Check DVD player 1. Check P2 & J4 signal 2. Check signal between P2 and U13 (IF AV1/AV2 mode) U13 input correct? 3. Check Tuner & U13 (IF TV mode) 4.
  • Page 28 (COMPONENT1, 2) IS NOT DISPLAY CORRECTLY Start 1. Check video Input signal good? 2. Check host’s setting 1. Check signal from P3 & P4 P3 input correct? 2. Check system power 12V& 5V(5VSB) 1. Check signal between U13 & P3 2.
  • Page 29 HDMI ) IS NOT DISPLAY CORRECTLY Start 1. Check video Input signal 2. Check host’s setting 1. Check P7 & P9 connect U13 no data out ? 2. Check the pin18 & 19 of P7 & P9 3. Check the pin 6 of U32 & U34 1.Is J9 connected good? 2.Is panel working ok? CONFIDENTIAL...
  • Page 30 TROUBLE OF DC-DC CONVERTER Start The voltage is about + 5V(+5VSB) 1. Check power board J1 PIN9,PIN10,PIN11 2. Check power cable, F1 & connection J1 3. Check U22 pin1 (+5VSB) & pin2 (+3V3SB) The voltage is about + 12V while power switch on 1.
