Altronix NetWay112 Installation Manual page 4

Unit should be tested at least once a year for the proper operation as follows:
While the NetWay112 is powered and the output is connected to a suitable UL Listed PoE device.
The NetWay112 should be tested for PoE shutdown operation (For Information Technology applications only).
For Access Control applications, the NetWay1SP is to be tested as part of a complete Access Control System and in
accordance with listed Access Control Devices.
Refer to NetWay112 Port Status and LED Flash Codes pg. 2.
Parameter
No. of Ports
Input power requirements
Indicators
PoE Shutdown Voltage
and Current Range
Environmental Conditions
Regulatory Compliance
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IINetWay112
- 4 -
Maintenance:
Troubleshooting:
Technical Specifications:
Description
One (1).
12VDC @ 1.6 amp.
Port Status LED.
5VDC to 24VDC or 12VAC to 24VAC.
Maximum current: 2mA for 5VDC.
Maximum current for higher voltages: 10mA.
Operating Ambient Temperature: Information Technology - 32ºF to 104ºF (0ºC to 40ºC).
Relative humidity: 85%, +/ ---5%.
Storage Temperature: ---4º to 158ºF (---20º to 70ºC) Storage.
Operating Altitude: --- 1000 to 10,000 ft. (--- 304.8 to 3048m).
CE approved
L07L
Access Control - 32ºF to 120.2ºF (0ºC to 49ºC).
MEMBER
NetWay112
