Summary of Contents for Suim P-154E

  • Page 1 P-154E Power Amplifier...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.

  • Page 3: Front Panel

    PRECAUTIONS 1. When first powering-up the amp, keep the amplifier gain controls all the way off, in order to prevent from being potentially damaged and from producing annoyed sounds caused by defective cables or hookups. When turning up gain control, do it gradually, until normal operation is verified. These precautions are necessary with all high- power amplifiers, since they have enough power to blow most speakers in abnormal situations.

  • Page 4: Slave Mode

    CONVENTION OF INPUTS AND OUTPUTS 1 / 4" phone jacks inputs wired The XLR inputs wired speakon outputs wired APPLICATION 1. SLAVE MODE MIXER SLAVE MODE...

  • Page 5: Master Mode

    1. MASTER MODE MIXER MASTER MODE SPECIFICATION Output 150 W x 4CH Output 250 W x 4CH 4 Ohms 1 kHz 0.5% THD 250W 8 Ohms 1 kHz 0.5% THD 150W Signal to Noise Ratio unweighted 20-20kHz -98dB Damping Factor >200 @ 8 Ohms Frequency Response 20Hz~20kHz...
