Amcrest AMC1080BC and AMC1080DM HDCVI Camera's
User's Manual
Version 1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMC1080BC and is the answer not in the manual?

Questions and answers

Related Manuals for Amcrest AMC1080BC

Summary of Contents for Amcrest AMC1080BC

  • Page 1 Amcrest AMC1080BC and AMC1080DM HDCVI Camera’s User's Manual Version 1.0.0...

  • Page 2: Table Of Contents

    Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Specifications ........................ 1 Framework and Dimensions ..................... 3 AMC1080BC ......................... 3 AMC1080DM ......................... 4 Installation............................ 5 AMC1080BC ......................... 5 AMC1080DM ......................... 6 Menu ............................. 8 HDCVI Series DVR Settings ..................8...
  • Page 3 Welcome Thank you for purchasing our Amcrest HDCVI camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
  • Page 4 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC (24V AC) in the IEC60950-1. We assume no liability or responsibility for any fires or electrical shock caused by improper handling or installation.
  • Page 5 Please shut down the device and then unplug the power cable before you begin daily maintenance work. Use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.

  • Page 6: General Introduction

    1.3 Specifications Model Megapixel HDCVI Mini 2 Megapixel HDCVI Mini IR Dome Waterproof Fixed Camera Series Camera Series Parameter AMC1080BC AMC1080DM Video Processor 1/2.9" 2.0 Mega Pixels CMOS Video Format PAL/NTSC Effective Pixel 1984（H）× 1105（V） Min Illumination 0.005Lux@(F1.2,AGC ON), 0Lux with IR...
  • Page 7 Sync Mode Video Output 1-channel HDCVI high definition video output White Balance Auto Gain Control Auto Auto IR Light Control Plan Advanced non-photosensor control plan Transmission Over 300m for 720P and 500m for 1080P via 75-3 coaxial cable. Distance Smart IR Support Max IR Distance Protection Level...

  • Page 8: Framework And Dimensions

    2 Framework and Dimensions Please refer to the following figures for dimension information. The unit is mm. See Figure 2-1 to Figure 2- 2.1 AMC1080BC Figure 2-1 Figure 2-2 Please refer to the following sheet for detailed information. Name Function Lens This is to receive the optical signal from the environment.

  • Page 9: Amc1080Dm

    2.2 AMC1080DM Please refer to the following figures for dimension information. The unit is mm. Figure 2-3 Figure 2-4 When the standard definition/high definition switch control cable is short circuited, the system outputs standard definition video. Otherwise, when the circuit is open, system outputs the high definition video.

  • Page 10: Installation

    Before the installation, please make sure the installation surface can sustain at least 3X the weight of the bracket and the camera. 3.1 AMC1080BC Step 1 Drill three holes in the installation surface of the wall or the ceiling. Insert three expansion bolts to the three holes and then lock firmly.

  • Page 11: Amc1080Dm

    Step 4 Connect the device video output port to the terminal device such as the DVR, NVS, etc. Then connect the power cable to the device. 3.2 AMC1080DM Step1 Device Installation Take the wrench from the accessories bag and use it to loosen the three set screws on the side of the camera body.
  • Page 12 Figure 3-5 Step 4 Fix Monitor Angle To prevent the dome from moving, use wrench to secure the three set screws to secure the monitor angle position.

  • Page 13: Menu

    4 Menu 4.1 HDCVI Series DVR Settings Note The following operation and interfaces are for reference only. Please refer to the HDCVI series DVR user’s manual for detailed information. After connecting the camera to the HDCVI series DVR, from Main Menu->Setting->System->PTZ, you need to set the control mode as HDCVI and the protocol as DH-CVI.
  • Page 14 Click the Iris to open menu or confirm current operation. Click up/down button to view all the items on the left pane of the following list. Click left/right button to set the corresponding values on the right pane of the following list. If there is “ ”, click the confirm button to go to the 2nd menu.

  • Page 15: Appendix Toxic Or Hazardous Materials Or Elements

    Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component Device ○ ○ ○ ○ ○ ○ Construction Material ○ ○ ○ ○ ○...
