Split Air Conditioner
Thank you for selecting LENNOX air conditioners.Please read this manual
carefully before operation and keep it for further reference.
OWNER'S MANUAL
LENNOX A I R C O N D I T I O N E R S
M O D E L :
LM018CI-100P232-1X
LM018CO-100P232-1X
LM024CI-100P232-1X
LM024CO-100P232-1X
LM018HI-100P232-1X
LM018HO-100P232-1X
LM024HI-100P232-1X
LM024HO-100P232-1X
LM009CI-100P232-1
LM009CO-100P232-1
Advertisement
Table of Contents
Related Manuals for Lennox LM018CI-100P232-1X
Summary of Contents for Lennox LM018CI-100P232-1X
- Page 1 Split Air Conditioner OWNER'S MANUAL LENNOX A I R C O N D I T I O N E R S M O D E L : LM018CI-100P232-1X LM018CO-100P232-1X LM024CI-100P232-1X LM024CO-100P232-1X LM018HI-100P232-1X LM018HO-100P232-1X LM024HI-100P232-1X LM024HO-100P232-1X LM009CI-100P232-1 LM009CO-100P232-1 Thank you for selecting LENNOX air conditioners.Please read this manual...
-
Page 2: Table Of Contents
Content Operation Notices Precautions......................1 Parts Name......................7 ScreenOperation Guide Buttons on remote controller .................9 Introduction for icons on display screen ...............9 Introduction for buttons on remote controller ............10 Function introduction for combination buttons .............13 Operation guide ....................14 Replacement of batteries in remote controller .............14 Emergency operation .................. -
Page 3: Precautions
Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 Precautions WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
- Page 5 Precautions WARNING Attachment Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
- Page 6 Precautions WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
- Page 7 Precautions WARNING For the air conditioner with plug, the plug should be reachable after finishing installation. For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.
- Page 8 Precautions For LM018CI-100P232-1X, LM018CO-100P232-1X, LM018HI-100P232-1X LM018HO-100P232-1X,LM024CI-100P232-1X, LM024CO-100P232-1X LM024HI-100P232-1X, LM024HO-100P232-1X Indoor side DB/WB(℃ ) Outdoor side DB/WB(℃ ) Maximum cooling 32/23 48/30 Maximum heating 27/- 24/18 NOTICE: ● The operating temperature range (outdoor temperature) for cooling only unit is 18℃ ~ 48℃ ; for heat pump unit is -7℃ ~ 48℃ .
-
Page 9: Parts Name
Parts Name Indoor Unit air inlet panel aux.button horizontal louver air outlet (Display content or position may be di fferent from above remote control graphics, please refer to actual products) Outdoor Unit air inlet Connection wire air outlet NOTICE: Actual product may be different from above graphics, please refer to actual products. - Page 10 Parts Name Display For some model: For some model: temp. cooling power receiver indicator indicator indicator window heating indicator display cooling indicator receiver power heating temp. drying window indicator display indicator indicator indicator drying indicator For some model: display temp. indicator Power LED color indicator: Green-status-ON.
-
Page 11: Buttons On Remote Controller
Buttons on remote controller ON/OFF button ▲ button MODE button SWING button button FAN button TIMER OFF button CLOCK button TIMER ON button SLEEP button TEMP button TURBO button X-FAN button I FEEL button button Introduction for icons on display screen Set fan speed I feel Send signal... -
Page 12: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: ● After putting through the power, the air conditioner will give out a sound. Operation indictor " " is ON (red indicator). After that, you can operate the air conditioner by using remote controller. ●... - Page 13 Introduction for buttons on remote controller FAN button This button is used for setting Fan Speed in the sequence that goes from AUTO, , to , then back to Auto. Auto Low speed Medium speed High speed TIMER OFF button Press this button to initiate the auto-off timer.
- Page 14 Introduction for buttons on remote controller unit displays set temperature; When selecting " " with remote controller, temperature indicator on indoor unit displays indoor ambient temperature; 3s later or within 3s it receives other remote controller signal that will return to display the setting temperature. Caution: This model hasn't outdoor ambient temperature display function.
-
Page 15: Function Introduction For Combination Buttons
