Hyundai Tucson Quick Reference Manual

TUCSON CUSTOMER DELIVERY CHECKLIST (continued)
TIRE PRESSURE MONITORING SYSTEM
(TPMS) – page 30
Explain TPMS function to customer.
- When illuminated, one or more
tires are under-inflated.
- Blinks for approximately one minute
then remains illuminated when there
is a malfunction with the TPMS.
CLOCK ADJUSTMENT – page 28
- With Radio Off
1. Press and hold SETUP
button w.
2. Rotate knob q to adjust
HOUR. Press knob q to enter.
3. Rotate knob q to adjust
MINUTE. Press knob q to enter.
VEHICLE SETTINGS – pages 12-13
- Demonstrate vehicle settings
in instrument cluster
- Demonstrate navigation use,
enter dealer address
- Show radio presets
BLUETOOTH – pages 20-23
- Demonstrate phone pairing
Refer to www.hyundaiusa.com/bluetooth
- Demonstrate QR code
Sales Consultant Date Sales Manager
Customer
@
Email
MAINTENANCE
Scheduled Maintenance
Engine Oil and Filter
Tire Rotation
Air Cleaner Filter
Vacuum Hose
Climate Control Air Filter
(for Evaporator and Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Electronic Throttle Control
Front Disc Brake/Pads, Calipers & Rotors
Propeller Shaft (AWD)
q
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Brake/Clutch Fluid
q
Crankcase Ventilation Hose
Fuel Filter
Fuel Lines, Fuel Hoses and Connections
Fuel Tank Air Filter
Rear Disc Brake/Pads, Parking Brake
Vapor Hose, Fuel Tank & Fuel Filler Cap
Manual Transaxle Fluid
Rear Axle Oil (AWD)
Transfer Case Oil (AWD)
Valve Clearance
Drive Belt (Alt, A/C)
Spark Plugs (Iridium Coated)
Coolant
Automatic Transaxle Fluid
*See Owner's Manual for details.
Looking for more detailed information?
Owner's Manual. If you require additional information or are unsure of a specific issue, you should always
refer to the vehicle's Owner's Manual or contact your authorized Hyundai dealer.
Date
The information contained in this Quick Reference Guide was correct at the time of printing; however,
specifications and equipment can change without notice. No warranty or guarantee is being extended in
this Quick Reference Guide, and Hyundai reserves the right to change product specifications and
Date
equipment at any time without incurring obligations. Some vehicles are shown with optional equipment.
Specifications apply to U.S. vehicles only. Please contact your Hyundai dealer for current vehicle
specifications.
Normal Usage Severe Usage*
Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Perform 7,500 Perform 7,500
Inspect 7,500 Inspect Same As Normal
Replace 30,000 Replace More Frequently
Inspect 7,500 Inspect Same As Normal
Replace 15,000 Replace More Frequently
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect 7,500
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect 7,500
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect More Frequently
Inspect 30,000 Inspect Same As Normal
Inspect 37,500 Replace 75,000
Inspect 37,500 Replace 75,000
Inspect 37,500 Replace 75,000
Inspect 60,000 Inspect Same As Normal
1st Inspect 60,000 or 48 mos.
Inspect Same As Normal
Add. Inspect 15,000 or 12 mos.
Replace 105,000 Replace More Frequently
1st Replace 120,000 or 120 mos.
Replace Same As Normal
Add. Replace 30,000 or 24 mos.
No check, No service required Replace 60,000
This Quick Reference Guide does not replace your vehicle's
NP150-T02013
(Rev 10/08/12)
Printing 10/10/12
TUCSON
HYUNDAI
Quick Reference Guide
