Specifications

Power supply : AC 220V-240V
Power consumption : 26 W (approx. 2 W in power save mode)
DVD
Recording format DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format, MP3, JPEG, DivX
DVD-R DL: DVD-Video format
DVD-RW: DVD-Video format, DVD Video Recording format
+R, +RW, +R DL
Recording discs DVD-RAM: Ver.2.0, Ver.2.1 /3X Rev.1.0,
Playback discs
DVD-R:
DVD-R DL: Ver.3.0, DL Ver.3.x/4X Rev.1.0
DVD-RW: Ver.1.1, Ver.1.x /2X Rev.1.0,
DVD+R:
DVD+R DL: Ver.1.0
DVD+RW: Ver.1.1, Ver.1.2/4X
Playback discs DVD-Video, DVD-Audio, CD-Audio (CD-DA), Video-CD,
CD-R/RW (CD-DA, Video CD, SVCD, MP3/JPEG/DivX
formatted discs), SVCD that are IEC62107-compliant
LASER specification LASER product of class 1
Wave length: 662 nm for DVD, 780 nm for CD
Laser output: No dangerous radiation due to the safety device.
Norsk: Bølgelengde: 662 nm (DVD), 780 nm (CD)
Laserstyrke: Ingen farlig stråling sendes ut.
Optical pick-up: System with 1 lens, 2 integration units
Other Regional code: 2
DV input IEEE 1394 Standard (4-pin)
TV system PAL: 625/50 / SECAM (input only) NTSC: 525/60
Video interface
Input Input impedance: 75 Ohm.
AV1 SCART Video: 1 Vp-p
AV2 SCART Video: 1 Vp-p, Y: 1 Vp-p C: 0.3 Vp-p (PAL-Burst),
AV3 VIDEO Video: 1 Vp-p
AV3 S VIDEO Y: 1 Vp-p, C: 0,3 Vp-p (PAL-Burst)
Output For 75 Ohm termination.
AV1 SCART Video: 1 Vp-p; RGB: 0,7 Vp-p (625/50) only DVD
AV2 SCART Video: 1 Vp-p
VIDEO Video: 1 Vp-p
S VIDEO Y: 1 Vp-p, C: 0,3 Vp-p (PAL-Burst)
COMPONENTVIDEO OUT Y: 1 Vp-p, P : 0,7 Vp-p, P : 0,7 Vp-p (PAL: 625i/625p, NTSC: 525i/525p)
Audio interface
Recording System: Dolby Digital 2ch
Input Input impedance: more than 10 kOhm.
AV1 SCART Standard: 0.5 Vrms, full scale: 2 Vrms at 1 kHz
AV2 SCART Standard: 0.5 Vrms, full scale: 2 Vrms at 1 kHz
AV3 AUDIO Standard: 0.5 Vrms, full scale: 2 Vrms at 1 kHz
Output The output impedance of each output socket is less
than 1 kOhm.
AV1 SCART Standard: 0.5 Vrms, full scale: 2 Vrms at 1 kHz
AV2 SCART Standard: 0.5 Vrms, full scale: 2 Vrms at 1 kHz
AUDIO Standard: 0.5 Vrms, full scale: 2 Vrms ar 1 kHz
OPTICAL Optical connection (PCM, Dolby Digital, DTS, MPEG)
Tuner An integrated tuner (for both DVD and VCR)
Tuner system PAL-BGH, SECAM-BG
Channel area VHF: CH E2-E12 A-H2 (Italy), UHF: CH 21-69
CATV: S01-S05 (S1-S3), S1-S20 (M1-U10), S21-S41
Quick Start for Recording (Quick Start: [On])
1 sec Quick Start for Recording on DVD-RAM (when connecting to TV using SCART, Component Video, Video or S-Video terminals)
From power off mode, recording on DVD-RAM starts about 1 sec after first pressing
Note:The values given for weight and dimension are approximate values. Specifications can change without notice.
50 Hz
Ver.2.2 /5X Rev.2.0
for General
Ver.2.0, Ver.2.0 /4X Rev.1.0,
Ver.2.x /8X Rev.3.0,
Ver.2.x/16X Rev.6.0
Ver.1.x /4X Rev.2.0, Ver.1.x/6X Rev.3.0
Ver.1.0, Ver.1.1, Ver.1.2, Ver.1.3
B R
Dimensions : approx. 430 mm (W) x 84 mm (H) x 351 mm (D)
Weight :
Operating temperature :
Operating humidity :
VHS
Recording format VHS video cassette system standard with FM audio
(PAL, MESECAM, NTSC, )
Video and sound heads 4 rotating video heads, 2 rotating Hi-Fi heads
1 fixed head for normal audio
Recording mode PAL/MESECAM: SP: 23.39 mm/s 240 min.
Recording time
NTSC:
Video Data
Horizontal Resolution SP: more than 240 lines
Signal to Noise Ratio SP: more than 43 dB, LP: more than 40 dB,
EP: more than 38 dB
Frequency Response SP, LP: 0 ±2 dB at 2 MHz (0 dB at 0.1 MHz),
EP: 0 ±3 dB at 2 MHz (0 dB at 0.1 MHz)
Audio Data
Dynamic Range HiFi:
Frequency Response HiFi:
Normal: SP: 80 Hz-8 kHz (-1 ±5 dB)
Signal-to-noise ratio HiFi:
Normal:SP: more than 43 dB, LP, EP: more than 41 dB
Cross talk more than 50 dB at 1 kHz (HiFi)
Wow and Flutter HiFi:
Normal:
TV system PAL/SECAM: 625/50
Standby/On and then sequentially pressing
approx. 5.4 kg
5°C - 40°C
35% - 80% RH (no condensation)
LP: 11.7 mm/s 480 min.
EP: 7.8 mm/s 720 min.
SP: 33.35 mm/s 168 min.
EP: 11.12 mm/s 505 min.
(for E-240 cassettes)
more than 90 dB (Cinch)
20 Hz-20 kHz (0 ±3 dB)
LP: 80 Hz-5 kHz (0 ±5 dB)
EP: 80 Hz-3 kHz (0 ±5 dB)
more than 65 dB
Less than 0.005 Wrms
SP: 0.2% max. LP, EP: 0.4% max.
NTSC: 525/60
REC .
