Mac Mini Model A1347 Teardown
© 2010 iFixit — CC BY-NC-SA
Step 20
The bare logic board.
The brains of the unit feature:
Intel P8600 2.4 GHz Core 2 Duo
NVIDIA GeForce 320M
256MB of shared DDR3 SDRAM
Other notable chips include:
Broadcom BCM57765
and memory card reader controller
Cirrus 4206ACNZ audio controller
Delta LFE9249-R
Step 21
The Mac Mini comes with either a 320GB or 500GB
SATA hard drive.
Sadly, there's only one hard drive in our non-server
model.
Need more storage? Only time will tell if this Mac Mini
is as easily modified
recommend just getting the server edition.
www.iFixit.com
processor
graphics processor with
integrated gigabit ethernet
discrete LAN filter
as its predecessor. For now, we
