Summary of Contents for DWG FE5403
- Page 1 Panoramic Fisheye IP Camera Quick Installation Guide 8608595330000...
-
Page 2: Table Of Contents
Please follow the installation below steps to set up Panoramic Fisheye IP Camera. Check the package contents against the list below.See P.1 Physical overview.See P.2 I/O Terminal Block Circuit. See P.3 I/O Terminal Block Pin Definition. See P.3 LED Indicator Definition. See P.4 Power mode. -
Page 3: Physical Overview.see
Physical overview Top cover Ethernet Socket External I/O connector DC 12V/1A Routing hole Lens MicroSD/SDHC Reset Power LED Indicator Network LED Indicator... -
Page 4: I/O Terminal Block Circuit. See
I/O Terminal Block Circuit I/O Terminal Block Pin Definition This Camera provides a 6pin cable for external I/O which is used to connect input/ output devices.The pin definitions are described below. Definition Description Max. V/A Black Ground 12V DC Brown + 12V DC 1.2W Audio... -
Page 5: Led Indicator Definition. See
LED Indicator Definition Color Indication Network Blue Flash blue while Network activity. Steady red for booting up process Blue Steady blue for booting up completion Power Flash purple during firmware upgrading; when reset button Purple pressed for at least 5 sec. to factory default Unlit When you press reset button;... - Page 6 B. Wall mount L-type Bracket installation(optional) 1. Position the L-type at the desired installation location. Drill two holes into the placement and hammer the included screw anchors. 2. Align the two holes on the L-type bracket to the two plastic anchors on the wall or ceiling, insert the supplied screws to the corresponding hole and fix them.
- Page 7 C. Wall mounting and Ceiling mounting 1. Attached the alignment sticker to the wall/ceiling. Drill three holes into the wall, which two for screws and one for cable. 2. Hammer the supplied plastic anchors into the holes. 3. Align the two holes on the base of camera with the two plastic anchors on the wall or ceiling, insert the supplied screws to the corresponding hole and screw them.
-
Page 8: Microsoft Os: Use The Software Cd To Install Intelligent Ip Installer.see
D. Wall mounting and Ceiling mounting f1. Without Power over Ethernet (PoE) connection 1. Connect the power adaptor to the IP Camera. 2. Connect the IP Camera to a normal Hub / Switch / Router. f2. Power over Ethernet (PoE) 1. - Page 9 Access the IP Camera using Intelligent IP Installer 1. Please check two settings before using Intelligent IP Installer . a. Browser’s Internet Properties → b. Browser’s Internet Properties → Privacy→ Uncheck Pop-up Blocker Security 2. Click the Intelligent IP Installer Icon on your desktop. The main page will show up listing all active camera and video server devices.
- Page 10 4. When accessing the IP Camera for the first time, a yellow information bar appears below the address bar: This website wants to install the following add-on: ‘AxvideoView.cab’. 5. Click the information bar, and select Install ActiveX control. 6. Click Install. 7.
- Page 11 Mac OS using Safari Browser 2. Click Bonjour function and select 1. Select Safari icon the camera you wish to access. 3. Enter name and password to 4. The monitor image will be login to the IP camera. (Default is displayed in your browser.
- Page 12 Change the Web Interface into your preferred language Use the settings screen to set the language of the Web Interface. Go to “System >Maintenance> Language”. 1. Go website http://www.champsolution.com/DownloadMainpage.php download language pack. 3. The web interface Browse and select the preferred language and then click OK. will change into your preferred language.
