Specifications

Recordable discs:
DVD-RAM:
Ver. 2.0
Ver. 2.1/3X–SPEED DVD-RAM Revision 1.0
Ver. 2.2/5X–SPEED DVD-RAM Revision 2.0
DVD-R:
For General Ver. 2.0
For General Ver. 2.0/4X–SPEED DVD-R Revision 1.0
For General Ver. 2.x/8X–SPEED DVD-R Revision 3.0
For General Ver. 2.x/16X–SPEED DVD-R Revision 6.0
For DL Ver. 3.0
For DL Ver. 3.x/4X–SPEED DVD-R for DL Revision 1.0
DVD-RW:
Ver. 1.1
Ver. 1.x/2X–SPEED DVD-RW Revision 1.0
Ver. 1.x/4X–SPEED DVD-RW Revision 2.0
Ver. 1.x/6X–SPEED DVD-RW Revision 3.0
+R:
Ver. 1.0
Ver. 1.1
Ver. 1.2
Ver. 1.3
For DL Ver. 1.0
+RW:
Ver. 1.1
Ver. 1.2/4X–SPEED
Recording system:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time:
Max. 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour
LP: Approx. 4 hours
Playable discs:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format, DVD Video Recording format
+R +R DL (Double Layer)
+RW DVD-Video
DVD-Audio CD-Audio (CD-DA)
Video CD CD-R/CD-RW (CD-DA, Video CD, MP3, JPEG)
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specification
Class I LASER Product
Wave length:
Laser power:
Television system
TV system:
Antenna reception
input:
RF converter output: Not provided
The model number and serial number of this product can be found
on either the back or the bottom of the unit.
Please note them in the space provided below and keep for future
reference.
MODEL NUMBER
SERIAL NUMBER
RQT8327
54
SP: Approx. 2 hours
EP: Approx. 6 hours or 8 hours
780 nm (CDs)
662 nm (DVDs)
No hazardous radiation is emitted with the
safety protection
NTSC system, 525 lines, 60 fields
TV Channel: 2 ch–69 ch
CATV Channel: 1 ch–125 ch
DMR-ES25
Video system
Recording system:
MPEG2 (Hybrid VBR)
Input:
LINE (pin jack) ×2,
S connector ×2
Output:
LINE (pin jack) ×1,
S connector ×1
Component video
Y, P
output:
(480i/480p)
Audio system
Recording system: Dolby Digital (2ch)
Analog Input: LINE (pin jack) ×2
Reference input: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Input impedance: 47 kΩ
Analog Output:
LINE (pin jack) ×1
Reference output: 309 mVrms
FS: 2 Vrms (1 kHz, 0 dB)
Output impedance: 1 kΩ
(Load impedance: 10 kΩ)
Number of channels: Recording: 2 channels
Playback: 2 channels
Digital Output: Digital audio optical output connector
×1
(PCM, Dolby Digital, DTS)
HDMI Output: (19 pin type A) ×1
HDMI Ver. 1.2a (EDID Ver. 1.3)
SD Card Slot:
Still Picture (JPEG, TIFF) SD Memory Card Slot
Compatible media: SD Memory Card*, Multi Media Card
* Includes miniSD™ cards. (A
Format:
FAT12, FAT16
Image file format:
JPEG conforming to DCF (Design
rule for Camera File system)
TIFF (Uncompressed RGB chunky),
DPOF Compatible
Sub sampling; 4:2:2 or 4:2:0
Number of pixels: between 34 × 34 and 6144 × 4096
pixels
Thawing time: Approx. 3 sec (6 M pixels, JPEG)
DV Input:
Regional Code:
Clock unit: Quartz-controlled 12-hour digital display
Operating temperature range:
Operating humidity range:
Power supply:
Power consumption:
Dimensions (W × H × D): Approx. 430 mm × 58 mm × 248 mm
Mass:
Power consumption in standby mode:
approx. 2.1 W (Shipping condition)
approx. 6.1 W (User setting: Quick Start: On)
Note
Specifications are subject to change without notice.
Mass and dimensions are approximate.
User memo:
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
1.0 Vp-p; 75 Ω
1.0 Vp-p; 75 Ω
Y:
C: 0.286 Vp-p; 75 Ω
1.0 Vp-p; 75 Ω
1.0 Vp-p; 75 Ω
Y:
C: 0.286 Vp-p; 75 Ω
1.0 Vp-p; 75 Ω
, P ×1 Y:
B R
0.7 Vp-p; 75 Ω
P :
B
0.7 Vp-p; 75 Ω
P :
R
miniSD™ adaptor needs to be
inserted.)
IEEE 1394 Standard, 4 Pin: 1 pc
5 °C to 40 °C (41 °F to 104 °F)
10 % to 80 % RH (no condensation)
AC 120 V, 60 Hz
Approx. 21 W
15 " × 2 5 " × 9 13
(Approx. 16 / /
16 16
Approx. 2.8 kg (6.16 lbs)
1 pc
