Comrex ACCESS 2USB Quick Start Manual

Quickstart Guide
ACCESS 2USB Portable Diagrams and Descriptions
1) Backlight Key - Controls operation of the display
light. Hold for one second to enable Power Saving
Mode, where LCD lighting will turn off after ten
seconds of non-use. Press the key to turn on light for
another ten seconds. Hold for one second to enter
Toggle Mode, where presses will turn light on/off.
Hold for one second to return to default Always On
Mode.
2) Directional Cursors & Enter Key - May be used
instead of touch-screen to navigate and select
options in the User Interface.
Figure 1 – Front Panel Diagram
1
2
4
3) Power Key - Hold this button down for one
second to turn the ACCESS 2USB on or off.
4) F1 Key - Used to access the top menu bar.
5) F2 Key - This is user programmable; refer to the
User Interface section in the product manual for
details.
6) Battery - Clip on Lithium-Ion battery pack.
3
5
6
