Page 1: Quick Installation Guide
APC Mach 5 V3 Quick Installation Guide Revision 1.5 28 January 2014 Copyright © 2014 Deliberant www.deliberant.com Product size and shape are subject to change without notice, and actual product appearance may differ from that depicted in the user guide... -
Page 3: Copyright
This user’s guide and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Deliberant. Notice Deliberant reserves the right to change specifications without prior notice. -
Page 4: Table Of Contents
APC Mach 5 V3 Mounting ......................... 10 Mounting on a Pole ........................10 Mounting on a Wall ........................11 ACCESS THE APC MACH 5 V3 ......................13 Connection via WEB Browser ......................13 Resetting to Factory Defaults ......................14 DECLARATION OF CONFORMITY ....................15... -
Page 5: Introduction
Parliament and the Council of 9 March 1999 on Radio Equipment and Telecommunication Terminal Equipment and the Mutual Recognition of their Conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000. deliberant Page 5... -
Page 6: Safety
However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this manual and of the computer manufacturer must therefore be allowed at all times to ensure the safe use of the equipment. EU Countries Not Intended for Use None. deliberant Page 6... -
Page 7: About This Guide
File names, directory names, form names, system-generated output, and user typed entries are displayed in constant-width type Technical Support If you encounter problems when installing or using this product, please consult the Deliberant website at www.deliberant.com for: Direct contact to the Deliberant support centers. -
Page 8: Installation
Quick Installation Guide Installation Installation This chapter provides installation instructions for the hardware components of the APC Mach 5 V3. Package Contents The figure below displays APC Mach 5 V3 package contents: Figure 1 –APC Mach 5 V3 Package Contents... -
Page 9: Hardware Introduction
Quick Installation Guide Installation Hardware Introduction The APC unit is housed in an aluminum enclosure. The panel of the APC Mach 5 V3 unit contains: Integrated antenna Data/Power connection in the form of passive PoE through standard Ethernet cable ... -
Page 10: Leds
LEDs The APC Mach 5 V3 has 6 LEDs located on the side panel: power, LAN and 4 RSSI LEDs (refer at the Figure 2 – General View of the APC Mach 5 V3 Unit for details). The various states of the LEDs... -
Page 11: Mounting On A Wall
The mounting bolts for unit installation on the wall are not included in the package. For mounting APC Mach 5 V3 unit on the wall, first mount one half of the bracket to the wall and then connect the two halves of the bracket together and tighten the nut and bolt. - Page 12 Quick Installation Guide Installation Step 4. Attach the following part of the mounting bracket to the APC Mach 5 V3 unit with 4 screws as displayed below: Step 5 Attach the second part of the mounting bracket to the wall using screws (not included)
-
Page 13: Access The Apc Mach 5 V3
Access the APC Mach 5 V3 The first connection to the APC Mach 5 V3 can be made using a standard Ethernet cable connected directly to your PC. See next sections for the instructions on how to access the APC Mach 5 V3 management interfaces. -
Page 14: Resetting To Factory Defaults
Resetting to Factory Defaults APC Mach 5 V3 has the capability of being reset to defaults by pinging the device with a certain packet size when the device is booting. During the startup of the device, when the drivers of the ethernet interfaces are loaded, the reset program is started. -
Page 15: Declaration Of Conformity
Par la présente Deliberant déclare que l'appareil Deliberant APC Mach 5 V3, est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Par la présente, Deliberant déclare que ce Deliberant APC Mach 5 V3 , est conforme aux exigences essentielles et aux autres dispositions de la directive 1999/5/CE qui lui sont applicables.
