Hetis H61 Series Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Hetis H61 Series
Personal Computer
MS-B025 System
G52-B0251X7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H61 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hetis H61 Series

  • Page 1 Hetis H61 Series Personal Computer MS-B025 System G52-B0251X7...

  • Page 2: Getting Started

    Service Manual Getting Started Important All information is subject to change without prior notice. How to Use this Service Manual  This Service Manual is targeted for MSI-authorized dealer or service center. It provides in-depth illustration of disassembling the system. Each topic may be related with each other;...

  • Page 3: Other Notice

    Hetis H61 Series ■ Do not drop or jolt the system. ■ Do not bump or knock the LCD screen as it is fragile and could break. ■ Do not use another power adapter other than the one enclosed with the system.

  • Page 4: System Disassembly

    Service Manual System Disassembly Cover  Step 1. Place the system horizon- tally on a flat and steady surface. Step 2. Unlock the two screws on the rear panel and then remove the cover care- fully. Keep the screws and the cover for later use. Step .

  • Page 5: Optical Disk Drive (Odd)

    Hetis H61 Series Optical Disk Drive (ODD)  Step 1. Locate the ODD set and the screw on the front panel that secure it. Unlock the screw and keep it for later use. Step 2. Disconnect the ODD power cord and signal cable.
  • Page 6 Service Manual Step . Pull the lock bracket outwards on both sides to release the ODD. Step 5. Remove the ODD carefully from the cage and set it aside for later use. Follow the above procedures in reverse order to replace the ODD if necessary.

  • Page 7: Hard Disk Drive (Hdd)

    Hetis H61 Series Hard Disk Drive (HDD)  Step 1. Locate the HDD set and disconnect the HDD power cord and signal cable. Step 2. Pull the HDD set forwards to release it from the chassis. Step . Unlock the four screws on both sides of the HDD set.

  • Page 8: Central Processing Unit (Cpu)

    Service Manual Central Processing Unit (CPU)  Step 1. Locate the cooler set and the screws that secure it. Step 2. Disconnect the its power cord. Step . Unlock the four screws to release the cooler set from the mainboard.
  • Page 9 Hetis H61 Series Step . Remove the cooler set care- fully to uncover the CPU. Set the cooler set aside for later use. Step 5. Locate the CPU socket. Step 6. Open the load lever and lift it up.
  • Page 10 Service Manual Step . Open the load plate. Step . Remove the CPU carefully from the socket and set it aside for later use. Follow the above procedures in reverse order to replace the CPU if necessary.
  • Page 11 Hetis H61 Series Memory  Step 1. Locate the memory slots. Step 2. Flip the slot clips outwards and the memory will spring up- wards instantly. Step . To avoid damaging the golden finger, remove the memory carefully at the same angle it was inserted.

  • Page 12: Cmos Battery

    Service Manual CMOS Battery  NOTE: Make sure that you write down the CMOS settings before removing the CMOS battery. Step 1. Locate the CMOS battery. Step 2. Flip the clip and the CMOS battery will spring upwards instantly. Follow the above procedures in reverse order to replace the CMOS battery if necessary.
  • Page 13 Hetis H61 Series Stand  Step 1. Lift up the system and put the rubber feet into the pits on the stand. Step 2. Make sure the rubber feet fit the stand properly. Vertical Type Horizontal Type Important We suggest you to install the stand if you would like to place your system on the desk...
