PVG R 25X-TC series Operating Manual

Hide thumbs Also See for R 25X-TC series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
3
2
6
5
IN
4
>
u
1
:
=
y
R 25x-TC*
MANUEL D'UTILISATION
GEBRAUCHSANWEISUNG
BRUGSANVISNING
INSTRUCCIONES DE USO
KÄYTTÖOHJE
OPERATING MANUAL
ISTRUZIONI D'USO
BRUKSANVISNING
GEBRUIKSAANWIJZING
INSTRUKCJI OBS?UGI
BRUKSANVISNING
NAVODILA ZA UPORABO
2
14
26
38
50
62
74
86
98
110
122
134

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R 25X-TC series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PVG R 25X-TC series

Summary of Contents for PVG R 25X-TC series

  • Page 1 R 25x-TC* MANUEL D'UTILISATION GEBRAUCHSANWEISUNG BRUGSANVISNING INSTRUCCIONES DE USO KÄYTTÖOHJE OPERATING MANUAL ISTRUZIONI D’USO > BRUKSANVISNING GEBRUIKSAANWIJZING INSTRUKCJI OBS?UGI BRUKSANVISNING NAVODILA ZA UPORABO...
  • Page 2 This appliance comes with a 24-month manufacturer’s warranty on all defects in material or workmanship. We wish you much warmth and comfort from your heater. Yours sincerely, PVG Holding b.v. Customer Service Department 1 READ THE DIRECTIONS FOR USE FIRST. 2 IN CASE OF ANY DOUBT, CONTACT YOUR DEALER.

  • Page 3: General Directions For Use

    GENERAL DIRECTIONS FOR USE MAIN COMPONENTS Below you will find the main steps to be taken for using your heater. For more details, please refer to ³ OFF - button the MANUAL (pages 65 ff.). · Knurled wick adjustment knob Remove all packaging materials (refer to Section A, Fig.

  • Page 4: Safety System

    WHAT YOU NEED TO KNOW IN ADVANCE ALWAYS MAKE SURE THAT THERE IS SUFFICIENT VENTILATION Read this user manual carefully before using the appliance and keep it for future reference. Install this device only when it complies with local/national legislation, ordinances and standards.

  • Page 5: The Right Fuel

    THE RIGHT FUEL Your heater has been designed for use with high-quality water-free pure paraffin oil, such as Zibro Extra or Zibro Kristal. Only fuels of this kind will ensure clean and proper burning. Lower quality fuel may result in: excessive tar deposits on the glass fibre wick incomplete burning reduced heater lifetime...

  • Page 6: Filling Fuel

    Put the combustion chamber back into its place. The combustion chamber is positioned correctly when it can be smoothly moved a little to the left and to the right by its handle ´ (Fig. F). Close the grill: Slightly lift it to reposition it in its slot.

  • Page 7: Switching Off The Heater

    IGNITING THE HEATER A new heater may give off some smells for a short while, when it is used for the first time. You should therefore provide extra ventilation or ignite the heater out- side the living room. When you use the heater for the first time, first put the filled removable tank into place, and then wait approximately 30 minutes before you ignite the heater.

  • Page 8: Malfunction, Causes And Solutions

    MALFUNCTION, CAUSES AND SOLUTIONS If any malfunctioning cannot be solved from the directions below, please contact your dealer. THE HEATER DOES NOT IGNITE The batteries are not positioned correctly in the holder. Check (Fig. G). There is not enough power left in the batteries for the ignition. Replace (Fig.

  • Page 9: Maintenance

    MAINTENANCE Your heater needs hardly any maintenance. It is, however, important that you remove dust and stains in time with a damp cloth, because otherwise these may cause stains that are hard to remove. Under normal conditions, only three components are subject to wear: 1.

  • Page 10: Warranty Provisions

    TRANSPORTATION Take the following measures to avoid fuel leakage during the transportation of the heater: Let the heater cool down. Remove the removable tank ¾ from the heater and remove the fuel filter (Fig. O). Some drops may leak from the filter; keep a cloth at hand. Store the fuel filter and the removable tank outside the heater.

  • Page 11: Tips For Safe Use

    The warranty will not apply to damages caused by actions not in compliance with the Directions for Use, neglect, and the use of an incorrect type of fuel, or fuel past its use-by date. The use of incorrect fuel can even be dangerous*. Transportation costs and the risks involved during the transportation of the heater or heater components will always be the responsibility of the purchaser.
  • Page 12 REPLACEMENT OF THE WICK ENSURE THAT THE HEATER IS OFF AND COMPLETELY COOL BEFORE STARTING TO REPLACE THE WICK. Open the lid and remove the removable tank. Remove the batteries from the battery holder. Open the front grill. Remove the combustion chamber from the heater.
  • Page 13 Install the wick to the wick sleeve according to the allowed direction engraved on the wick sleeve. Install the wick sleeve (with wick) to the primary air tube. And then turn the wick sleeve clockwise to set in the handle arm. Install the bracket.
  • Page 14 1-3 cm.
  • Page 15 *R 25x-TC: Heator R 251 TC Stover R 252 TC Tectro R 253 TC Toyoheater R 254 TC Toyoset R 255 TC Toyostove R 256 TC Webber R 257 TC Royalheater R 258 TC Sous réserve de modification Ändrungen vorbehalten Ændringer forbeholdes ¾...
  • Page 16 Printed in Japan Rev. 7/11 7963000903...
