Summary of Contents for BeiJer iX Panel T4A
- Page 1 Panel T4A Installation Manual English MAEN015A, 2011-05...
- Page 2 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB reserves the right to change any information without updating this publication. Beijer Electronics AB assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Autoflex EB ............14 5 Operator Panel Drawings ..........15 Communication Ports ........... 15 iX Panel T4A Outline ..........16 6 Additional Installation Tips ..........17 Grounding the Operator Panel ......... 17 Ethernet Connection in the Panel ...... -
Page 4: Safety Precautions
Separate the high voltage, signal and supply cables. • Make sure that the voltage and polarity of the power source is correct before • connecting the product to the power outlet. Peripheral equipment must be appropriate for the application and location. • Beijer Electronics, MAEN015A... -
Page 5: During Use
Dismantling and Scrapping The operator panel or parts thereof shall be recycled according to local • regulations. The following components contain substances that might be hazardous • to health and the environment: lithium battery, electrolytic capacitor and display. Beijer Electronics, MAEN015A... -
Page 6: Installation
Space requirements when installing the operator panel: • 100 mm 104 mm 50 mm 50 mm 100 mm 100 mm 43 mm 145 mm Caution: The openings on the enclosure are for air convection. Do not cover these openings. Beijer Electronics, MAEN015A... -
Page 7: Installation Process
2. Use the cut out dimensions that are included on the outline drawing to cut a correct opening in the cabinet. A separate cut out drawing is available for download from the Beijer Electronics web site. 3. Secure the operator panel in position, using all the fastening holes and the provided brackets and screws: 0.5 - 1.0... - Page 8 When connecting the operator panel to the power outlet for the first time, make sure not to interrupt power for a minimum of 48 hours in order to charge the battery completely. After that, the battery may be charged partly during a shorter period of time. Beijer Electronics, MAEN015A...
-
Page 9: Connections To The Controller
file for the driver in question. 2.2.2 Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Beijer Electronics, MAEN015A... -
Page 10: Technical Data
Technical Data Technical Data Parameter iX Panel T4A Front panel, W x H x D 145 x 103 x 7 mm Mounting depth 43 mm (143 mm including clearance) Standalone mounting VESA 50x50 Note: Maximum screw length for VESA mounting is 4 mm. - Page 11 Technical Data Parameter iX Panel T4A Storage temperature -20 ° to +85 °C (depending on display) Relative humidity <95 % non-condensed Approvals and Information is available on the web site certifications www.beijerelectronics.com * See section Chemical Resistance for more information.
-
Page 12: Chemical Resistance
The powder paint shows little or no resistance to the following chemicals at room temperature: Acetic acid, conc. Methyl-ethyl ketone Toluene Acetone Nitric acid 30% Trichlorethylene Ammonia 5% Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octan unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octan leaded petrol Beijer Electronics, MAEN015A... -
Page 13: Touch Screen And Overlay
Autotex withstands DIN 42 115 Part 2 exposure of up to 1 hour duration to glacial acetic acid without visible change. Autotex is not resistant to high pressure steam at over 100 °C or the following chemicals: Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Methylene chloride Beijer Electronics, MAEN015A... -
Page 14: Touch Screen Surface
4.2.3 Autoflex EB It is recommended to use the Autoflex EB touch display protection film, that can be ordered from Beijer Electronics. Solvent Resistance Autoflex EB withstands exposure to the same chemicals as Autotex F157 or F207 according to section Autotex F157/207. -
Page 15: Operator Panel Drawings
RS485 TX+/RX+ RS485 TX+/RX+ RS232 RX RS232 RX RS232 TX RS232 TX RS422 RX+ RS422 RX+ RS422 TX- / RS422 TX- / RS485 TX-/RX- RS485 TX-/RX- RS232 RTS RS422 RTS+ RS232 CTS RS422 RTS- RS422 RX- RS422 RX- Beijer Electronics, MAEN015A... -
Page 16: Ix Panel T4A Outline
Operator Panel Drawings iX Panel T4A Outline SD memory USB host max 11 mm card slot material thickness Beijer Electronics, MAEN015A... -
Page 17: Additional Installation Tips
Multi-wire conductors are better than single wire conductors with the same area. A braided conductor wire with the same area is even better. The best is a short, thick grounding braid. Beijer Electronics, MAEN015A... -
Page 18: Ethernet Connection In The Panel
A more elegant method is to expand the shielded Ethernet cabling with a piece of unshielded Ethernet cable, see 4 in drawing above. You can ground the shield via an external 0.1 uF/250 V plastic capacitor, see 5 in drawing above. This will connect the HF transients to the ground. Beijer Electronics, MAEN015A... -
Page 19: To Achieve Better Emc Protection
Additional Installation Tips To Achieve Better EMC Protection Initially, use the original cabling from Beijer Electronics primarily. • Use shielded cables for RS232 communication. • Use twisted pair and shielded cabling for RS422 and RS485. • Use the cabling intended for the bus type; Ethernet, Profibus, CC-Link, •... -
Page 20: Ambient Temperature
The loss effect drops from e.g. 25 W to only 5 W. The operator panel’s loss effect = supply voltage x current. Virtually no power goes to external users and no loss effects due to inputs. Beijer Electronics, MAEN015A... -
Page 21: Safety
Transients on the 24 V feed are connected to the ground. • No risk that the 24 V feed is at a high level in relationship to the ground. This • is not unusual since there is high static electricity. Beijer Electronics, MAEN015A... -
Page 22: Galvanic Isolation
24 V feed, disturbances and grounding currents from the 0 V on the 24 V side will disrupt communication. Using this type of unit solves one problem but creates a larger problem! A substandard installation may work now, but problems may arise when other devices are connected. Beijer Electronics, MAEN015A... -
Page 23: Cable And Bus Termination Rs485
Set jumper pins 6-19. Use CAB8. It offers the option of bus termination with pull-up/-down. It • is also easy to connect the bus cable via the screw terminal block. See 4 in drawing above. Beijer Electronics, MAEN015A... - Page 24 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
