ELEV-8 ASSEMBLY GUIDE

Disclaimer of liability:

Parallax Inc. is not responsible for any special, incidental, or consequential damages and personal injuries,

including that to life and health, resulting from the customer's application and use of any Parallax Inc.

products. You, the customer, assume full and unlimited responsibility for all customer ELEV-8 Quadcopter

applications and uses.

Table of Contents

Need help?

Do you have a question about the ELEV-8 and is the answer not in the manual?

Page 1 Parallax Inc. is not responsible for any special, incidental, or consequential damages and personal injuries, including that to life and health, resulting from the customer’s application and use of any Parallax Inc. products. You, the customer, assume full and unlimited responsibility for all customer ELEV-8 Quadcopter...
Page 2 This document is intended to be a guide during the assembly of an ELEV-8 Quadcopter. It is not a step by step walk-through of how to assemble the platform. In this document you will find specific instructions on how to assemble components that should be followed. These will help to decrease your potential for catastrophic failure of your ELEV-8.
Page 3 Sport board plate, ensure that it is oriented with the “Front” side pointing towards the front of your ELEV-8. Also, ensure that the Light Tube hole on top of the Control Board Top Plate(4) is directly above the LED on your Sport Board. This will ensure that when you place your Light Tube(7) into the Top...
Page 4 Figure 1 Transmitter parameter settings. Parameter Setting End point adjustment 100% for “+” and “-“ sides Dual-Rates (D/R) 100% Channel Reverse Normal – HiTec, Spektrum, JR Reversed - Futaba Trims Centered Sub Trims Centered Exponential After experienced add up to 30% into aileron and elevator...
Page 5 Figure 2 CW- Clock Wise CCW- Counter Clock Wise...
