Berkefeld TWA 6 Operating Instructions Manual

Hide thumbs

Advertisement

Quick Links

I
Description TWA 6
II
Standard dosing plan
"Berkefeld EMERGENCY EXERCISE and ACTION (full) SDP"
III
Short operating instructions TWA 6
IV
Operating instructions TWA 6
V
Trouble-shooting
VI
Maintenance work and repair work
VII
Operating instructions and spare parts lists for aggregates
VIII
Loading list, loading plan
Operating instructions TWA 6
Please keep for future use!
Contents

Advertisement

loading
Need help?

Need help?

Do you have a question about the TWA 6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Berkefeld TWA 6

  • Page 1 Operating instructions TWA 6 Please keep for future use! Contents Description TWA 6 Standard dosing plan “Berkefeld EMERGENCY EXERCISE and ACTION (full) SDP“ Short operating instructions TWA 6 Operating instructions TWA 6 Trouble-shooting Maintenance work and repair work Operating instructions and spare parts lists for aggregates...
  • Page 2 KE) is fed to the precoat filter by the precoat pump. By the following pre-treated raw water stream the filter material is precoated to the special Berkefeld filter candles located in the precoat filter, and there it forms the filtering layer. Flow direction in the precoat filter is upwards (see attachment 6).
  • Page 3 Standard dosing plan “Berkefeld EMERGENCY EXERCISE and ACTION (full) SDP“ 1. The Berkefeld SDP is used in case of disaster abroad with unknown waters and - in reduced extent - for exercises. 2. The EMERGENCY EXERCISE SDP is used with extremely strongly polluted, unknown waters or in case of chemical disasters.
  • Page 4 Filling the raw water pump with raw water and installation of a raw water tankincl. all suction and delivery hoses. Prepare the required chemicals for the TWA 6 per 8 m tank. Dissolve chlorine acc. To the corresponding dosing plan in approx. 10 litres ofwater and fill into the tank with the first water.

  • Page 5: Table Of Contents

    Operating instructions for Berkefeld drinking water purifier TWA 6 Capacity 6 m Contents IV 1. Colour of hoses and pumps IV 1.1. Installation, pumps, hoses, raw water tank IV 1.2. Operation/pretreatment unit IV 1.3. Precoat filter IV 1.3.1. Pure water tank and pure water distributor IV 1.3.2.

  • Page 6: 1. Colour Of Hoses And Pumps

    IV 1. Colour of hoses and pumps All hoses and pumps are coloured. All red hoses and pumps are raw water conducting plant components and may only be coupled with this colour marking. All white hoses and pumps are pure water conducting plant parts and may only be coupled with this colour marking.

  • Page 7: 1.2 Operation/Pretreatment Unit

    Install the raw water pump as close to the intake place as possible. Connect one or two raw water suction hoses with strainer, protective basket and plastic float with chain on suction side. Secure the suction valve and hoses with an arrester cable. Hang the raw water inflow pipe into the first raw water tank and connect it to the raw water pump with a corresponding number of raw water pressure hoses.

  • Page 8: 1.3 Precoat Filter

    IV 1.3 Precoat filter The precoat pump has to be connected with the four-way suction valve. A raw water suction hose has to be connected from the raw water collector to the four-way suction valve (C-Storz). The precoat hose which is 2 m long and which is equipped with one Storz coupling D only has to be connected to the four-way suction valve.

  • Page 9: 1.3.2 Operation Of The Precoat Filter

    supporting ring and the cover has to be laid on the bracing (see annex 1). Brace the cover with the cords at the supports of the supporting ring. Pay attention to utmost cleanliness at the pure water tank. Attention Then on suction side the pure water pump is coupled with a pure water suction hose and a gate valve to the pure water tank (Storz C).

  • Page 10: 1.3.3. Backwash Of The Filter Plant

    The deaerators have to be opened from time to time, so that entered air can escape. After approx. 5-7 min. circuit operation the 3-way tap is brought to position „filtration“ again. The first water (approx. 30 sec.) should be used for rinsing of the pure water pipes. Only hereafter the pure water inflow pipe is put in the pure water tank.
  • Page 11 valve and ball valve are closed, the pressure manometer on precoat filter side shows approx. 3 - 4 bar. The ball valve at the sludge outflow hose is opened suddenly and remains open for approx. 5 sec., then close slowly. This process must be repeated 6 times.
  • Page 12 IV 1.4. Operating instructions chemical displacement dosator LC 9 Berkefeld drinking water purifier TWA Contents IV 1.4.1. Purpose of the unit IV 1.4.2. Working method IV 1.4.3. Addition of chemicals in proportion to the water supply IV 1.4.4. Preparation of chemical solution IV 1.4.5.
  • Page 13 The unit is used for dosing of water treatment chemicals in mobile drinking water purifiers. Installation can be carried out preceding or after a Berkefeld precoat filter plant by coupling the unit with the connections between 2 hoses. Dosing is carried out continuously into the treated pure water.
  • Page 14 IV 1.4.3. Chemical addition in proportion to the water supply The quantity of the chlorine added is determined by the corresponding responsible man in each single case. If no instruction has been given, we recommend to adjust chlorination of the water having a chlorine excess of 0.5 - 1 mg Cl The following mentioned common chlorinous chemicals are used: 1.
  • Page 15 IV 1.4.4. Preparation of the chemical solution Wear protection clothes! Attention When preparing the solution, 9 l pure water and the chlorine media (corresponding to the concentration) in the following mentioned quantities have to be stirred well. Chlorine bleaching solution 12 % 450 g Chloramin...
  • Page 16 8. Control function of the dosing unit at the control valve and overflow pipe If the outflow for filling of a tanker has been elevated, the dosing quantity has to be changed. Re-adjustment at control valve is absolutely necessary. If no pure water is given and the filter plant is switched to circuit, the control valve and gate valve have to be closed or the quick-coupling has to be separated respectively.
  • Page 17 IV 1.4.7. L E A F L E T “Chlorine Definitions“ „Effective chlorine“ (total chlorine) The sum of the elementary chlorine (free effective chlorine), available in the water at the point of time of analysis and its sterilizing acting compounds (bound effective chlorine) is called „effective chlorine“...
  • Page 18 The quantity flow rate meter has to be controlled continuously during operation of the precoat filter. Should - for any reason - the precoat filter suck air or should the precoat pump fail, one would recognize this at the float of the flow rate meter and one could switch the 3-way tap to „circuit“, so that the pure water cannot be polluted.
  • Page 19 IV 1.7. I M P O R T A N T N O T E S If the first pre-treatment tank is pumped-off, one has to change-over to the second one in time. This is carried out by opening the ball valve at the raw water collector of tank 2 and only after that the ball valve of tank 1 is closed.
  • Page 20 V Trouble shooting Trouble Reason Remedy Electr. pump or motor Pump not deaerated Deaerate pump by filling up pump does not prime water with water Precoat pump does not prime water in Main ball valve of the 4-way suction Open corresponding ball spite of deaeration device is closed valves...
  • Page 21 Maintenance work and repair work TWA 6 During operation of the plant the following work has to be carried out hourly: 1. When operating combustion-engined pumps: Refill fuel. 2. Controlling the differential pressure at the precoat filter. 3. Preparing the chemicals acc. to the standard dosing plant.
  • Page 22 Operating instructions and spare parts lists of aggregates General operating instructions for Berkefeld pumps Filled with water/surface water, this portable multi-purpose pump is self-priming and determined for lifting of contaminated water and sludge water. Due to its size and its weight it is especially intended as transportable multi-purpose pump, but it can also be used as stationary pump for continuous operation.
  • Page 23 Four-stroke fuel motor Pump with four-stroke motor not to be installed with an inclination of more than 15°. Otherwise a lack of lubrication may occur. Check oil level. Starting With cold motor, adjust lever to CHOKE; with warm motor to RUN up to ¼ direction to CHOKE.
  • Page 24 Repair instructions Dismantling Drain the pump by opening the screw plug (13). Release the screws for fastening the motor on the sledge and detach the motor together with the pump from the sledge. Release the screws for connection of the pump casing (11) with the pump cover (1).
  • Page 25 VIII Loading list, packing list accessories, tools list, loading plan Loading list TWA 6 standard Item Q’ty Part No. Description Remark 01.00 104 534 Transport box 600x400x410 compl. packed in this: 104 155 Bags of activated carbon (2.5 kg) 02.00...
  • Page 26 20.00 40 500 807 barring ring support 21.00 1 105 130 transport trestle for barring rings 22.00 1 500 832 Filter group TWA 6 compl. 23.00 1 510 432 Dosing plant TWA 6 compl. 24.00 3 109 213 Centrifugal pumps NP-4-DH diesel 25.00 1...
  • Page 27 As at 04/2002 Page 3 Packing list accessories/spare parts TWA 6 Packed in transport box 800x600x410 (part No. 510 254) Item Q’ty Part No. Description Remark 01.00 3 104 316 Stirring paddle 500 lg. 02.00 2 104 399 Marking tape 03.00 4...
  • Page 28 As at 04/2002 Page 4 Item Q’ty Part No. Description Remark 15.00 1 105 814 Hazardous goods case compl. consisting of: 167 338 Case 109 968 Respiratory half mask 119 354 Fine dust mask 110 041 Apron 105 526 Safety glasses 123 625 Eye rinsing bottle 123 623...
  • Page 29 As at 04/2002 Page 5 Item Q’ty Part No. Description Remark 31.00 1 104 317 Measuring beaker 32.00 1 500 669 Flow meter dosator 33.00 1 104 537 Spare glass with ball for flow meter dosator 34.00 1 100 818 O-ring 22x6 -„- 35.00 1...
  • Page 30 As at 04/2002 Page 6 Tools list TWA standard Part No. 500 716 (in rolling bag 104 644) Item Q’ty Part No. Description Remark 01.00 1 500 771 Double-ended open-jawed spanner set 8-piece consisting of: 105 362 Double-ended open-jawed spanner SW 8x9 mm 105 363 Double-ended open-jawed spanner SW 10x11mm 105 364...
  • Page 31 Berkefeld Standard Dosing Plan for raw water pretreatment Process step Additive Formula Q'ty to be added SDP EMERGENCY EX FULL SDP Reaction time 100 g/m 180 g/m 360 g/m Oxidation, alkaline HTH chlorine (C8) Ca(OCl) filling time + 10 min...
  • Page 32 S T E R L I N G Check list drinking water treatment plant in operation Berkefeld Place of operation: ................................Date: ......Meteorological conditions ....:........Air temperature: ....... Vegetation at the riverside and variety of species: .....................….. Assistants: ..................Filter vehicle: ......Trailer: ....
  • Page 33 Precoating Filter aid Basic precoating (g)/time Secondary precoating (g)/time Total quantity (g) Berkesil - KE Berkesil - KE Remarks: ..............................................…………………………..Appliance After precoating Remarks, e.g. reason for backwash precoating precoating precoating Filter capacity in m Filter loss of head (bar) Pump pressure (bar) Operation time/day (h) Total capacity/day (m...
  • Page 34 The total hardness of the water is composed of calcium and magnesium salts. The carbonate hardness consists of hydrogen carbonate (HCO Total hardness (TH) = carbonate hardness (CH) + non-carbonate hardness (NCH). A common measuring unit in Germany is 1 mval/l = 2,8 °dH (German hardness). French and English hardness degrees are measured as well.
  • Page 35 Analysis of drinking water quality Designation Unit Limit value TVO Limit value WHO Sensory parameters Colour (SAK-436nm) Turbidity TE/F 01-May Physical parameters Temperature °C n. g. Electr. conductivity (referred to 25 °C) mS/m pH-value at 10 °C 6.5 - 9.5 <...
  • Page 36 Designation Unit Limit value TVO Limit value WHO Bacteriological parameters Koloniezahl 20 °C per 1 ml Koloniezahl 36 °C per 1 ml Coliform bacteria per 100 ml Escherichia-coli (2) per 100 ml Faecal streptococci (2) per 100 ml Hardness graduation Hardness grade Water hardness Designation...
  • Page 37 Conversion factors for analysis results Formerly usual details Old unit of New unit of New designation measurement measurement Colour (platinum) 1 mg/l 0,025 m colouring, abs. coeff. HG 436 nm 40 mg/l UV extinction 1 cm 100 m UV abs. coeff. HG 254 nm 0,01 cm Electr.
  • Page 38 Table of weights TWA plants TWA 1 TWA 2 TWA 3 TWA 6 TWA 10 Single Single Single Single Single weight Total weight weight Total weight weight Total weight weight Total weight weight Total weight Filter group 161.0 kg 161.0 kg 160.0 kg...
  • Page 39 Explanation friction losses in pipes Shall water be pumped over a longer distance, the table located in the plant can be used. If a water flow of 10 m /h shall be pumped over a distance of 1000 m, using a pipe with an inside diameter of 50 mm, this means a loss of 5.25 m WC per 100 m.
  • Page 40 The pressure head losses ∆ h apply to medium-rough pipes (k=00.1 mm). With new, smooth pipes (k=0.05 mm) they have to be multiplied by 0.9; with very rough pipes (k=0.5 mm) which have been in operation for a longer time with 1.4. Berkefeld-Filter Anlagenbau GmbH, Lückenweg 5, D-29227 Celle, Phone: (0 51 41) 803-0, Fax: 803-100...
  • Page 41 29227 Celle Telefax : (+49) 05141 / 803-100 Germany Ansprechpartner: Labor ; Telefon: 117 Product : Berkefeld Aktivkohle Product use : Composition / Information on ingredients All components contained in this product are included in the EINECS/ELINCS-inventory Chemical name :...
  • Page 42 SAFETY DATA SHEET (93/112/EC) Berkefeld Aktivkohle Hazardous decomposition products : , CO Accidental Release Measures Protective equipment See section : 8. " Exposure controls/ Personal protection " Small spills : Sweep up for disposal or recovery. Collect the spill in a suitable container. Flush the area with plenty of water.
  • Page 43 SAFETY DATA SHEET (93/112/EC) Berkefeld Aktivkohle Conditions to avoid : Unknown Materials to avoid : metal salts, strong oxidizing materials Hazardous decomposition products at None normal use : Toxicological Information Acute toxicity Oral LD (rat) : > 5000 mg/kg. Dermal LD (rabbit) : No specific test data available.
  • Page 44 SAFETY DATA SHEET (93/112/EC) Berkefeld Aktivkohle Important notice: This data sheet is a supplement to the technical instructions but does not replace them. The data are given in good faith based on information derived from our knowledge of the product at the date of issue of this document. Each user is reponsible to determine that the product is suitable for the user's intended application and that such usage complies with applicable legislative and administrative rules and guidelines.
  • Page 45 SAFETY DATA SHEET (93/112/EC) Identification of the product and company Berkefeld-Filter Lückenweg 5 Telephone (+49) 05141 / 803-0 29227 Celle Telefax : (+49) 05141 / 803-100 Germany Ansprechpartner: Labor ; Telefon: 117 Product : BerkeSIL KE Product use : Composition / Information on ingredients...
  • Page 46 SAFETY DATA SHEET (93/112/EC) BerkeSIL KE Hazardous decomposition products : , CO Accidental Release Measures Protective equipment See section : 8. " Exposure controls/ Personal protection " Small spills : Sweep up for disposal or recovery. Collect the spill in a suitable container. Flush the area with plenty of water.
  • Page 47 SAFETY DATA SHEET (93/112/EC) BerkeSIL KE Conditions to avoid : Unknown Materials to avoid : metal salts, strong oxidizing materials Hazardous decomposition products at None normal use : Toxicological Information Acute toxicity Oral LD (rat) : > 5000 mg/kg. Dermal LD (rabbit) : No specific test data available.
  • Page 48 SAFETY DATA SHEET (93/112/EC) BerkeSIL KE Important notice: This data sheet is a supplement to the technical instructions but does not replace them. The data are given in good faith based on information derived from our knowledge of the product at the date of issue of this document. Each user is reponsible to determine that the product is suitable for the user's intended application and that such usage complies with applicable legislative and administrative rules and guidelines.
  • Page 49 29227 Celle Telefax : (+49) 05141 / 803-100 Germany Ansprechpartner: Labor ; Telefon: 117 Product : Berkefeld Calciumhydroxid Product use : Composition / Information on ingredients All components contained in this product are included in the EINECS/ELINCS-inventory Chemical name :...
  • Page 50 SAFETY DATA SHEET (93/112/EC) Berkefeld Calciumhydroxid Explosion hazards : Not applicable Fire hazards : Not applicable Hazardous decomposition products : Accidental Release Measures Protective equipment See section : 8. " Exposure controls/ Personal protection " Small spills : Collect the spill in a suitable container. Flush the area with plenty of water.
  • Page 51 SAFETY DATA SHEET (93/112/EC) Berkefeld Calciumhydroxid Conditions to avoid : Unknown. Materials to avoid : nitrogen compounds ( Explosion hazards ) in the presence of Water: Reacts with most metals to release hydrogen gas which can form explosive mixtures with air Hazardous decomposition products at Unknown.
  • Page 52 SAFETY DATA SHEET (93/112/EC) Berkefeld Calciumhydroxid Safety phrases : S 1/2-22-24-26 Keep locked up and out of reach of children. Do not breathe dust. Avoid contact with skin. In case of contact with eyes, rinse immediately with plenty of water (at least 15 minutes) and...
  • Page 53 29227 Celle Telefax : (+49) 05141 / 803-100 Germany Ansprechpartner: Labor ; Telefon: 117 Product : Berkefeld Chlorgranulat Product use : Composition / Information on ingredients All components contained in this product are included in the EINECS/ELINCS-inventory Chemical name :...
  • Page 54 SAFETY DATA SHEET (93/112/EC) Berkefeld Chlorgranulat Ingestion : Rinse mouth. Feed bread soaked in milk, followed by olive oil or cooking oil. Do NOT induce vomiting. NEVER give anything by mouth to an unconscious person. Get medical attention immediately. Inhalation : Move person to fresh air.
  • Page 55 SAFETY DATA SHEET (93/112/EC) Berkefeld Chlorgranulat Physical and Chemical Properties (not to be taken as product specifications) Appearance : Granulate Colour : white Odour : Chlorine Boiling point : Not applicable. Freezing/melting point : 177 °C.(decomposition) Relative density (water = 1) : 2.3 kg/m...
  • Page 56 SAFETY DATA SHEET (93/112/EC) Berkefeld Chlorgranulat Transport Information UN-nr packing group : 2880 - II Road : ADR; class - item : 5.1 - 15b ADR Shipping name : CALCIUMHYPOCHLORITE, HYDRATED Sea : IMDG class : IMDG page : EmS / MFAG-table : 5.1 - 06...
  • Page 57 SAFETY DATA SHEET (93/112/EC) Berkefeld Chlorgranulat Other information Zur Desinfection von Schwimm- und Badebeckenwasser nach DIN 19643. Das Produkt ist kennzeichnungspflichtig nach der Gefahrstoffverordnung in der letztgültigen Fassung Calciumchlorit, Granulat hat einen akt. Chlorgehalt von ca. 70%. Chlorgranulat ist registriert unter UBA-Nr. 1973008...
  • Page 58 Telefax : (+49) 05141 / 803-100 Germany Ansprechpartner: Labor ; Telefon: 117 Product : Berkefeld Eisen-(III)-chlorid wasserfrei subl. techn. rein Product use : Composition / Information on ingredients All components contained in this product are included in the EINECS/ELINCS-inventory Chemical name :...
  • Page 59 SAFETY DATA SHEET (93/112/EC) Berkefeld Eisen-(III)-chlorid wasserfrei subl. techn. rein Explosion hazards : Not applicable. Fire hazards : Not applicable. Hazardous decomposition products : chlorine Accidental Release Measures Protective equipment See section : 8. " Exposure controls/ Personal protection "...
  • Page 60 SAFETY DATA SHEET (93/112/EC) Berkefeld Eisen-(III)-chlorid wasserfrei subl. techn. rein Stability and Reactivity Chemical stability : Stable. Hazardous polymerization : No polymerisation possible. Conditions to avoid : Excessive heat. Materials to avoid : strong alkalies, solution: Corrosive to metals. Hazardous decomposition products at...
  • Page 61 SAFETY DATA SHEET (93/112/EC) Berkefeld Eisen-(III)-chlorid wasserfrei subl. techn. rein Air : ICAO/IATA-DGR The IATA instruction is subject to annual revision. Contact your local supplier Regulatory Information EU-labeling requirements : HARMFUL (Xn) Risk phrases : R-22, 38, 41 Harmful if swallowed. Irritating to skin. Risk of serious damage to eyes.
