kincrome K10101 Owner's Manual
  1. Manuals
  2. Brands
  3. kincrome Manuals
  4. Inverter
  5. K10101
  6. Owner's manual

kincrome K10101 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Generator

Advertisement

loading
Need help?

Need help?

Do you have a question about the K10101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for kincrome K10101

  • Page 1 Generator...
  • Page 2 Selecting a Generator You must know the rated and maximum wattage for appliances to be used with a generator. Appliances with electric motors may require 2-3 times the rated power when starting up, e.g. an appliance with a rated output of 200W can draw up to 600W at start up.
  • Page 3 Petrol...
  • Page 4 Part 1 General Precautions 1.1 Work Area Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Generators create sparks which may ignite the dust or fumes.
  • Page 5 Double insulated tools are equipped with a polarized plug where one blade is wider than the other. This plug fits in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet.
  • Page 6 Damaged power cords increase the risk of electric shock. When operating a power tool outside, use an outdoor extension cord All connections and conduits from the generator to the load must only be installed by trained and licensed electricians, and in compliance with all relevant local, state, and federal electrical codes and standards, and other regulations where applicable.
  • Page 7 conductors with any part of the body, or with any non-insulated conductive object. Connect the generator only to a load or electrical system that is compatible with the electrical characteristics and rated capacities of the generator. Before servicing equipment powered by the generator, disconnect the equipment from its power input.
  • Page 8 1.3 Personal Safety Stay alert. Watch what you are doing, and use common sense when operating a generator. Do not use generator while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating generators may result in serious personal injury. Dress properly.
  • Page 9 balance at all times. Use safety equipment. Always wear eye protection. Wear approved safety impact eye goggles. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions. Do not force the generator. Use the generator correctly for your application.
  • Page 10 the generator. Such preventive safety measures reduce the risk of starting the generator accidentally. Store idle generators out of reach of children and other untrained persons. Generators are dangerous in the hands of untrained users. Maintain generators with care. Do not use damaged generator.
  • Page 11 1.5 Servicing Maintain labels and name plates on the generator and engine. These carry important information. If they are unreadable or missing, contact local dealers immediately for a replacement. Generator service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury.
  • Page 12 All electrical work, including the earth-ground connection, should be completed by a licensed electrician. Any separate fuel storage or generator supply facility must be built or installed in full compliance with all relevant local, state, and federal regulations.
  • Page 13 Part 2 PARTS AND COMPONENTS INTRODUCTION 1. fuel tank 8. air cleaner 9. pipe support 2. muffler 10. spark plug 3. Earth terminal 11. fuel tank cap 4. A.C plug/socket 12. AC.breaker 5. carburetor throttle valve 13. dipstick 6. starter handle 14.

  • Page 14: Part 3 Inspection Before Operation

    Part 3 INSPECTION BEFORE OPERATION 3.1 Machine oil level Always check the machine oil level after stopping generator on a level ground. 1. Turn out the oil filter cap and clean the dipstick with a clean cloth. 2. Insert the dipstick back into the filter hole without turning.
  • Page 15 3.2 Fuel level 1. Open the fuel tank cap. 2. Check the fuel oil level, and refill if necessary. 3. Refill up to the shoulder of the fuel filter. 4. Reinstall the fuel tank cap.
  • Page 16 3.3 Air cleaner 1. Remove the clip and dismantle the air cleaner housing or unscrew the nuts and air cleaner cover. 2. Unscrew the nut and washer, and dismantle the filter element for several times. 3. Dismantle the 4. Wash filter element.
  • Page 17 Part 4 STARTING OF GENERATOR cork...
  • Page 18 Tips and cautions for operating: 1. Do not start two or more appliances simultaneously. Start them one by one. 2. Warm up the engine without load for about 3 minutes. lf the generator is to supply power to more than one appliances, be sure to connect them one by one with higher current rated first.
  • Page 19 If the indication of voltmeter is too low or too high, stop the machine and examine it for cause of malfunction. The generator can load when the indicator of voltmeter show at 240V+10% (50 Hz) on the panel of control box. 4.
  • Page 20 This charging function cannot replace charging with a special battery charger! This device does not have a charging current regulator or an automatic shutdown when the battery is fully charged! Be sure to inform yourself about the design of your automotive battery, as well as its proper charging and maintenance! Contact a qualified specialist! Strictly adhere to the safety rules and instructions of the battery manufacturer!
  • Page 21 PART 5 STOPPING OF GENERATOR 1. Switch off the AC breaker. 2. Turn the generator switch to “off” position. 3. Set the fuel cork to “off” position. Note: To stop the generator in emergency. turn the generator switch to "off" position.

  • Page 22: Periodic Checks And Maintenance

    PART 6 PERIODIC CHECKS AND MAINTENANCE 6.1 Periodic checks and maintenance Periodic checks and maintenance are very important for keeping the engine in good condition and dependable. The generator consists of gasoline engine, alternator, control panel and frame, etc. Shut off the engine before performing any maintenance.
  • Page 23 Item Daily 20hrs or 50hrs or 100hrs or 300hrs or check first month every 3 every 6 every 1 months months year Oil filter clean Spark plug clean Valve Check/ clearance adjust Cylinder clean cover wash Fuel tank Wash if necessary, replace every 3 years. wash 6.2 Machine oil replacement 1.
  • Page 24 3. Screw on the drain plug. 4. Fill machine oil up to the upper level. 5. Reinstall the dipstick. Machine oil: 4 stroke petrol engine oil-SE, SF from API Service Classification or SAE 10W-30 equivalent to SG class. Low air temperature (below 10°C): recommended machine oil SAE10W-30...
  • Page 25 Frigid air temperature (below -15°C): SE, SF from API Service Classification or SAE10W-30 equivalent to SG class. Air cleaner (refer to page 8:Air cleaner) ■ ■ Spark plug 1. Dismantle the spark plug high-pressure cap. 2. Dismantle the spark plug. 3.
  • Page 26 4. Measure the electrodes clearance. 5. Reinstall the spark plug and high-pressure cap. 6.3 Fuel filter maintenance 1. Set the fuel cork to “off” position, and dismantle the fuel filter cup. 2. Clean the fuel filter cup thoroughly. 3. Mount a new rubber ring and the filter cup securely.
  • Page 27 6.4 Maintenance for long- term storage If the generator needs to be stored for a long time, the following preparation should be made: 1 .Screw off the fuel drain plug, and empty the fuel inside the carburetor. 2. Turn off the oil filter plug and oil drain plug, and empty the machine oil inside the crankcase.

  • Page 28: Troubleshooting Guide

    Part 7 TROUBLESHOOTING GUIDE PROBLEM CAUSE CORRECTION 1.Circuit breaker is 1.Reset circuit breaker. open. 2.Check and repair. Engine is 3.Connect another 2.Poor connection or running, but no device that is in good defective cord set. AC output is condition. 3.Connected device is available.
  • Page 29 PROBLEM CAUSE CORRECTION 1.Out of petrol. 1.Fill fuel tank. Engine shuts 2.Low oil level. 2.Fill crankcase to proper down during 3.Fault in engine. level. operation. 3.Contact Authorized Service Facility. 1.See “Don't Overload 1.Load is too high. 2.Dirty air filter. the Generator”. Engine lacks 3.Engine needs to be 2.Replace air filter.
  • Page 31 (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. Your rights under this warranty are in addition to any other rights you have under the Australian Consumer Law or other applicable laws.
