VPR Imprex VAPORE 3000 ASPIRA Manual

Hide thumbs

Advertisement

Table of Contents

IT IS RECOMMENDED TO CAREFULLY READ THE FOLLOWING MANUAL
TECHNICAL FEATURES
MODEL: VAPORE 3000 ASPIRA
MAXIMUM PRESSURE: 6,5 bar
POWER SUPPLY: SPECIFICATIONS WRITTEN ON THE MACHINE'S PLATE.
INSTALLED CAPACITY: 2,1 Kw
BASIC CONSTRUCTION MATERIAL: Stainless steel AISI 304 (boiler, heating elements, body)
AUTONOMY: UNLIMITED
VAPOR TEMPERATURE: 160°C / 320 F°
Vacuum Specifications
POWER: 1000 W
LOUDNESS: 72 decibels
VACUUM PRESSURE: 1900 mm. Of water
SOILED WATER TANK CAPACITY: 12 L /3.17 gallons
Note: The accessories, the technical and/or manufacturing and/or aesthetic features can vary at the
Manufacturer's final discretion and without notice.
CERTIFICATIONS
 Vapore 3000 ASPIRA is a CE/ETL Canada/USA certified product.
For service contact:
VPR Impex Inc.
3755 Hickmore
Ville St-Laurent, QC, Canada
H4T 1S5
(514) 733-2906
info@vprimpex.com
www.vprimpex.com
VAPORE 3000 ASPIRA
BEFORE USING THE MACHINE.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAPORE 3000 ASPIRA and is the answer not in the manual?

Questions and answers

Summary of Contents for VPR Imprex VAPORE 3000 ASPIRA

  • Page 1 SOILED WATER TANK CAPACITY: 12 L /3.17 gallons Note: The accessories, the technical and/or manufacturing and/or aesthetic features can vary at the Manufacturer’s final discretion and without notice. CERTIFICATIONS  Vapore 3000 ASPIRA is a CE/ETL Canada/USA certified product. For service contact: VPR Impex Inc. 3755 Hickmore...
  • Page 2 IMPORTANT SAFTETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE VAPOR CLEANING SYSTEM When using the Cleaning System, always use basic precaution, including the following: Warning- To reduce the risk of fire, electrical shock or injury: Do not leave appliance when plugged in. Unplug the Cleaning System from outlet when not in use, or before servicing.

  • Page 3: Section 1- Getting Started

    Fill the external tank (approx. 5 litres- 1,3 Us gallon ) with drinkable tap water and carefully reposition the cap with the probes inside the tank (refer to section 2.3) Connect VAPORE 3000 ASPIRA to a grounded power outlet. Make sure the power outlet can bear the machine power (look at the technical features on the machine).
  • Page 4 1.3 The Economy Function VAPORE 3000 ASPIRA can work in normal mode or in Economy mode. The Economizer switch allows the user to switch from normal function into Economy mode, and vice versa. The Economy function allows one of the heating elements to be deactivated, thus reducing the power absorbed by around 40%.
  • Page 5 VAPOR & VACUUM Figure 3- Standard acceccories included with this model ACCESSORY LIST- Vapor & Vacuum POS. DESCRIPTION CODE FRAME WITH BRISTLES mm 150 C2031 FRAME+SQUEEGEE mm 150 C2033 NOZZLE, VAPOR INTAKE mm 150 SMALL SIZE C2029 1” BRASS BRUSH VACUUM C1812 1"...

  • Page 6: Section 2- Using The Machine

    (refer to fig. 5). When the “OK” green light turns on, VAPORE 3000 ASPIRA is ready to generate vapor. However, after the initial heating, it is advisable to release the air in the system by pressing the trigger on the handle for a few seconds; when the “OK”...

  • Page 7: Section 3- Maintenance

    Ensure that the machine is disconnected from the power supply. Ensure that the boiler is not pressurised and that VAPORE 3000 ASPIRA has been turned off for at least 5 hours. Using the special wrench you have been provided with, unscrew the plug positioned under the machine.

  • Page 8: Section 4- Vacuum

    Fill the reservoir of the machine with water, turn main switch ON.  You can now choose to use VAPORE 3000 ASPIRA with vapor only or with vapor and vacuum: to generate vapor, press the trigger on the handle. ...

  • Page 9: Section 6- Warranty

    Be sure that product ONLY goes in the injection tank and NOT the water tank  The injection pump used for VAPORE 3000 ASPIRA is specifically designed to mix detergents, disinfectants and water. Its characteristics make it suitable not to damage the operator or other persons in the room in any way. Any other use is to be considered improper and therefore dangerous.
  • Page 10 Vapor is coming out from the safety valve (under the machine)  The safety valve has intervened. Contact an Authorised Service Centre. The machine does not reach the working pressure  Improper connection of the machine to a power supply. ...
  • Page 11 ATTENTION ! Be sure that extension tubes are properly locked Locked Unlocked Locked Unlocked For service contact: VPR Impex Inc. 3755 Hickmore Ville St-Laurent, QC, Canada H4T 1S5 (514) 733-2906 info@vprimpex.com www.vprimpex.com...
