Summary of Contents for ZYLUX Z-CARTV-HD-IQ

Page 1 Owner’s Manual...
Page 2 The lighting flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk at electric shock to persons. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK –...
Page 3 Precaution On Safety Installation or servicing of this in-car DVB-T receiver without the relevant training and / or experience in electronic equipment and automotive accessories may be dangerous and could expose you to the risk of electric shock or other hazards. If the in-car DVB-T receiver does not work properly, please contact your authorised dealer from where you purchased it for further technical support.
Page 4: Table Of Contents
Table of Contents Unit Description and Installation………………………………………………………………………5,6 I/O Ports / Wiring……………………………………………………………………………………………..7,8 Antenna Installation……………………………………………………………………………………………9 Remote Control features/functions…………………………………………………………………..10 Accessories Included…………………………………………………………………………………………11 1. Home Menu ..................12 1. Quick Guide for First-time User ............13 1.1. DVB-T TV Watching ...............13 1.2. DVB-T Radio Listening ............15 1.3. Record Function ..............16 1.4.
Page 5: Unit Description And Installation
Unit Description & Installation Guide Front Side (4) Reset (2) Operating (1) AV In (5) USB (3) Power (1) AV In (3.5 Φ earphone jack): audio/video signal input ports for external devices such as DVD, GPS, i-Pod, i-Phone, etc. (2) Operating: the “Operating” LED indicates if the system is working. (3) Power: the “Power”...
Page 6 Back Side (5) Power/IR port (4) Monitor Port (3) AV I/O port (1) Ant-in (2) TV Out (6) HDMI port (1) Ant. In: Antenna connection port (NOTE: this unit provides +5V antenna power through this connection port.) (2) TV Out: Connect the TV output ports (CVBS, Audio L, and Audio R) to monitor.
Page 7: I/O Ports / Wiring
I/O Ports Definition Power I/O Port Ground (black wire). Connect this cable to vehicles chassis ground. - Reverse status (orange wire). Connect this cable to reverse gear to see the image of rear view camera image on front monitor. - Keep the cable grounded if the reverse mode is not enabled. +12 ~ 24 V DC input (yellow wire).
Page 8 AV I/O Port Audio R input Audio L input External Audio ground AV Input Video ground Video input Video ground Video Video out for rear monitor Output Video out for rear monitor Monitor Port B output Video GND G output Component R output Video Out...
Page 9: Antenna Installation
Warning: Please connect the antennas before switching the unit on. If you turn the unit on before connecting the antennas, the receiver may not receive any signal. Antenna Connection DVB-T reception will vary from vehicle to vehicle and you may have to try several mounting positions to determine which position provides the strongest signal in your vehicle.
Page 10: Remote Control Features/Functions
Remote Control Operations Button name Function POWER Select power-on or stand-by MUTE Mute control SOURCE Select a video source from DTV/AV1/AV2 PREVIEW No function AUDIO Select second language and stereo audio ENTER To enter the selected channel number INFO Display digital TV system information Digital keys Digit buttons to select channels RECALL...
Page 11: Accessories Included
Accessories Basic: o Power Harness o Remote control o AV Harness o IR Receiver Module. o USB extension cable o 2 x Passive Antenna’s o iPhone Cable...
Page 12: Home Menu
1. Home Menu This is the home menu screen. You can highlight the DVB-T TV mode, the DVB-T Radio mode, the video playback mode, the music playback mode, the picture viewing mode and the system settings. Use [CH ] and [CH ] buttons to highlight the desired item and press [OK] button to select it.
Page 13: Quick Guide For First-Time User
1. Quick Guide for First-time User DVB-T TV Watching 1.1. Step 1: Turn on the unit 1. Turn on the vehicles ACC or IGN. (or start the vehicle) 2. When the unit has power, the POWER LED indicator will illuminate RED. 3.
Page 14 Step 3: Select your own OSD Language, your located region, whether it’s summer time at present. 1. Use [CH ]/[CH ] buttons to highlight the item. 2. Use [VOL ] button to set the highlight item. 3. Press [CH ]/[CH ] buttons to scroll up and down the options. 4.
Page 15: Dvb-T Radio Listening
DVB-T Radio Listening 1.2. 1. Press [CH ]/[ CH ]] buttons to select the Ratio item and then press [OK] button to enter the radio mode. 2. Press [CH ]/[CH ]buttons select your preferred radio channel. 3. The radio service will instantly start.
Page 16: Record Function
Record Function 1.3. NOTE: CAR TVIQ-HD supports both DVB-T TV and DVB-T Radio recording. 1. During TV or Radio mode, press [REC] to start recording TV/Radio programs. When unit is start recording, icon will appear on the upper left screen &...
Page 17: Movie Watching
Movie Watching 1.4. The section below will explain you how to quickly play a video file stored on USB device. After selecting movie playback mode on the home screen, file browser screen will appear. Press [OK] button to select the root folder.
Page 18: Music Listening
Music Listening 1.5. The section below will explain you how to quickly play a music file stored on USB device. 1. After selecting music playback mode on the home screen, file browser screen will appear. Press [OK] button to select the root folder.
Page 19: Photo Viewing
Photo Viewing 1.6. The section below will explain you how to view a picture file stored on USB device. 1. After selecting photo viewing mode on the home screen, file browser screen will appear. Press [OK] button to select the root folder.
Page 20 Photo Viewing – Advanced Functions Rotating picture Press [VOL ] button to rotate the picture clockwise, press [VOL ] button to rotate it counterclockwise. Slideshow Press [PLAY/PAUSE] to start/stop photo slideshow. Zoom 1. When viewing a picture, press [OK] to enter zoom mode. 2.
Page 21: Using The Menu
Using the Menu 2.1.1 DVB-T TV/Radio Menu After entering the DVB-T TV or Radio service, press [MENU] button to make the menu appear. By navigating the different options, you can have access to channel list, channel management, automatic channel search function, DVB-T audio settings, channel info, aspect ratio, subtitle function, and teletext.
Page 22: Channel Management
information of the selected program. 6. Press [EXIT]/[MENU] button to return to “Channel List”. c. Brief 1. Press [EXIT]/[MENU] return “Schedule”. 2.1.3 Channel Management To rearrange and to edit the TV channel listing using skip, move, and delete functions. 1. Select “Channel Management” in the TV Menu press [OK]...
Page 23: Auto Search
Channel Delete 1. After entering the channel editing menu, select the “DELETE” visual-button on screen by using [VOL ]/[VOL ] buttons. 2. Press [OK] button to delete the channel. NOTE: this function will permanently delete the channel from the current program list.
Page 24: Channel Information
2.1.6 Channel Information Provide the information of current service’s system parameters and signal information. 1. Browse menu screen using [CH ]/[CH ] buttons to highlight the channel information option. NOTE: you can also press [INFO] button to enter “Channel Information” while enjoying DVB-T TV/Radio.
Page 25: Afs Setting
DVB-T TV/Radio. 2. Press [CH ] button to view next page or [CH ] to view previous teletext page. 3. Press numerical key button to jump to specific teletext page. 4. Press [MENU]/[EXIT] to leave. 2.1.9 AFS Setting* 1. OFF: Turning OFF AFS function 2.
Page 26: System Settings
System Settings 2.2. This is the system settings menu screen. Users can adjust the country/language setting, monitor port setting, HDMI setting, reset default, and proceed to a software upgrade. Use [CH ] and [CH ] buttons to highlight the desired item and press [OK] button to select one.
Page 27: Hdmi Setting
2.2.3 HDMI Setting To set up the HDMI output 1. Press [CH ]/[CH ] buttons to highlight the item you want to adjust. 2. Press [VOL ] button [CH ]/[CH ] to scroll up and down the options. 3. Select one by pressing the [OK] button or exit setting pressing...
Page 28: Photo Menu
Photo Menu 2.3. On entering Photo service, press [MENU] button to invoke photo menu. Though this menu, user can adjust playing mode, slideshow time, and slideshow effect 1. Press [CH ]/[CH ] buttons to highlight the item you want to adjust. 2.
Page 29: Movie Menus
Movie Menus 2.5. On entering Movie service, user can manipulate aspect ratio, sound effect, set up the equalizer, set the play mode, change audio, and subtitle. 2.5.1 Menu 1. Press [MENU] to enter “Menu”. 2. Press [CH ]/[CH ] buttons to highlight the item you want to adjust.
Page 30: Trouble Shooting Q&A
3. Trouble Shooting Q&A Most of the troubleshooting issues can be easily solved. The common cases and their respective solutions are listed in the table below. If the problem persists, please contact the after sales service. Problem Possible Reason Solution Power Cable is not Check the power wire connection and inserted correctly...
Page 31: Specifications
4. Specifications Features DVB-T Reception Best in class performance of DVB-T TV reception (Diversity-2) Multimedia playback MP3, MPEG4, JPEG multimedia playback through USB device Advanced functions Support Pay TV, TV-recording , and AFS function RF Input Antenna Active antenna supported (F-Connector) Frequency range VHF (170-230 MHz) and UHF band (470-862 MHz) RF input impedance...
Page 32 TV out 1 CVBS video out, 1 audio (L/R) out Power Input voltage +12-24 V DC Power consumption 5.5 W Dimension and Weight Dimension 185 x 147.2 x 34 mm Weight 750 g...
Page 33: Warranty
Email: info@zylux.com.au If the Authorised Supplier and / or Zylux service centre concludes that while under normal use, a product failure or malfunction occurred during the warranty period and was caused by a defect in material or workmanship (see Exclusions), the Customer will be asked to ship to the nearest service point so the product can be assessed and repaired.
Page 34 Distributed by Zylux Distribution Pty. Ltd. 166 Christmas Street, Fairfield, VIC, 3078, Australia. Tel: (03) 9482 2203 Fax: (03) 9486 2297 Website: www.zylux.com.au Version 1.0...
