Summary of Contents for MagniLink MLV-BASIC-HD-23
- Page 1 User Manual MagniLink Vision BASIC LVI Low Vision International Verkstadsgatan 5 Tel: +46 470 – 727700 E-mail: info@lvi.se 352 46 Växjö Fax: +46 470 – 727725 Internet: www.lvi.se...
- Page 2 User Manual 79 44 269 | MagniLink Vision BASIC...
-
Page 3: Table Of Contents
Panel ....................12 Reading table ..................13 TROUBLESHOOTING ..............14 TECHNICAL SPECIFICATION ........... 15 FCC STATEMENT (USA AND CANADA ONLY) ......17 User Manual 79 44 269 | MagniLink Vision BASIC... - Page 4 In the interest of continued product development, LVI reserves the right to make improvements to this manual, and the products it describes, at any time, without notice or obligation. User Manual 79 44 269 | MagniLink Vision BASIC...
-
Page 5: General Information
General Information MagniLink Vision (MLV) is a video magnifier which is available in several models. All models have the same structure, reading table and electronics. Thereafter, the module is chosen following 2 steps: - Camera (available as Standard Definition (SD) or High Definition (HD). - Page 6 3 Turn MLV-BASIC-HD-19 18.5” 3 Turn MLV-BASIC-HD-23 23.0” 3 Turn The equipment complies with requirements for CE-approval of medical devices according to 93/42/EEG directives and MDD 93/42/ECC with amendment from directive 2007/47/EC. User Manual 79 44 269 | MagniLink Vision BASIC...
-
Page 7: Safety Information
If the MagniLink Vision is to be transported, do not lift the unit by the screen or the reading table, as these are movable parts. - Page 8 To prevent fire or shock hazard, do not expose the equipment to moisture. To reduce the risk of electric shock, do not remove the cover. No user serviceable parts inside. Please refer service to qualified service personnel. User Manual 79 44 269 | MagniLink Vision BASIC...
-
Page 9: Unpacking
Inspect the package for exterior damage. Note that severe damages should be addressed with the transport company. Open the box and take out the MagniLink Vision. Remove the packaging and place the unit on a table. The mains cord is placed on the back of the unit. -
Page 10: Installation
Installation Place the unit on a table. The MagniLink Vision should be placed at least 10 cm/3.9 inches from the edge of the table. Note that the system’s reading table can be moved up to 30 cm/11.8 inches in three directions. -
Page 11: Work Place
Work place A comfortable work place around your MagniLink is important. It could be useful to keep the following in mind: The chair should have a back rest. The seat of the chair should be at a height which does not make your legs become numb. -
Page 12: Instructions
There are four combinations in the standard configuration: Background/Text Background/Text White/Black Yellow/Black Black/White Black/Yellow User Manual 79 44 269 | MagniLink Vision BASIC... -
Page 13: Reading Table
Set the depth way friction by moving this handle. With the brake in the near end position, the reading table is unlocked. To increase friction, push the depth way brake towards the back. User Manual 79 44 269 | MagniLink Vision BASIC... -
Page 14: Troubleshooting
If the LED to the left of the main switch is solid red, something is wrong with the equipment and it cannot be used. Press the main switch once and MagniLink Vision will make three attempts to restart. If the light still indicates a solid red, turn off the equipment and contact an authorised service technician. -
Page 15: Technical Specification
420 x 470 x 570 mm (W x D x H) 16.5 x 18.5 x 24.4” (W x D) Dimensions of packaging: 620 x 590 x 610 mm (W x D x H) 24.4 x 23.2 x 24.0” (W x D) User Manual 79 44 269 | MagniLink Vision BASIC... - Page 16 The recycling of materials will help to conserve natural resources. For more detailed information about the recycling of this product, please contact your local city office, household waste disposal service or the retail store where you purchased this product. User Manual 79 44 269 | MagniLink Vision BASIC...
-
Page 17: Fcc Statement (Usa And Canada Only)
To comply with the FCC rules, the system should only be used with the enclosed LVI power supply. User Manual 79 44 269 | MagniLink Vision BASIC... - Page 18 to follow the requirements regarding products placed on the market as described in section 4 of Annex VII. Manufacturer Manufacturer´s authorized representative Date Signature Position 2010-09-21 Managing Director Clarification Erik Bondemark User Manual 79 44 269 | MagniLink Vision BASIC...
