- Page 1 Freestanding Gas Stove MODEL: PGS3006 GPEES30C Installation and Maintenance Manual...
- Page 2 Warning � � � � Maintenance products should be carried out by professional and technical personnel with relevant qualification, as improper maintenance may lead to other dangers! � � � � Before maintenance, be sure to cut off the power! �...
- Page 3 Table SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS ……………………………………………………………………………1 TECHNICAL INFORMATION …………………………………………………………….1 INSTALLATIONS INSTALLATIONS INSTALLATIONS INSTALLATIONS ……………………………………………………………………………..2 SAFETY PRECAUTIONS FOR INSTALLATION …………………………………..2 INSTALLATION OF OVEN ………………………………………………………………..2 SERVICE SERVICE SERVICE SERVICE INFORMATION INFORMATION INFORMATION INFORMATION …………………………………………………………………3 NECESSARY TOOLS …………………………………………………………………...3 DISASSEMBLY AND ADJUSTMENT ……………………………………………….5 COMPONENTS TEST PROCEDURE COMPONENTS...
-
Page 4: Specification
Specification Technical Parameters Product Type 30inch Product Dimensions 760*600*940 (Height / width / depth) (mm) Maximum temperature 250°C Function switch (quantity) 9/11 Grill number of layers Nozzle hole diameter (mm) φ0.88/ φ 0.5/φ0.64/φ0.8 Heating tube power (down) (W) 2800 - 1 -... -
Page 5: Installation Warning
Installation Before Maintenance, please read the following instructions carefully! Installation Warning All the equipment around 50mm of the product should be able to have heat resistance above 75 ° C, otherwise, nearby apparatus may deform during the use of this product. When removing packing materials, keep metal plates, packaging bags, foam, screws and other materials away from the reach of children to avoid potential threat. -
Page 6: Maintenance Information
Maintenance Information Relevant Tools Relevant tools list. • • • • Drill steel clamp (vise) • • • • Needle-nosed pliers • • • • Phillips screwdriver • • • • Electric iron • • • • Solder wire • • • • Insulation tape •... - Page 7 B. The removal of cooktop back guard 1) Remove the screws for fixing the back board. (See below pictures) Remove the screws C. Remove the right and left bracket of the cooktop 1) Turn off the gas source. 2) Remove the screws on supporting blocks of both sides of the cooktop cover. (See below pictures) - 4 -...
- Page 8 D. Remove of the stove board 1) Turn off the gas supply, disconnect the power, remove the power line. 2) Remove back plate connection board 3) Remove the screws of the end of the cooking plate connection the cup（See below pictures） 4）...
- Page 9 Pneumatic control part Push from back to front 5~10mm E．Removal and Replacement of Glass Door 1) Remove the door and lie flat carefully. 2) Remove the screws for fixing supporting blocks at the bottom of door. 3) Remove the screws for fixing handle, remove the handle, seal and window glass outside the door carefully.
- Page 10 Parts Test program Results Stove body Test tightness Normal: less than 0.5ml/min, (use airtight instrument test: under 15kpa Fault:∞ or more than 0.5 pressure) - 7 -...
-
Page 11: Troubleshooting
Trouble shooting When you receive customer complaints, what needs to do first is analyzing complaints carefully. If some of the following situation is suitable, please tell the customer how to use the oven properly. This will avoid unnecessary maintenance. Attention! 1.
