Page 1 HN5i - Quick Start Guide...
Page 3: Table Of Contents
Parts of the HN5i ..................... 4 Inserting & Removing MicroSD cards ..............6 Using the MicroSD Card Adapter ................ 7 Mounting the HN5i on the Windscreen ..............8 Turning the HN5i ON and OFF ................. 10 Charging the Battery ..................10 Resetting the HN5i ..................
Page 4 HN5i - Quick Start Guide Main Menu ....................14 Tools Menu ....................15 Street Nav ....................... 46 Street Nav ....................46 Getting To Know the Screens and Buttons ............46 Map Screen and Functions ................49 Quick Menu button ..................50 Map Screen Options during Navigation .............
Page 5 Table of Contents Selecting a Map ..................... 95 Memory-Map Navigator DVD Installation ............97 Important Product Information ................. 104 Important Product Information ..............104 Technical Data Sheet ................... 106...
Page 7: Hn5I Quick Start Guide
Quick Start Guide Safety Notes & Maintenance Safety Notes & Maintenance This section of the Quick Start Guide contains some general information and recommendations related to the use of your HEMA NAVIGATOR HN5i. Operating Environment External Influences  Do not allow objects to drop onto the device from above.
Page 8: Safety While Operating The Device
Safety While Travelling While the HEMA NAVIGATOR HN5i is a valuable tool for navigation, it is only that - a tool - and as such should not be used as a replacement for hard-copy maps and other traditional navigational aids while travelling, especially in remote areas.
Page 9: Cleaning The Unit
HEMA takes great pride in providing its customers with quality navigation solutions supported by friendly and effective customer service. HEMA is confident that the NAVIGATOR will prove to be a valuable tool in the pursuit of your adventures and ensure a safe and pleasant journey wherever the road or track may lead you.
Page 10: Hn5I Features
 New 64-Channel GPS for improved location accuracy and faster GPS fix  2GB on-board memory  8GB microSD card Preloaded with HEMA 4WD maps & Topo 250 Austalia (1:250K)  Bluetooth – Built-in hands free calling  FM Transmitter ...
Page 11 HN5i Quick Start Guide Power Button: Powers the NAVIGATOR ON / OFF or activates sleep mode LCD Touch Screen Display: 5.0 inch LCD display LED Power Indicator: Glows red when charging and green when fully charged Top View Power Button: Powers the NAVIGATOR ON / OFF or activates sleep mode...
Page 12: Inserting & Removing Microsd Cards
USB port: Connects the NAVIGATOR to a 12/24V power source or Windows PC computer system Inserting & Removing MicroSD cards The HEMA NAVIGATOR HN5i comes with a pre-installed 8GB MicroSD card. To remove the MicroSD card from your HN5i 1. Turn the NAVIGATOR so that the rear of the device is visible.
Page 13: Using The Microsd Card Adapter
HN5i Quick Start Guide NOTE Avoid letting the MicroSD card eject quickly out of the slot. To re-insert the MicroSD card 1. Turn the NAVIGATOR so that the rear of the device is visible. Locate the MicroSD card slot on the side of the device.
Page 14: Mounting The Hn5I On The Windscreen
LOCK. This will WRITE PROTECT the card, and prevent data being written to the card. Mounting the HN5i on the Windscreen Attach Cradle to Windscreen Mount Attach the cradle to the windscreen mount via the 4 pin system and slide it down until it snaps/locks securely in place.
Page 15 NAVIGATOR. 2. Plug the car charger into the power outlet of the vehicle. Attach the HN5i to the Mount 1. Secure the NAVIGATOR to the cradle on the windscreen mount by aligning the base of the device with the tabs on the cradle.
Page 16: Turning The Hn5I On And Off
The SLEEP MODE screen will be displayed briefly and the display will be turned off. Powering the unit back on from SLEEP MODE will restart the HN5i on the same screen from which the sleep mode was originally activated. NOTE The unit is not completely shut down and will discharge the battery over the course of time.
Page 17: Stylus Techniques
Hold the stylus on an open overlay window, and then quickly drag/flick the window off the edge of the screen in one movement. Additional Information You can find product manuals and support information on the NAVIGATOR website http://www.hemanavigator.com.au/ including User Guides for each of the Navigation applications on the HEMA NAVIGATOR HN5i.
Page 18: Pc Connectivity
HN5i - Quick Start Guide PC Connectivity PC Connectivity The HN5i can be connected to a PC for the following purposes:  Accessing the contents of NAVIGATOR MicroSD Card.  Using the iGo NaviExtras Toolbox to purchase and activate products through the Online Store such as extra mapping and functionality.
Page 19: Pc Sync Mode
HN5i Quick Start Guide C:\ (System hard disk) D:\ (Data hard disk) E:\ (DVDRW drive) G:\ (USB Memory stick) After you connect the NAVIGATOR in Mass Storage mode, Windows will assign the drive letters the following way: C:\ (System hard disk)
Page 20: Power Connection Mode
HN5i - Quick Start Guide Power Connection Mode NOTE This mode provides no data communications connectivity. This mode will charge the NAVIGATOR device using the USB port of the PC as the charging source. Main Menu Main Menu Tools button...
Page 21: Tools Menu
The NAVIGATOR Tools menu consists of the following elements: BlueTooth BlueTooth is a wireless technology which enables the transmission of voice and data over a short distance. The HEMA NAVIGATOR is able to pair with a BlueTooth enabled mobile phone to make or receive phone calls. Player The Player allows you to read text files, listen to music, and view photographs, video and flash files.
Page 22 A scientific calculator for mathematical operations. Calendar A calendar for viewing any day, month or year. Transmits the audio signal from the HEMA NAVIGATOR to an FM radio receiver (car radio) in your vehicle on the specified frequency. AV IN With a compatible reversing camera connected, you can view the video signals produced by the camera.
Page 23 HN5i Quick Start Guide The NAVIGATOR Bluetooth menu consists of the following elements: Keypad Access the Keypad screen to make calls Call Record Displays lists of calls showing date & time and call duration. Lists provided are:  Outgoing calls ...
Page 24 HN5i - Quick Start Guide When you choose to pair with the NAVIGATOR, you will be prompted to enter the PIN code (default 8888).
Page 25 HN5i Quick Start Guide Back button: Return to previous screen Pairing Countdown Timer: Counts down from 60 seconds during which time, the NAVIGATOR is discoverable Once your phone has paired successfully, you will see the Pair Success message briefly on the screen of your NAVIGATOR.
Page 26 HN5i - Quick Start Guide Back button: Return to previous screen Bluetooth indicator: Showing connection to mobile phone 1. Enter the number using the keypad buttons 2. Tap the Green Handset button to make the call Back button: Return to previous screen...
Page 27 HN5i Quick Start Guide Bluetooth Attributes Tap the Attributes button on the Bluetooth menu to view and change various settings related to your NAVIGATOR's Bluetooth operation. You can perform the following actions:  Change the PIN code  Turn on the option to keep Bluetooth running in the background ...
Page 28 HN5i - Quick Start Guide Back button: Return to previous screen Current PIN Code: Shows the currently set PIN code Clear button: Clears the current PIN code completely, ready for re-entering Backspace button: Clears right-most character of PIN code Keep Bluetooth running in background Tapping the Keep Bluetooth Running indicator button will switch this feature ON.
Page 29 HN5i Quick Start Guide Tapping the Auto Pickup indicator button will switch this feature ON. This will cause your phone to automatically answer any incoming call. Answer Incoming Call When an incoming call is received, you phone will answer the call automatically if the Auto Pickup Incoming Call option is switched on.
Page 30 HN5i - Quick Start Guide Back button: Return to previous screen Call Record List Select button: Choose which of the three screens you wish to view...
Page 31 HN5i Quick Start Guide Call Record List buttons The buttons at the bottom of the Call Record screens perform the following functions: Delete selected entry: Removes the highlighted entry from the current list Delete ALL Entries: Removes ALL entries from the current list...
Page 32 HN5i - Quick Start Guide Keypad screen buttons Call Number: Call the number displayed Hang Up: End current call Backspace: Delete right-most digit of phone number displayed Volume Down: Decrease volume level during call Volume Up: Increase volume level during call...
Page 33 HN5i Quick Start Guide Pair Device screen buttons Re-connect to selected Device: Re-establishes Bluetooth connection with selected device in list Drop connection: Disconnects from selected device in list Delete ALL Entries: Removes ALL entries from the current list Previous Entry: Moves back one entry in the current list...
Page 34 HN5i - Quick Start Guide Create Note button: Create a new empty note Save Note: Store note for later viewing Delete Note: Delete the selected note Create New Note Back button: Return to previous screen To create a new note: 1.
Page 35 4. Tap the Delete Note button to permanently erase the selected note. Calculator Application The HEMA NAVIGATOR HN5i comes with a comprehensive scientific calculator which can be used for simple or advanced calculations. Back button: Return to previous screen...
Page 36 Back button: Return to previous screen OK button: Used to set the System Date to that shown by the calendar FM Transmitter Function The HEMA NAVIGATOR HN5i can be set to transmit audio on a preselected FM radio frequency. NOTE The NAVIGATOR will NOT output sound through the internal speaker while the FM function is switched ON.
Page 37 HN5i Quick Start Guide Back button: Return to previous screen Frequency selection control: Slide the green arrow to selected the desired frequency. You can also use the left & right arrows to move the green arrow slider in .1 MHZ increments...
Page 38 HN5i - Quick Start Guide The NAVIGATOR can play music, video, text, image and Flash files. Each section of the Player has a file browser screen where you can choose the files you wish to play. Music Use this option to select and play music files (MP3 format)
Page 39 HN5i Quick Start Guide Music Player The Music Player will appear when the Music button is selected on the Player screen and a compatible file is selected in the Music Player File Browser. Back button: Return to previous screen Current Folder: Shows the current folder you are browsing Folder Contents: Shows the contents of the current folder 1.
Page 40 HN5i - Quick Start Guide Back button: Return to previous screen Track Name: The name of the currently playing track Status: Audio bandwidth display and play status panel Progress Meter: Shows how far through the current track you are Volume Control: Allows you to increase / decrease the volume level during...
Page 41 HN5i Quick Start Guide Video Player The Video Player will appear when the Video button is selected on the Player screen and a compatible file is selected in the Video Player File Browser. NOTE Operation of the Video Player is not recommended during navigation.
Page 42 HN5i - Quick Start Guide File Name: The name of the currently playing video file Video Display: Video playback window Progress Meter: Shows how far through the current video you are Video Player Screen buttons Previous: Skip to previous video...
Page 43 HN5i Quick Start Guide Back button: Return to previous screen 1. Browse to the text file in the Text Browser 2. Select the file to view by tapping the required icon The Text Viewer will display the contents of the text file.
Page 44 HN5i - Quick Start Guide Back button: Return to previous screen Current Folder: Shows the current folder you are browsing Folder Contents: Shows the contents of the current folder NOTE It may take a short while to generate thumbnail images of the images in the selected folder, depending upon the size of the image files.
Page 45 HN5i Quick Start Guide Photo Player Screen buttons Previous Image: Skip to previous image in current folder Next Image: Skip to next image in current folder Zoom In: Zoom in current image Zoom Out: Zoom out current image Slideshow: Make current image fullscreen and start slideshow. Slideshow will continue until screen is tapped.
Page 46 HN5i - Quick Start Guide Back button: Return to previous screen The NAVIGATOR System menu consists of the following elements: Volume Adjusts the master volume level of the internal audio Power Displays battery charge level and status, and allows adjustment of power saving...
Page 47 HN5i Quick Start Guide The Volume produced by the internal speaker in the NAVIGATOR can be adjusted by the tapping the buttons as shown below. The Enable sounds for taps option, when switched ON, produced a sound when options are tapped in the NAVIGATOR's menu system.
Page 48 HN5i - Quick Start Guide Back button: Return to previous screen Battery level indicator: Animated when charging, shows current level when unit is disconnected from power source. Sleep Mode Indicator / Adjustment: Set the unit to go into Sleep Mode after a set time period on battery power.
Page 49 HN5i Quick Start Guide Back button: Return to previous screen Backlight level indicator / Adjustment: Shows current backlight level. Use arrows to adjust. Dim Mode Indicator / Adjustment: Set the unit to dim the screen after a set time period on battery power.
Page 50 HN5i - Quick Start Guide Back button: Return to previous screen Day, Month, Year, Hour & Minute Adjustment: Use arrows to adjust current date & time. Time zone Indicator / Adjustment: Set the unit to the appropriate time zone using the arrows.
Page 51 HN5i Quick Start Guide Sys Info. Displays various items of system information, including the signal strength of GPS satellites. You can also perform the following functions: Back button: Return to previous screen System Status Panel: Shows various items of system information, including signal strength of GPS satellites.
Page 52: Street Nav
HN5i - Quick Start Guide Occasionally, It may become necessary to recalibrate the NAVIGATOR's touch screen. Recalibrating the touch screen ensures that where you tap on the screen is registered by the system in the correct place. Simply tap and follow the numbered cross hairs around the screen. Start from the centre (1), then tap 2, 3, 4, and 5 in turn.
Page 53 HN5i Quick Start Guide Once the program has started, the Navigation Menu will be displayed: By default, iGo will automatically switch to night colour mode between sunset and sunrise. Exit button...
Page 54 HN5i - Quick Start Guide The Exit button will exit from the iGo application and return you to the NAVIGATOR Main Menu. Show Map button The Show Map button will take you to the main map display, which will show your position on the moving map, or your route if navigating to a specific destination.
Page 55: Map Screen And Functions
HN5i Quick Start Guide More button Tap the More button to access the More… Menu. Here you can  customise the way iGo works via the Settings menu  access additional features and functions Back button Wherever you see the Back button displayed, it can be tapped to take you back to the previous screen.
Page 56: Quick Menu Button
HN5i - Quick Start Guide The standard features of the Map screen are: Direction and Street Numbers Indicator: Shows street numbers on either side of your current street, and the general direction. Quick Menu button: Jumps to the Quick Menu Current Speed: Shows the current speed.
Page 57: Map Screen Options During Navigation
HN5i Quick Start Guide The Quick Menu contains functions which are handy to have quick access to during navigation (such as Cancel Route and volume controls). The Quick Menu has 8 buttons, and these buttons can be configured to suit you by going to the Settings >...
Page 58 HN5i - Quick Start Guide During navigation, the map screen displays a number of pieces of information and indicators. These are only visible when navigating to a destination, or along a route. If displayed, the Menu button will take you to the Navigation Menu.
Page 59: Using The Find Button
HN5i Quick Start Guide The Quick Menu button will take you to the Quick Menu. The lower-right of the map screen contains a group of info panels. You can tap these to toggle between a single panel and a three panel view.
Page 60 HN5i - Quick Start Guide Tap Find Address button to specify an address as your destination. Tap the Find Places button to select a Point Of Interest (POI) as your destination. Tap the Find on Map button to navigate to a location selected directly on the map.
Page 61: Finding An Address
HN5i Quick Start Guide Tap the #1 or #2 buttons to navigate to a previously used destination. Tap the History button to access a list of previously used destinations. Tap the More button to navigate to a coordinate or to a location saved in a photo.
Page 62 HN5i - Quick Start Guide The Country selection will, by default, show you the Country and State where you are currently located. If you need to, change the Country/State by tapping the Country button, and entering data with the on screen keyboard.
Page 63 HN5i Quick Start Guide You will then see a 2D map view of the address you have selected, with the selected address marked with a cursor. Tap the Next button to calculate a route to your selected destination. The route to your destination is now calculating.
Page 64 HN5i - Quick Start Guide You will then see a preview of the route chosen. You can tap the More button to see some additional options, such as  Route Alternatives  Itinerary  Route Settings  Simulate Route ...
Page 65: Finding A Poi
HN5i Quick Start Guide If you wish to cancel the current destination, or make other changes while in navigation mode, tap the Quick Menu button to access these functions. Finding a POI Tap the Find Places button from the Find menu The Find Places menu allows you to specify where you want to go by searching a comprehensive list of POIs.
Page 66 HN5i - Quick Start Guide iGo dynamically changes the options available to you from the Find Places screen depending on whether you are currently en route to a destination. For example, when you are currently en route to a destination, iGo can show you a list of petrol stations which are along the route taken.
Page 67 HN5i Quick Start Guide Tap the Results button to display the results list. If required, you can further refine your search using the Filter button. In the example above we searched for “caravan” around our current location. The Places Found screen displays a list of matching entries in order of distance away from your current location (closest to furthest).
Page 68 HN5i - Quick Start Guide You will see the location previewed on the map. Tap the Next button to start the navigation process. Quick Search Along Route The Quick Search Along Route button is displayed if you are currently navigating to a destination.
Page 69: Quick Search Along Route
HN5i Quick Start Guide POI Deviation Indicators The list will also show indicators to help you gauge how far off your route the POIs are (i.e. small, medium or large deviation from your route). This can help you to decide which petrol station is easier for you to stop at during your journey for example.
Page 70: Quick Shortcuts On Find Places Screen
HN5i - Quick Start Guide Note the indicators on the items in the search results list. These indicators will show you how much of a deviation from your route each of the places is. The indicators will be one of the following:...
Page 71: Custom Search
HN5i Quick Start Guide Performs a quick search for Petrol Stations either around your current location, or along your current route. Available when not navigating Available when navigating along a route Performs a quick search for Accomodation either around your current location, or at the destination of your current route.
Page 72 HN5i - Quick Start Guide The Custom Search button allows you to fully customise all aspects of the search you want to perform. Tapping the Custom Search button will take you to the main Custom Search screen. Note that you will see one of two different views of this screen, depending on whether you are currently routing to a destination or not.
Page 73 HN5i Quick Start Guide 2. Custom Search - Around here Search for POIs around your current location 3. Custom Search - Along route Search for POIs along your current route, if you are currently navigating to a destination. 4. Custom Search - Around Destination Search for POIs around the destination of your current route, if you are currently navigating a route.
Page 74: List Of Poi Categories
HN5i - Quick Start Guide You can also narrow your search down using the Find by Name button, which will filter the currently selected categories according to the Name you enter using the on screen keyboard. List of POI Categories...
Page 75: Using Your Navigator With Camps 6 Book
Using your Navigator with CAMPS 6 Book Using Navigator with CAMPS 6 The CAMPS 6 POI data included with your HEMA NAVIGATOR HN5i is designed to work in conjunction with the Camps Australia Wide 6 book. The range of CAMPS 6 Australia Wide books are available from many retailers or direct from HEMA.
Page 76 The Camps Australia Wide 6 book contains a wealth of information for each location. The pairing of a HEMA NAVIGATOR HN5i and the Camps Australia Wide 6 book makes a great team and a terrific resource for travellers! Finding CAMPS6 POIs...
Page 77 HN5i Quick Start Guide Tap the Find Places button to go to the Find Places menu. Tap the Camps 6 Along Route button You will see a list of CAMPS 6 POIs which are located along the route. You can scroll up and down through the list using the arrows to the right of the list.
Page 78 HN5i - Quick Start Guide Use the on screen keyboard to enter the name (or a part thereof). In this example, we are searching for any CAMPS 6 POI which matches the word “MUCKA” You will then see the Places Found screen, showing any matches for the name you searched for.
Page 79 HN5i Quick Start Guide Tapping the Next button will take you to the Use this location as… screen. You can then you can choose to  Create a new route to that place, which supersedes your original route.  Add the place to your route as a waypoint, keeping the original route destination.
Page 80: More Menu
HN5i - Quick Start Guide The Places Found screen will show only the CAMPS 6 ID which you searched for, and you can perform the same functions as shown in the previous section, such as setting the POI as your new destination, etc.
Page 81 HN5i Quick Start Guide The options available from the More menu are as follows: The Settings menu is where you can customise many of the options within iGo, such  Fine tune route planning options  Change the look / colours of the map screen ...
Page 82 HN5i - Quick Start Guide The Unit Converter tool will help you convert many units of measure, such as length, speed, temperature etc. The Clothing tool gives you access to comparison tables which help compare sizes of various items of clothing using standard sizes from different countries.
Page 83: Settings Menu
HN5i Quick Start Guide The Trip Monitor tool allows you to make records of journeys including saving a track log. The Country Information tool shows some useful information for most of the countries of the world, such as standard vehicle speed limits, blood alcohol levels, emergency phone numbers etc.
Page 84 HN5i - Quick Start Guide Sound and Warnings  Adjust sound volume of different aspect of audio output  Change voice guidance profile  Enable and set up warnings Customise Quick Menu  Customise the 8 (eight) buttons which are available from the Quick Menu...
Page 85 HN5i Quick Start Guide Map Settings Adjust all map related settings, such as  Day and night colour schemes  Default zoom level  Change between 2D & 3D modes  Suppress building models  Change your Vehimarker (the icon used to mark your vehicles position when on...
Page 86: 4Wd Nav
Deletes all saved data and resets the program settings to the factory defaults. 4WD Nav 4WD Nav The 4WD Nav function on the HEMA NAVIGATOR HN5i uses the OziExplorer application to provide an exceptional user experience during offroad navigation. The OziExplorer interface, which is known as HEMA-EziOzi, has been customised using the OziExplorer Screen Designer tool, in an effort make the software more accessible and enjoyable during use.
Page 87: Getting To Know Oziexplorer
HN5i Quick Start Guide To begin 4WD Navigation, tap the 4WD button from the Main Menu. OziExplorer will display a splash screen during startup, as shown below: Getting to know OziExplorer A typical OziExplorer screen is shown above (in this case the Map View page).
Page 88: Map Overlay Information & Buttons
HN5i - Quick Start Guide This image shows some of the key features of the OziExplorer display. Page Title: Shows the name of the currently displayed page Standard Toolbar: Contains buttons for commonly used functions Page Specific Toolbar: Contains buttons specific to the current page Map Overlay Information &...
Page 89: Standard Toolbar
HN5i Quick Start Guide Position Pointer / Cursor: The current GPS position Latitude / Longitude: Current position Scale + button: Increase map scale (change to more detailed map) Current Zoom Level: Current zoom (or magnification) level of displayed map Scale - button: Decrease map scale (change to less detailed map)
Page 90: Acquiring A Gps Satellite Fix
HN5i - Quick Start Guide Popup Toolbar button: Alternately shows / hides the popup toolbar Settings button: Opens the Settings page allowing modification of program settings GPS OFF/ON button: Alternately suspends / resumes GPS tracking Exit button: Exits the program back to the NAVIGATOR Main Menu As well as the Standard Toolbar, the program displays a toolbar located along the bottom of the screen.
Page 91: Page Selection
HN5i Quick Start Guide Num Sats: Number of satellites currently visible HDOP: Horizontal Dilution of Precision - An indication of horizontal positioning accuracy GPS Status: Shows whether the internal GPS is currently active Satellite Signals: Shows numbered satellites and relative signal strengths...
Page 92: Pages And Their Functions
HN5i - Quick Start Guide The currently selected page is indicated by a red highlight on the select page menu. Pages and their Functions Map View The main view within OziExplorer which gives the most amount of screen real estate to the actual map.
Page 93: Opening A Map
HN5i Quick Start Guide Similar to Map View, but has a bottom toolbar allowing access to functions related to Routes. Route Nav Similar to Map View, but has Next Waypoint data fields at the lower border of the map panel for use during Route navigation.
Page 94: Adding Waypoints
HN5i - Quick Start Guide Double-tap to open folders Name of the currently selected map Scroll up and down list of maps Double-tap to open selected map file, or single-tap to highlight and tap the OK button Adding Waypoints The Add Waypoint button is accessible from any page within OziExplorer that displays a map.
Page 95: Exiting Oziexplorer
DVD or install to your PC (recommended). The PC software will allow you to view the same maps that are preloaded on the HN5i and can be used to create waypoints, tracks and routes. This data can then be exported to the HN5i via the supplied USB cable.
Page 96 NAVIGATOR HN5 range can be connected to the HEMA NAVIGATOR Explorer PC software. Turn on the HN5i and wait for it to launch the Main Menu showing STREET, 4WD and TOPO Nav. Connect the HN5i to your computer via the supplied USB cable and wait for the sync program on the PC to start (Microsoft Active Sync for Windows XP or Windows Mobile Device Centre for Vista and Windows 7).
Page 97: Topo Nav
 Exporting of data such as routes, tracks and waypoints to the HN5i device.  Importing of data such as routes, tracks and waypoints from the HN5i device to the HEMA NAVIGATOR Explorer PC application.  A full list of all functions and methods of creating routes, tracks and waypoints.
Page 98: Acquiring A Gps Satellite Fix
HN5i - Quick Start Guide To begin Topo Navigation, tap the Topo button from the Main Menu. When the application starts, it will display a startup screen, and then four tutorial screens. Tap on each screen to move through the tutorial screens, until the Navigation Mode screen appears.
Page 99: Navigation Mode
HN5i Quick Start Guide The Satellites window will be displayed, showing the amount and strength of satellite fixes Navigation Mode Navigation mode is a good general way to view the TOPO maps on your NAVIGATOR and whilst navigating. In Navigation mode, the following overlay buttons will be displayed:...
Page 100: Planning Mode
HN5i - Quick Start Guide Go to Mark After establishing a GPS Fix, pressing the Go to Mark button will display a list of current waypoints available for navigation. Once a waypoint is selected, a bearing and navigational arrow will display straight line navigation information to the selected waypoint/mark.
Page 101: Selecting A Map
The Save and Close button is used to close the Memory Map application and return to the main HEMA NAVIGATOR Menu. When the Memory-Map application is activated again, it will load at the point that it was previously closed. Any marks, tracks and route information will also be loaded.
Page 102 HN5i - Quick Start Guide The following menu will be displayed: Select the Map… menu option. The Select Map window will appear, complete with a list of all the maps available for viewing / loading into Memory-Map. Tap the Refresh button to ensure that all available maps are loaded.
Page 103: Memory-Map Navigator Dvd Installation
DVD or install to your PC (Install maps to PC is highly recommended). The PC software will allow you to view the same maps that are preloaded on the HN5i and can be used to create overlays such as waypoints (marks), tracks, routes and text.
Page 104 HN5i - Quick Start Guide 2. Registration by entering the serial number found on the back of the DVD paper sleeve Creation of Online Account Click the Memory-Map icon on your desktop. Once the program has started click the Help > License Management menu...
Page 105 HN5i Quick Start Guide The License Information window will display. Click the Sign In button If you already have a Memory-Map online account, sign in. Enter: 1. User ID 2. Password 3. Tick the Save Password checkbox so the program remembers your login details for future use, if required.
Page 106 HN5i - Quick Start Guide Enter the following details:  User ID  Password (must be entered twice to ensure accuracy)  Name  Company / Affiliation  Email Address  Tick the Save Password checkbox if you wish to be notified about product updates etc.
Page 107 HN5i Quick Start Guide Highlight the four HEMA Region licenses (click on Region 1 and press the Shift Key on your keyboard, click on Region 4 while holding down the Shift Key) Click the Activate button Locate the Registration Serial Number on the back of the Memory Map DVD paper...
Page 108 Activation window and enter the serial number including the full stops: xxx.xxx.xxx.xxx. The Registration Menu will show each of the four HEMA Region zones, one at a time and will apply the Serial Number code to each of the four zones.
Page 109 Once the Memory-Map software has been installed and the maps have been activated, you will be able to view the maps from the Memory-Map PC application. NOTE These are the same maps that have been pre-installed on your HEMA NAVIGATOR HN5i Click on the Map > Map List... menu The available maps will be displayed in the Map List window, and can be selected by clicking on the desired map.
Page 110: Important Product Information
Important Product Information Important Product Information Software License Agreement BY USING THE HN5I, YOU AGREE TO BE BOUND BY THE TERMS & CONDITIONS OF THE FOLLOWING SOFTWARE LICENSE AGREEMENT, PLEASE READ THIS AGREEMENT CAREFULLY. HEMA MAPS grants you a limited license to use the software embedded in this device and supplied on the Australia 4WD Raster Map Collection DVD (the “software”) in...
Page 111 Part 15 HEMA NAVIGATOR Limited Warranty The HN5I product is warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, HEMA MAPS will, at its sole...
Page 112: Technical Data Sheet
HEMA retains the exclusive right to repair or replace the unit or software or offer a full refund of the purchase price at its sole discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.
Page 113 HN5i Quick Start Guide Resolution 480 x 270 Flash ROM 2Gb NAND Flash Memory SDRAM 128Mb DDR RAM Built-in 64 Channel SIRF Atlas IV GPS Module Internal GPS accessed via COM Port 7 Antenna Embedded Input Touch Screen Interface FM Transmitter Function...
Page 114 HN5i - Quick Start Guide hours 12/24V DC Car Charger Output 5V DC 1.5 A Operation 0 - 55 °C Temperature Storage -20 - 35 °C Environmental Conditions Operation 45 - 80 % Non-Condensed Humidity Storage 30 - 90 % Non-Condensed...
