Summary of Contents for CamPilot mr900
- Page 1 C a m P i l o t M R 9 0 0 U s e r ’s G u i d e 1. CamPilot MR900 Introduction 2. CamPilot MR900 Installation CamPilot MR900 20090723 CamPilot MR900 - 20090723 1 / 8...
- Page 2 • CamPilot MR900 Features 1) Easy to use - CamPilot MR900 doesn’t require an additional PC for operation. Users can monitor video /audio data from CamPilot MR900 through a regular PC’s Web Browsers (Explorer or Netscape).
- Page 3 CamPilot MR900 • CamPilot MR900 Specification Item Specification ARM926EJ-S 270MHz Flash Memory DDR2 667MHz, 256MB Embedded Linux Video 1ch. in / 1ch. decoding-out (BNC connector) Audio 1ch. in / 1ch. out (Ø 3.5mm stereo jack) NTSC : D1(720X480), 4CIF(704X480), VGA(640x480), CIF(352x240),...
- Page 4 2) CamPilot MR900 is subject to electric damage. Check the external power supply capacity. 3) CamPilot MR900 is vulnerable to physical damage. Don’t throw or drop the product down. 4) CamPilot MR900 is made of metal and might cause injury if thrown out to a person. Be careful for tight installation.
- Page 5 ■ DC 12V - Power (DC 12V 1000mA Adapter) ■ ETHERNET - LAN cable (RJ45 Jack) - A client PC or a network devices is connected to the CamPilot ■ VIDEO - Video cable (BNC Jack) - IN : Input - OUT : Mode Selectable output (Connected camera or received image over IP) ■...
- Page 6 - The Camera List displays the basic information of the searched CamPilots on the local network. (Default IP address is 192.168.1.2) - Select a CamPilot and change the network setup appropriately. - After the setup, click “Save” button. - Refer to “ENCP 2.0” manual for details.
- Page 7 CamPilot MR900 4) Accessing to CamPilot MR900 with a web browser - Open a web browser on PC and enter the IP address assigned to a Campilot MR900 as following. http:// 192.168.1.2/ - Figure: Initial display after the access to the CamPilot MR900 ▶...
- Page 8 CamPilot MR900 ③ Completion of the access to CamPilot MR900 - Video / audio monitoring and CamPilot managing are available by a web browser. - Various CamPilot setup changing are available by the access of the administrator account. ▶Monitoring page ▶...
