Installation manual (EN/UK)
Modore 75H
Warning:
The combustion chamber of this stove should only be opened and serviced
by a registered gas installer.
Leave these instructions as manual with the device

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Modore 75H and is the answer not in the manual?

Questions and answers

Summary of Contents for Element Modore 75H

  • Page 1 Installation manual (EN/UK) Modore 75H Warning: The combustion chamber of this stove should only be opened and serviced by a registered gas installer. Leave these instructions as manual with the device...
  • Page 3: Table Of Contents

    17 Dimensional drawings ������������������������������������������������������������������20 4 Installation requirements �������������������������������������������������������������������6 17�1 Control hatch, BDLE4 ����������������������������������������������������������������20 4�1 Distance between combustible materials ����������������������������������������6 17�2 Modore 75H ��������������������������������������������������������������������������������21 4.2 Important points - fireplace �������������������������������������������������������������6 18 Parts Ontop flue material ���������������������������������������������������������������22 4�3 Important points gas connection �����������������������������������������������������6 19 Warranty conditions �����������������������������������������������������������������������28...
  • Page 4: Ce Declaration �����������������������������������������������������������������������������������4 12�1 Location At Roof Outlet

    This unit is designed for use with natural gas or LPG� Product: gas decorative heating appliance However, each unit is only suitable for the type of gas Models: Modore 75H E4-19 that is specified at the time of the purchase. Applicable EC-directives: 90/396/EEC...
  • Page 5: Remote Control With Full Electronic Ignition

    InstallatIon manual 3 Remote control with full electronic ignition 3.1.3 Switching off the fireplace The unit is operated using a remote control (fig. 1). The You switch off the fireplace by pressing the on/off button, ignition, regulating the flame height and switching off is this also turns off the pilot light! done using the remote control, operating a receiver (fig.
  • Page 6: Installation Requirements �������������������������������������������������������������������6 17�1 Control Hatch, Bdle4

    InstallatIon manual 4 Installation requirements This warranty is void if the apparatus is installed (fully or partly) with other materials than with the described This device was developed, tested and approved in above� accordance with the applicable standards for use, the 5 Preparation and installation instructions performance and safety of the product�...
  • Page 7: 5�3 Assembly And Placement Of Discharge Material

    InstallatIon manual 5.3 Assembly and placement of discharge material The combined supply and discharge can go both through the sides (C11) and the roof (C31)� Verify that the desired outlet position complies with local regulations regarding pollution and ventilation openings� (see page 12 and 13) For the proper functioning, the mouth must be at least 0�5 m away from:...
  • Page 8: Glass Removal

    InstallatIon manual 7 Glass removal Before you start: Prepare a safe place to store the glass plate and use the suction cup to remove the glass� Take the following steps to remove the glass: Remove the edge strips 1, 2 and 3. fig. 7.1, Position the suction cup on the glass sheet.
  • Page 9: Installing The Decorative Material

    InstallatIon manual 8 Installing the decorative material 9 Check installation and first use Make sure that the grid is placed firmly at the bottom Remove the glass sheet from the appliance if necessary of the burner chamber and that the long groove in the and use the pre-pressure measuring nipple on the gas middle of the grid lies in one line parallel with the burner regulator to bleed the gas pipe! fig 9.1 and 9.2.
  • Page 10: Important Points Installation

    InstallatIon manual 10 Important points installation 11.2 Main chimney rules. 11.2.1 Determining the chimney diameter To guarantee fire safety around flue material, a casing is necessary� Use heat resistant sheet materials� The main rule is that the chimney must always be Do not insulate a vent shaft, it must be ventilated! so that 200/130 in diameter�...
  • Page 11: 11�2�6 Flue Gas Restrictor

    InstallatIon manual 11.2.6 Flue gas restrictor Take care with curves! Curves give extra resistance in the system and should therefore be included in the TVP and THP. A limiter of 35 mm is mounted as standard in the combustion chamber� This is mounted in addition to the We have two kinds of curves, being: flue gas opening.
  • Page 12: 11�2�7 Calculation Table Horizontal Outlet Pipe Diameter 200/130

    InstallatIon manual 11.2.7 Calculation table horizontal outlet pipe diameter 200/130...
  • Page 13: 11�2�8 Calculation Table Vertical Outlet Pipe Diameter 200/130

    InstallatIon manual 11.2.8 Calculation table vertical outlet pipe diameter 200/130...
  • Page 14: Outlet Location

    InstallatIon manual 12 Outlet location Dimensions Position at end Distance (mm) Directly beneath an opening, ventilation brick, open window etc� Above an opening, ventilation brick, open window etc� Next to an opening, ventilation brick, open window etc� Under gutters or drainage pipes Under roof edges Under balconies or roofs of open garages From a vertical drainage pipe...
  • Page 15 InstallatIon manual 12.1 Location at roof outlet “Distance” = minimum distance required to position the outlet to prevent negative effects involving: A� A ventilation opening of a used room, toilet or bathroom B. Hot air supply, like the supply flowing through a room in use. C�...
  • Page 16 InstallatIon manual 13 Technical data The model tag indicates for which gas type, gas pressure and for which country this unit is intended� The model tag is attached to a chain� It must stay attached to the chain NB: Check to ensure the device is suitable for the local gas type and gas pressure. Natural gas: United Kingdom : 12HG20@20 mbar...
  • Page 17: 14�2 Maintenance Instructions For Installer

    InstallatIon manual 14 Instructions for use 14.3 Anti-reflective glass We advise you to have it checked annually by a qualified Anti-reflective glass is polished ceramic glass to which specialist in order to guarantee safe use and a long service 10 layers of metal oxide coating was applied� The life, thickness of the coating is checked to the nanometre to garanderen,...
  • Page 18 InstallatIon manual 15 Emergency repairs You will find an overview of the possible cause and solutions below. Problem Possible Cause Solution A� No transmission 1� The (new) communication 1� Hold the reset button of the receiver (motor not running) code between receiver and pushed in until you hear 2 beeps�...
  • Page 19 InstallatIon manual Problem Possible Cause Solution F� Electronics continue to spark 1. Damaged receiver. 1. Replace the receiver and confirm the code while pilot light is burning G� Pilot light is burning but 1� Thermocouple is not working� 1�1 Measure the voltage, using a digital multi-meter solenoid valve closes after app�...
  • Page 20: Dimensional Drawings

    InstallatIon manual 16 Packaging materials The packaging of the appliance is recyclable� The following can be used: • Cardboard • CFC-free foam (soft) • Wood • Plastic • Paper These materials must be disposed of in a responsible manner and in accordance with the official regulations Batteries should be disposed of as chemical waste�...
  • Page 21: 17�2 Modore 75H

    InstallatIon manual 17.2 Modore 75H...
  • Page 22 InstallatIon manual 18 Parts Ontop flue material On the following pages you will find a description of the components that can be used with the installation with the closed combustion system of this unit� The part number in the table refers to the number of the part on the following pages� This number is also the number that is used to designate components in the proposed installation schedules�...
  • Page 23 InstallatIon manual...
  • Page 24 InstallatIon manual...
  • Page 25 InstallatIon manual...
  • Page 26 InstallatIon manual...
  • Page 27 InstallatIon manual...
  • Page 28: Warranty Conditions

    InstallatIon manual 19 Warranty conditions The warranty is not applicable in the following cases: If there are malfunctions that you cannot solve using the 1) If the above points have not been met or where only fault finder on pag 20, please contact your installer or partially met�...
  • Page 32 Element4 B.V. Paxtonstraat 23 8013 RP Zwolle The Netherlands December 2015...
