Premium Design Phone with Touchscreen
Thank you for purchasing a Panasonic product.
Please read this document before using the unit and save it for future reference.
For detailed information about the features of your phone system, refer to the
Operating Instructions, which is available by tapping
visiting the support page for this product at the address below.
http://www.panasonic.net/pcc/support/tel/sdect
To use this unit in your country, first change the unit's region setting to match
your country (page 23).
(For Czech and Slovakia)
This cordless telephone is possible to use according to General licence No.:
VO-R/8/08.2005-23 (for Czech), VPR-7/2001 (for Slovakia).
Quick Guide
KX-PRX150FX
Model No.
in the home screen or by
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic KX-PRX150FX
Summary of Contents for Panasonic KX-PRX150FX
-
Page 1: Quick Guide
Premium Design Phone with Touchscreen KX-PRX150FX Model No. Thank you for purchasing a Panasonic product. Please read this document before using the unit and save it for future reference. For detailed information about the features of your phone system, refer to the... -
Page 2: Accessory Information
KX-A405 Key finder KX-TGA20FX Contact Panasonic or the authorised sales department listed on the back cover for the headset available in your area. You can register up to 4 optional key finders to your phone system. By registering a key finder to the base unit and then attaching the key finder to an easily misplaced item, such as your house or car keys, you can use your handset to find the item. -
Page 3: Expanding Your Phone System
R For use in other countries, please contact your equipment supplier. Declaration of Conformity: R Panasonic System Networks Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. - Page 4 R Google and Android are trademarks of Google Inc. ® R The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. R Wi-Fi ® is a registered mark of the Wi-Fi Alliance.
-
Page 5: For Your Safety
Important Information such devices to malfunction resulting in an accident. For your safety R Do not allow the AC adaptor or telephone line cord to be excessively pulled, bent or To prevent severe injury and loss of life/ placed under heavy objects. property, read this section carefully before R Keep all accessories, including the SIM using the product to ensure proper and safe... -
Page 6: Installation And Location
Important Information information, consult the manufacturer of GSM features operate between 880 MHz your vehicle or its equipment. and 1.88 GHz with a peak transmission R Turn the product off when boarding an power of 2 W. aeroplane. Await instructions from flight W-CDMA features operate between staff regarding the use of electronic devices 880 MHz and 2.17 GHz with a peak... -
Page 7: Important Safety Instructions
Base unit location/avoiding noise R Charge the battery in accordance with the The base unit and other compatible Panasonic instructions and limitations specified in this units use radio waves to communicate with manual. -
Page 8: Information For Users On Collection And Disposal Of Old Equipment And Used Batteries
Important Information R Operating the product near electrical Information for Users on Collection appliances may cause interference. Move and Disposal of Old Equipment and away from the electrical appliances. used Batteries Routine care R Wipe the outer surface of the product with a soft moist cloth. -
Page 9: Note For The Battery Symbol
This model meets international guidelines and rights shall remain with Panasonic or its EU requirements for exposure to radio waves. licensor. Your wireless device is a radio transmitter and Licence: receiver. -
Page 10: Specifications
R Wi-Fi: 2.4 GHz to 2.4835 GHz Panasonic System Networks Co., Ltd. R GSM900/W-CDMA900 (“Panasonic”) shall not be liable for loss of Uplink: 880 MHz to 915 MHz data or other incidental or consequential Downlink: 925 MHz to 960 MHz... - Page 11 Important Information R W-CDMA connection only: up to 290 hours Power source R Base unit: 220–240 V AC, 50/60 Hz R Charger: 100–240 V AC, 50/60 Hz Base unit power consumption R Standby: approx. 0.4 W R Maximum: approx. 0.8 W Charger power consumption R Standby: approx.
-
Page 12: Preparing The Base Unit
E DSL/ADSL service users only: Connect your DSL/ADSL filter (not supplied). Note: R Use only the supplied Panasonic AC adaptor PNLV226CE. R Use only the supplied telephone line cord. Preparing the charger A Insert the AC adaptor plug firmly into the charger. - Page 13 Getting Started Important: R When removing the battery, make sure you turn off the handset first. R To avoid loss of data or malfunction, do not damage, carelessly handle, or short-circuit the gold-coloured contacts of the SIM card or microSD card. Remove the handset’s cover.
-
Page 14: Charging The Handset
Getting Started Attach the cover. Charging the handset Charge the handset for about 5 hours before initial use. The charge indicator (A) lights while the handset is charging and turns off when the handset is fully charged. Important: R If the handset is placed into the charger while talking on the phone, the call is not disconnected. -
Page 15: Information About Power And Charging
Battery use and replacement R Use only the supplied battery. For replacement, use only the Panasonic rechargeable battery noted on page 2. R The battery might swell when its life is close to an end. This is dependent on the usage conditions and is not a problem. -
Page 16: Getting To Know Your Phone System
Getting Started Getting to know your phone system Handset overview A Headset jack B Power button C Charge indicator D Volume button ( E Touchscreen F Micro USB jack G Front camera H Receiver (menu) button J Home button (back) button L Microphone M Camera flash N Rear camera... -
Page 17: Turning The Handset On And Off
Getting Started Base unit overview N (locator) button Handsets registered to the base unit will ring when you press this button. This can be useful when you want to locate a misplaced handset. Turning the handset on and off To turn the handset on, press and hold the power button on the top of the handset. If the lock screen appears, unlock the screen (page 17). -
Page 18: Setting Up A Google Account
Getting Started Select the desired automatic time adjustment setting. R If you select [Use network provided time], a mobile network or Internet connection is needed for the handset to adjust its date and time setting automatically. Select the desired mobile network type (displayed only if a SIM card is installed). Add or create a Google™... -
Page 19: Landline App
Getting Started (back) button: Returns to the previous screen or closes the current dialogue box, menu, on-screen keyboard, etc. Note: R The buttons are displayed in most screens. They appear at the bottom of the handset next to the home button, and turn off if you do not use them for a while. To display the buttons after they have turned off, simply touch the area of the handset where they would normally be displayed. -
Page 20: Answering Calls
Getting Started Answering calls When a call is being received, tap and drag it to to end the call. Receiver or speaker volume Press the volume button up ( ) and down ( ) repeatedly during a call. Using the call logs The handset and base unit each log your calls, allowing you to check a record of your calls. -
Page 21: Ringtones And Audio Settings
Getting Started Tap [Call log list]. R The handset connects to the base unit. next to the phone number or person you want to call. Select the phone line you want to use to make the call. When finished, tap to end the call. -
Page 22: Answering System Features
Getting Started When finished, tap to end the call. Answering system features Turning the answering system on and off The answering system is already turned on at the time of purchase. Tap [Landline] in the home screen or app list. Tap [Answering system]. -
Page 23: Region Setting
Getting Started Region setting This setting resets certain base unit settings to their default values based on the region you select. Tap [Landline] in the home screen or app list. Tap [Landline settings] ® [Initial settings]. R The handset connects to the base unit. Tap [Country]. - Page 24 Getting Started → Tap [Set time], select the desired time, and then tap [Set].
-
Page 25: Troubleshooting
Getting Started Troubleshooting Problem Cause and/or solution R The handset is too far from the base unit. Move closer. is displayed. R The base unit’s AC adaptor is not properly connected. Reconnect AC adaptor to the base unit. R The handset is not registered to the base unit. Register it. See the Operating Instructions for more information (download information is on page 1). -
Page 26: Caller Id Support
Getting Started Caller ID support The base unit is Caller ID compatible. Caller ID is a service provided by your landline phone service provider which may require a subscription. Contact your landline phone service provider for details and availability. - Page 27 Notes...
- Page 28 B-dul Preciziei, Nr. 24, West Gate Park, Clădirea H3, Etaj 2, Sector 6, București, 062204, Romania Telefon: +40.21.316.31.61 Fax: +40.21.316.04.46 e-mail: suport.clienti@eu.panasonic.com web: www.panasonic.ro 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan © Panasonic System Networks Co., Ltd. 2013 *PNQW3785YA* *PNQW3785YA* PNQW3785YA CC1013YK1103 (E)
