QUICK SET UP GUIDE

STEP

Locating the components

Front speaker

(SB-HDV600)

Left and right speakers are exactly the same.

SC-HDV600

DVD player

(SL-HDV600)

Cassette deck

(RS-HDA800)

Check and identify the accessories shown at the top of steps 3 to 5

before connection.

For operation and other details with regard to each

component, please refer to the operating instructions.

Tuner

(ST-HDV600)

Amplifier

(SE-HDV600)

Front speaker

(SB-HDV600)

Table of Contents

Do you have a question about the SC-HDV600 and is the answer not in the manual?

Page 1 QUICK SET UP GUIDE SC-HDV600 For operation and other details with regard to each component, please refer to the operating instructions. STEP Locating the components DVD player Tuner (SL-HDV600) (ST-HDV600) Front speaker Cassette deck Amplifier Front speaker (SB-HDV600) (RS-HDA800) (SE-HDV600) (SB-HDV600) Left and right speakers are exactly the same.
Page 2 STEP Flat Disconnecting cables STEP Connect the cables to the terminals of the same color. On the speakers Speaker Gray cables Blue Black L (Left) R (Right) HF : High Frequency LF : Low Frequency Incorrect connection can damage unit. On the amplifier Be sure to connect only positive (red or gray) wires to...
Page 3 STEP ( a page 47 in the operating instructions) AM loop antenna Attach to a wall (using tape) facing in the direction of best reception. FM indoor antenna Place on a flat surface Surround Disconnecting cable Press down STEP ( a page 11 in the operating instructions) Video TV (not included) connection...
Page 4: Remote Control Operation
Check installation by playing a DVD Turn on the TV and select the appropriate video input on the TV. Turn on the unit. [ ; OPEN/CLOSE] Press and load a disc. To stop play [ q ] Press Adjust the volume. The disc tray closes automatically.
