Summary of Contents for R-BOX PEARL
- Page 1 R-Box User’s Guide...
-
Page 2: Safety Information
1. Safety Information Please read and understand all instructions before using this product. If the damage is caused by failure to follow the instructions, your warranty does not apply. 1.1 Warning To reduce the risk of electric shock, DO NOT remove the cover (or back). DO NOT attempt to repair the product –... -
Page 3: Handling Cautions
1.2.3 Heed all warnings. 1.2.4 Follow all instructions. 1.2.5 DO NOT use this apparatus near water. 1.2.6 DO NOT clean with any chemical detergent. Clean only with a dry cloth. 1.2.7 DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions. 1.2.8 DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat. -
Page 4: Package Contents
Optional Remote Controller 2.4G wireless Remote Controller USB wire/wireless Mouse & Keyboard Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V, 2A 2.2 R-Box Features Quad Core A53, 2.0GHz, 1GB RAM, 8GB EMMC ROM Powered by Android 5.1 OS ... -
Page 5: Exterior Features
2.3 Exterior Features Page 4 of 26... -
Page 6: Remote Controller
2.4 Remote Controller [01] Power [02] Mode [03] Mute [04] Up [05] Left [06] Right [15] Page up [07] Down [16] Volume - [08] Enter [17] Page down [09] Exit [10] Home [11] Switch [12] Menu [13] Volume + [14] Notification Page 5 of 26... -
Page 7: Initial Setup And Connections
If using Ethernet network connectivity, plug the R-Box via Ethernet cable into your network router/modem, or alternately you may use Wi-Fi connectivity. To configure the settings, connect your R-Box to a monitor and a USB mouse is recommended as well to expedite the configuration. -
Page 8: Basic Navigation
2.6 Basic Navigation To navigate on the R-Box, you can use the remote control device, or a USB mouse. With the remote control, use the navigation arrows (4 directions), OK, EXIT, and Menu keys to select the options. The option selected will be highlighted and confirmed by pressing the OK key. The EXIT key is the backwards looping arrow button on the bottom left side of the navigation arrow control. -
Page 9: Desktop Screen
The desktop screen then appears with various application and system icons present: Configure Essential Settings This User’s Guide documents the essential functions you will typically need to utilize the R-Box to play music. To configure your settings, click on the Settings Icon:... -
Page 10: Ethernet Configuration
Click on the Network icon (from the previous picture), then click Ethernet, then click on Ethernet Device, then “ON” and the R-Box will connect to the network automatically using DHCP if your network supports DHCP. Or alternately you can configure a static IP number and other related network settings. -
Page 11: Wifi Configuration
3.3 Bluetooth To have your R-Box connect to a wireless speaker system, from Desktop Screen go into Settings, then click “More Settings” twice. Then click the Bluetooth option and turn it on by sliding the toggle switch in the screen’s... -
Page 12: Sound & Notification
After doing this, the R-Box will be visible to nearby devices that support Bluetooth connectivity. 3.4 Sound & notification To configure the volume and other sound-related settings, from the Desktop screen click on Settings, then “More Settings”... - Page 13 4. R-Box App To commence playing music, from the desktop click on the R-Box Pearl icon: The R-Box app will open up to its Main Screen. R-Box Main Screen Page 12 of 26...
- Page 14 Device ID that is assigned to your R-Box. You can find your R-Box’s Device ID in two different ways, by either looking at the sticker on the bottom of your R-Box, or by looking at the Settings for the R-Box app.
-
Page 15: Music Playback
R-Box Settings Screen’s Security Token option. If you have a security token configured for your user account, you must also make sure to configure it in the R-Box. Failure to do so will cause the R-Box to not authenticate properly and you will not be able to play music until you either enter the Security Token into the R-Box settings, or alternately clear the Security Token from the Player Settings screen in your User Account’s... - Page 16 To access the Custom Schedules feature, click on ACCOUNT on the top menu of the RadioSparx site, then click on CUSTOM SCHEDULES. A list of any custom schedules that exist for your User Account will appear: To add a new schedule, click the ADD SCHEDULE button at the top right of the table. The following screen appears: Page 15 of 26...
- Page 17 By default, a newly added schedule will play in live-streaming mode, meaning that as each new track plays on the R-Box, it is actually being downloaded from the RadioSparx server in real-time. The Store-and-Forward mode is an advanced configuration which will be covered in more detail below.
- Page 18 5.2 Events Control What Music Will Play To configure exactly which music will play, click on the +ADD EVENT button. This will bring up a new screen, the “Add Event to Schedule” screen where you can configure the stations that will play for the event: For each event you add to a custom schedule, you can configure the following settings: 1.
- Page 19 Stop Event causes a countdown. Or alternately you can have the reboot trigger in the morning after the end of a countdown, or at any time in the middle of the night, to keep the R-Box’s operations “refreshed” each night.
- Page 20 Easy Listening Classical Lite Oxygen Classical + Jazz Pop Easy Listening Chillout Then a bit later in the day, coming up on lunch time, you can pick up the pace with stations such as these: Pop Vocals ...
- Page 21 Advanced Features settings include the following: Start Date – This field lets you configure an automatic start date for when this schedule should take effect. There’s a corresponding End Date field. Play Schedule on Which Days – These settings let you configure to have this schedule play only on ...
- Page 22 Playback Mode – This option lets you choose either Streaming in Real-Time or Store-and-Forward. Streaming in Real-Time – This mode causes the R-Box device to download and play each new track from the web server in real time. This mode works great as long as you have plenty of spare network bandwidth and a reliable internet connection that is up during the daytime without fail.
-
Page 23: Troubleshooting (Faq)
Make sure to click SAVE CHANGES if you make any changes on the Schedule Settings screen to lock in your changes. By default, the R-Box plays in live-streaming mode (i.e. Streaming in Real-Time) and will play the Pop Vocal station until you configure some events for your custom schedule and change its settings to operate in Store-and-Forward mode. -
Page 24: Specifications
8. Repairs If you contact us to repair your R-Box Pearl, we will first attempt to remote control the device to troubleshoot any common problems. If that is not successful, or the device won’t boot up, or we cannot remote control it successfully, you will generally need to ship the device back to us for closer review. - Page 25 DC Input 5.0V-2A SD Slot Max: 32G Video Output HDMI/CVBS Audio Output HDMI/RCA IR receiver RJ45 10/100M Ethernet interface WiFi IEEE 802.11 B/G/N AC 2.4G（5.8G Optional） Bluetooth Audio Decoder Low power Media CPU with DSP audio processing Supports MP3,AAC,WMA,RM,FLAC,Ogg and programmable with7.1/ 5.1 down-mixing Video/Picture H.265 HEVC MP-10@L5.0 up to 4K X 2K@60fps...
-
Page 26: Trademark Notices
HDMI Licensing LLC in United States and other countries. Navarr Enterprises Inc Navarr Enterprises Inc, R-Box, R-Box Pearl, and RadioSparx are trademarks or registered trademarks of Navarr Enterprises Inc. The R-Box Pearl application software may not be disassembled, reverse engineered, hacked, or otherwise improperly exploited, and may not be extracted from the R-Box hardware device for use with other unapproved hardware.
