Summary of Contents for Renau NEA SMART
- Page 1 NEA SMART ROOM CONTROL UNIT Installation and operating manual...
-
Page 2: Table Of Contents
CONTENT Safety More information on the NEA Smart control system and all Used symbols documentation available for download can be found at www.rehau.uk/neafamily Intended use General safety warnings Versions Technical data Compliance Installation Box contents Installation Operation Overview and display Commissioning (incl. -
Page 3: Safety
Intended use The NEA Smart room control unit (in the following abbreviated as room control unit) is a room control unit for the base station NEA Smart 24 The device is intended to - control of the NEA Smart base station 24 V. -
Page 4: Versions
10 to 28 °C the compliance of which is the responsibility of the installer. Target temp. resolution 0.25 K Actual temp. measuring 0 to 40°C (int. sensor) range Measuring accuracy of internal NTC ±0.3 K Tab. 2-1 Technical data NEA Smart room control unit... -
Page 5: Installation
3 INSTALLATION Box contents Installation ~ 30 cm ~150 cm Fig. 3-1 Box contents Fig. 3-2 Information on the mounting location of the room control unit... - Page 6 Ø 3,5 mm Fuse Pairing Power Pump Boiler Cool Master Fig. 3-3 Installation and connection of the room control unit...
-
Page 7: Operation
2. Activate the pairing function at the base station for the desired At the base station, the heating zone connected to this room control heating zone (see manual base station NEA Smart 24 V). unit changes status for 1 minute, in other words switches on or off 3. -
Page 8: Troubleshooting, Cleaning And Decommissioning
5 TROUBLESHOOTING, CLEANING AND DECOMMISSIONING Troubleshooting Cleaning The error signalling is carried out via the heating zones LED on the Only use a dry and solvent-free, soft cloth for cleaning. base station assigned to the room control unit. Disposal LED base station Meaning Solution The room control unit must not be disposed with domestic...
