Summary of Contents for rotowash R20
- Page 1 CAUTION Do not operate this appliance before reading the instructions INSTRUCTION MANUAL Floor Cleaning Machine...
- Page 2 Version 10/2009...
- Page 3 Use Only with the machine supplied, or in the parts list specified brushes. The use of other brushes can compromise security. When transporting the ROTOWASH in a lift ensure that the handle is placed in such a position to avoid a possible jamming against the lift walls.
- Page 4 WHAT IT IS This instruction manual is for following cleaning machines: is an indicator of the working width. X = 20 stands for 200 mm working width Y X Y X = 30 stands for 300 mm working width X = 45 stands for 440 mm working width X = 60 stands for 600 mm working width indicator stands for: Handle:...
- Page 5 ASSEMBLY Installing the stick handle for L, T Place the handle (1) on the plastic handle connector on the fork and push connecting pin (2) through to locate handle. Installing the loop handle for A, B, S Place the loop handle on the aluminium handle connectors and fit spring loaded bolts to locate.
- Page 6 Fitting the cables A, S Fit the electrical plug from machine into the correct socket. Mains supply Machine motor socket Fit the electrical plugs from machine and pump into the correct sockets. Spraying unit pump socket Spraying Machine motor socket unit Machine Pump...
- Page 7 WORKING WITH ROTOWASH Cleaning liquid Use only cleaning liquids which are recommended by a cleaning expert. If in doubt consult your ROTOWASH dealer. Tray capacity: 20 1,0 Litre (2 pints) 30 1,5 Litre (3 pints) 45 2,2 Litre (4 pints)
- Page 8 Setting brush pressure The brush pressure can be adjusted by turning the adjustment knob. Position 1 is for hard floors, Position 2 is for carpets. Position 1 Position 2 Manner of use Move the machine in a forward direction. By pushing the red button near the handgrip of the stick handle, or the pump activating lever on the loop handle,...
- Page 9 WORKING WITH ROTOWASH Attention: First remove mains plug from socket Emptying the soiled water Lift out wastewater tray. When refitting wastewater tray ensure that springs are pressing on the tray. Attention Avoid touching the edge of the stripperblade. It may cause injury.
- Page 10 If you need to transport the machine without carrying it, push the handle slightly forward and lift it (1). Then pull the handle back. This will enable you to push the ROTOWASH along on its transport rollers. For long transportation use the optional ROTOCART. Ask your dealer for information.
- Page 11 Stick handle 14. Pump activating lever Bowdencontrol 15. Combined On/Off switch and Cable safety Thermo relay Cable holder 16. Socket „Pump” 17. Socket „Motor” Tank 3l Connecting pin 18. Tank 7l Fork 19. Spring loaded bolt Clean water tray 20. Water valve Adjustment knob 21.
-
Page 13: Technical Data
TECHNICAL DATA >> WARNING – THIS APPLIANCE MUST BE EARTHED <<... - Page 14 NON-FOAMING detergents having a pH value ranging from 6.5 to 9.5. The floor cleaning machine from Rotowash is intended for wet and dry cleaning of hard floors, structural floors and textile floors. Prerequisite for the success is the right choose of the brushes.
