Summary of Contents for SUPERNOVA FD-D3
- Page 1 Baby Unit Parent Unit...
- Page 2 Congratulations! Thank you for choosing the SuperNOVA Digital Babycall, model FD-D3. This is a quality product developed for optimal safety and comfort, based on new, sophisticated technology. An electronic babysitter can never replace parental care for a child, but it is a practical aid that will ease your worries. Please read this user manual carefully and keep it in a safe place.
- Page 3 Parent Unit Telescopic antenna ..should be pulled out when unit in use B2 Light indicator .... blinks every six seconds on standby; blinks rapidly when activated B3 On/Off button ..... switches power on or off B4 LCD display ....shows all information about the unit's status B5 L key ......
- Page 4 Note: If the battery symbol blinks in one unit and you hear an alarm every 5 –10 seconds, this means the battery must be recharged to continue operation. The parent unit also gives a signal to indicate a weak baby unit battery but the sound is softer.
- Page 5 When you press the R key on the parent unit you disable all coding for three seconds. This enables you to listen to the channel if there is any traffic on it. Alarm tones can be heard under the following circumstances: From the Baby Unit: The battery is discharged weak beep every 5-10 seconds...
- Page 6 When your SuperNOVA is on standby you will not be disturbed by other baby monitors unless they are adjusted to the same code and the same channel, in contrast to other brands.
- Page 7 TROUBLESHOOTING CHART Problem Possible cause Solution The indicator (2) does not light up. The unit is not switched on. Press the On/Off button (3). The display goes out shortly after the The batteries are discharged. Recharge the batteries while the unit is unit is switched on.
