  • Page 1 Grundig SAT Systems SATELLITE HEADEND STATION STC 316 ENGLISH...

  • Page 2: Table Of Contents

    Connection example 3: analog and digital processing of broadcasts from one satellite Connection example 4: linking two headend stations STC 316 Technical Data SAT Cassettes Overview Service (at the end of this user manual)

  • Page 3: General

    GENERAL ____________________________________________________________________________ Scope of delivery 1 headend station STC 316 with installation material 1 input splitter 1 mains cable 1 user manual The headend station STC 316 This headend station is a modular system for the reception and conversion of...

  • Page 4: At A Glance

    AT A GLANCE ________________________________________________________________ STC 316 GAE 4700 STC 316 220-240V~ 50/60Hz Made in Germany OUTPUT OUTPUT INPUT 950 - 2150 MHz OUTPUT OUTPUT...

  • Page 5: Components And Connections

    AT A GLANCE ___________________________________________________________________________ Components and connectors Ventilation slots. Removable door. Door key. Type plate. 8 SAT cassette plug-in locations. 2 removable holders for the SAT input splitter. SAT input splitter: inputs A and B (female F-connectors), 9 outputs per input (female F-connectors), passage loss: typ.

  • Page 6: Installation, Fixation

    +50° Important! It is absolutely necessary to make sure that the ambient and -10° operating temperatures do neither fall below nor exceed the STC 316 ° ° admissible range (-10 C to +50 C) specified by the manufac- turer.

  • Page 7: Installation, Aeration

    INSTALLATION, AERATION _____________________________ Installation into rack systems Important: Before installing the headend station into a rack, the two fixation rails on the back of the station must be removed. Remove the power supply/control unit and the hybrid amplifier from the BU102 BU103 BU104...

  • Page 8: Connection

    CONNECTION _______________________________________________________________ Connection Caution: Before inserting new or replacing existing cassettes, it is absolutely necessary to disconnect the power supply plug! OUTPUT INPUT 950 - 2150 MHz OUTPUT When installing the headend station pay attention to the correct earth connec- tion according to the valid VDE regulations 0855 before putting the station into operation.

  • Page 9: Functional Description

    FUNCTIONAL DESCRIPTION ___________________________ Functional description of the headend station After connecting the headend station to the mains voltage, all cassettes (max. 8) are supplied with the required operating voltages by a switched-mode power supply unit via the plug-in connectors on the contact rail. The passive input splitter provides highest flexibility when selecting signals with horizontal or vertical polarization.

  • Page 10: Connection Examples

    Connection example 1: analog processing of broadcasts from one satellite as well as of terrestrial TV and FM broadcasts ASTRA 19.2° Ost oder EUTELSAT 13° Ost Quattro LNC (e.g. GRUNDIG (z.B. GRUNDIG UNI Q 2) OUTPUT OUTPUT INPUT 950 - 2150 MHz...

  • Page 11: Connection Example 4

    Lowband H/V Grundig Grundig Multischalter Multiswitch SVT 2-5 SVT 2-5 Highband H/V High Band Connection example 4: linking two headend stations STC 316 OUTPUT OUTPUT INPUT INPUT 950 - 2150 MHz 950 - 2150 MHz OUTPUT OUTPUT max. Output Level max.

  • Page 12: Technical Data

    TECHNICAL DATA _______________________________________________________ This product conforms with the requirements of the 73/23/EC and 89/336/EC guidelines of the European Council. The standards EN 50083-2, EN 50083-2/A1, EN 50083-1 and EN 60065 required for the CE certification are kept to. Cassettes (boxes): 8 plug-in locations Input frequency ranges: –...

  • Page 13: Sat Cassettes Overview

    SAT CASSETTES OVERVIEW ____________________________ SAT cassettes overview for this headend station An explanation of cassette programming is to be found in the operating instruc- tions of the respective cassette. It follows a list of the currently available cassettes with the most important data. The frequency assignment to the given channels is to be found in the chapter ”Channel/Frequency assignment”...
  • Page 14 SAT CASSETTES OVERVIEW ____________________________________________________ Cassette type Input range Output range Channel of cassette of cassette standard For terrestrial reception (OIRT) HRM 381 R1-R12, s2-s38, C21-C69 R1-R5, s2-s21, R6-R12 OIRT 49.75 MHz - 855.25 MHz 49.75 MHz - 351.25 MHz HRM 383 R1-R12, s2-s38, C21-C69 R6-R12, s2-s21 OIRT...
  • Page 15 FRANÇAIS...
