IceZone X Owner's Manual
®
Automated Ice Machine Sanitation System
IceZone X inhibits the growth of mold, slime, and other contamination
®
in ice machines, extending the life of the ice maker and lowering maintenance
costs. IceZone ® X delivers cleaner and healthier ice.

IMPORTANT!

Only qualified technicians should install this product
Install in accordance with relevant building codes
Read instructions carefully including safety warnings
PROTECT EYES FROM UV LIGHT TURN
OFF UNIT OR DISCONNECT BEFORE
© BioZone Scientific International

WARNING

SERVICING
IceZone X COMPONENTS
®
A.
Service Cover
B.
Service Cover Screw
C.
Lamp Connector
D.
Status Indicator
E.
Lamp Life Reset Port
F.
Lamp Seal
G.
Power Connection

SPECIFICATIONS

Dimensions:
11.93 in (L) x 4.25 in (W) x 2.05 in (H)
Electrical: Input: 100-240 V, 50/60 Hz
Output: 12 V, 0.8 A (transformer rated to 2.0 A)
Includes 8 ft cord and plug (2.5 m)
Ambient Air: Operating temperature range: 40° F to 104° F (5° C to 40° C)
0-90% non-condensing humidity
Water Supply:
No requirements (IceZone
Certifications:
HACCP, NSF (standard 169), UL (standards 507, 935), CE, RoHS WEEE, FCC part 15
US EPA Est No. 08795-FL-001
H. Main Body
I. UV-Lamp
J.
Plasma Ports
K. 12V DC 25W Power Adapter
L. Mounting Screws / Rivets
M. PlasmaProtect ® Tubing
N. PlasmaProtect ® Fittings
® is not integrated into the water system)
