Torrans double glider Assembly Instructions Manual

Hide thumbs

Table Of Contents

Your chair seat and back may not resemble the pictures shown in these instructions.

Instructions are for all styles of double gliders. Picture of assembled chair may not look

like the style you have.

Working on a clean padded surface or a lawn is recommended. Avoid concrete as your

assembly area.

DO NOT OVER TIGHTEN! THIS WILL RESULT IN BREAKING THE POWDERCOAT

AND WILL VOID YOUR WARRANTY!

Occasionally, when opening your metal lawn furniture, you may encounter some

slight discoloration. This is caused by moisture in the packaging. You can com-

pare this to the stain in the kitchen sink you get after leaving something metal for

too long. This and many other scuff marks can be easily removed with Chrome

Polish and a soft cloth.

Please CAREFULLY read, understand and follow ALL the steps in these Assembly In-

structions AND Complete Each Step Before Moving On To The Next.

Care and maintenance of your new Glider is quite minimal. The finish is Exterior Grade,

Ultra Violet resistant Powder Coat and it will keep its gloss and smooth appearance for

many years of enjoyment. It is resistant to all non abrasive household cleansers and any

common kitchen product can be used. However, Powder Coat is NOT scratch proof. It

does compare in hardness to the finish of modern automobile paints. Generally a good

bath with a soapy sponge removes all common yard stains. We have found a small appli-

cation of liquid auto wax such as "NU-FINISH" lessens efforts required to remove repeat

stains such as bird droppings and tree sap and increases the gloss of the Powder Coat.

A drop or two of lubricate from time to time will remove squeaks in the nylon bushings of

the Swing Arms.

NOTE: When moving assembled Glider, grasp Main Frame and NOT Seat and Back

Chair assembly of DOUBLE Glider.

Double Glider Assembly Instructions.

Thank you for purchasing your new Torrans Manufacturing

Company's Lawn Glider.

accomplished by one person however, it is advised that

you have a helper during a few of the assembly steps to

lessen the chance of marring the powder coat finish.

Assembly of the Glider can be

Table of Contents

Need help?

Do you have a question about the double glider and is the answer not in the manual?

Questions and answers

Summary of Contents for Torrans double glider

Page 1 Double Glider Assembly Instructions. Thank you for purchasing your new Torrans Manufacturing Company’s Lawn Glider. Assembly of the Glider can be accomplished by one person however, it is advised that you have a helper during a few of the assembly steps to lessen the chance of marring the powder coat finish.
Page 2 Double Glider Parts List 1 set of instructions with tools 4 acorn nuts 4 end caps 4 plastic spacers DG-19 long screws 16 large washers DG-10 short screws 2 side supports- 4 swing arms 1 center support DG-29 lock nuts SG-19 lock nuts...
Page 3 Step 1. Assemble Chair Seats and Backs with hardware as shown in Fig. 1. Place WASHER on SCREW and ensure screw enters from REAR of CHAIR BACK as shown in Fig. 2. Set ALL screws, nuts and washers into place and tighten.
Page 4 Step 3. Locate Two Main Frame parts as shown in Fig. 5. Insert Main Frame Back crossmember with reduced ends into Main Frames. Align mounting holes and secure with long screws, washers and nuts as shown in Fig. 6 . TIGHTEN ALL SCREWS.
Page 5 Chair frame front crossmember attaches to INSIDE FRONT of Chair Frame with screws and washers and is secured with washers and nuts as shown in Fig. 10. DO NOT FULLY TIGHTEN. Insert plastic end caps as shown in Fig. 13. Fig.
Page 6 Locate TWO Side Supports as shown in Fig. 13. Place Side Supports over screws in Chair Back as shown in Fig. 14. Ensure Support lands under “U” shaped Cross Member as shown in Fig. 14. Secure with nuts and washers. DO NOT FULLY TIGHTEN. Place screws with washers through mounting holes of “U” shaped crossmember and Side Supports and secure with washers and nuts.
Page 7 NOTE: SWING ARMS HAVE SLIGHT BEND ON EACH END. When Swing Arms are attached to Main Frame they MUST be in CORRECT position facing AWAY from main frame as shown in Fig. 17 WHEN SCREWS ARE TIGHTENED. Swing Arms are shown INCORRECTLY attached in Fig. 18. THREADS OF SCREWS MUST BE ON OUTSIDE OF MAIN FRAME.
