SMART IP24
825.209
Bedienungsanleitung
Elektrischer Infrarot-Heizstrahler
D/A/CH
Seite 3 bis 14
Instruction manual
Infrared electric heater
GB/UK
from page 15 to 26
Mode d'emploi
Chauffage électrique à infrarouge
F/B/CH
de page 27 à page 38
Instrucciones de servicio
Radiador eléctrico por infrarrojos
E
de la página 39 a la 50
Gebruiksaanwijzing
Elektrisch infrarood verwarmingsapparaat
NL/B
blz. 51 t/m 62
V1/0112
- 1 -
Advertisement
Table of Contents
Summary of Contents for Bartscher SMART IP24
- Page 1 SMART IP24 825.209 Bedienungsanleitung Elektrischer Infrarot-Heizstrahler D/A/CH Seite 3 bis 14 Instruction manual Infrared electric heater GB/UK from page 15 to 26 Mode d’emploi Chauffage électrique à infrarouge F/B/CH de page 27 à page 38 Instrucciones de servicio Radiador eléctrico por infrarrojos de la página 39 a la 50...
-
Page 2: Table Of Contents
5.3 Operating 24-25 6. Cleaning and maintenance 6.1 Safety advice 6.2 Cleaning 6.3 Safety instructions for maintenance 7. Waste disposal Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax: +49 (0) 5258 971-120 - 15 -... -
Page 3: General Information
1. General information 1.1 Information about the instruction manual This instruction manual contains information about the installation, operation and maintenance of the device and should be consulted as an important source of information and reference guide. Awareness of the safety instructions and instructions for use in this manual will ensure the safe and correct use of the device. -
Page 4: Liability And Warrantees
1.3 Liability and Warrantees All the information and instructions in this manual take into account standard safety regulations, current levels of technical engineering as well as the expertise and experience we have developed over the years. The instruction manual was translated with all due care and attention. However, we do not accept liability for any translation errors. -
Page 5: Safety
2. Safety This section provides an overview of all important safety aspects. In addition every chapter provides precise safety advice for the prevention of dangers which are highlighted by the use of the above mentioned symbols. Furthermore, attention should be paid to all pictograms, markers and labels on the device, which must be kept in a permanent state of legibility. -
Page 6: Intended Use
CAUTION! o The device is not intended for use by individuals (including children) with physical or mental disabilities, insufficient experience, and/or insufficient knowledge unless such persons are under the care of a person responsible for their safety or have received instructions regarding appropriate use of the device. -
Page 7: Delivery, Packaging And Storage
3. Transport, packaging and storage 3.1 Delivery check Please check the delivery upon completeness and transport damage immediately after receipt. In case of visible damage do not accept or accept the delivery with reservation only. Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint. Hidden damages should be reclaimed immediately after notice, as claims for damages can only be asserted within the effective period for complaints. -
Page 8: Technical Data
4. Technical data 4.1 Technical specification Infrared electric heater Name SMART IP24 for wall or ceiling mounting 825.209 Article number: Construction: housing and reflectors: aluminum, safety cage: steel Power: 230 V~ 50 Hz 1.5 kW Heating elements: infrared heating tubes... -
Page 9: Installation And Operation
5. Installation and operation 5.1 Safety instructions WARNING! Electrical hazard! The device must only be connected to a properly installed single socket with protective contact. Never yank cord to disconnect from outlet. Cable must not touch any hot parts. • Never touch device with wet or moist hands. -
Page 10: Assembly And Connection
5.2 Assembly and connection CAUTION! Assembly and power hook-up must be performed by qualified personnel. Remember to disconnect device from power before attempting any electrical workings. • Unpack device and remove all packaging material. • Do not place inflammable materials or aerosol sprays near powered device. Fire hazard! •... -
Page 11: Operating
① ③ ② ④ • Drill two holes in the desired location in order to fix the unit to the wall / ceiling, while maintaining the minimum distances given above. • Mount the appropriate pegs and attach the heater with two proper-sized screws in ④... -
Page 12: Cleaning And Maintenance
Used to regulate individual heating settings Used to regulate individual heating settings Used to regulate individual heating settings Bartscher item #: 825.210 6. Cleaning and maintenance 6.1 Safety advice o Before beginning with repair or cleaning works make sure the device has been disconnected from power socket (pull the power plug!!!) and has cooled down (approx. -
Page 13: Safety Instructions For Maintenance
NOTE! For the disposal of the device please consider and act according to the national and local rules and regulations. Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax:...
