O P E R A T I N G I N S T R U C T I O N S
CAUTION The Phase 3 Models Mini Scale Series Mustang is designed for intermediate
to advanced pilots. It is not intended for beginner pilots. It is not a trainer!
Includes 1 Cell 1300mAH
Li-Po Battery and 12V
DC Li-Po Charger!
Phase 3 Models
P.O. Box 402, Texaco Road PO,
New Territories,
Hong Kong
All contents copyright © 2009,
Phase 3 Models. V1.0, August 2009
IMPORTANT Before beginning assembly, please read and understand the warnings
listed on the next page. Failure to read and understand these warnings could lead
to bodily harm and/or injury. The Phase 3 Models Mini Scale Series Mustang is not
intended for those under 14 years of age, unless closely supervised by an adult.
SPeCIFICATIONS AND FeATuReS
Wingspan: 518mm (20-3/8")
l
Length: 483mm (19")
l
Flying Weight: 183g (6.45oz)
l
Almost Ready to Fly - Only Requires Simple Final Assembly
l
Durable Factory-Moulded Foam Airframe
l
2 Micro Servos and Electronic Speed Controller Included
l
Micro Motor, Li-Po Battery and Charger Included
l
Just Add Your Transmitter and Receiver!
l
Page 1
Part Number: PH021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH021 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mustang PH021

  • Page 1 Failure to read and understand these warnings could lead to bodily harm and/or injury. The Phase 3 Models Mini Scale Series Mustang is not intended for those under 14 years of age, unless closely supervised by an adult.

  • Page 2: General Warnings

    FOR YOuR SAFeTY - PLeASe ReAD AND uNDeRSTAND THeSe WARNINGS GeNeRAL WARNINGS LITHIuM POLYMeR (LI-PO) BATTeRY WARNINGS - YOu MuST ReAD THIS Do not fly your aircraft if another model is on the BeFORe CHARGING THe BATTeRY same frequency as you. All instructions, warnings, and cautions must be Never fly your aircraft from the street or at night. followed at all times. Failure to do so can lead to Always fly in an open area free of obstructions.

  • Page 3: Kit Contents

    INTRODuCTION Thank you for purchasing the Phase 3 Models Mini Scale Series Mustang. Before completing the final assembly of your new aircraft, please carefully read through these Operating Instructions in their entirety. Doing so will ensure your success the first time around. As you can see,...

  • Page 4: Step 1: Installing The Propeller

    ASSeMBLING THe MINI SCALe SeRIeS MuSTANG STeP 1: INSTALLING THe PROPeLLeR q Slide the propeller onto the aluminium propeller driver that has been pre-installed on the motor. q Remove the spinner cone from the spinner backplate by first removing the two retaining screws, using a small philips head screwdriver. q Slide the spinner backplate over the propeller and secure with the propeller nut.

  • Page 5: Step 3: Installing Your Receiver

    ASSeMBLING THe MINI SCALe SeRIeS MuSTANG STeP 3: INSTALLING YOuR ReCeIVeR q Connect the aileron extension lead (supplied) to your receiver’s aileron output socket. q Now connect the factory-installed speed controller to your receiver’s throttle output socket and the elevator servo to your receiver’s elevator output socket. q Install your receiver into the fuselage, near the back of the wing saddle opening. Most receivers will fit firmly between the sides of the fuselage. If your receiver is smaller, you can opt to use a piece of double-sided foam tape (not supplied), to secure the receiver in place.
  • Page 6 ASSeMBLING THe MINI SCALe SeRIeS MuSTANG q Slide the front of the fin into the slot in the top of the fuselage, then push the fin down so that it fits firmly against the top of the stabiliser. The back of the fin should also fit firmly into the slot in the back of the fuselage.

  • Page 7: Step 6: Charging The Battery

    To unplug, squeeze the tab on the battery connector and pull the two connectors apart. q After charging the battery, install it in the Mustang, using the hatch on the top of the fuselage. WARNING Always remove the battery from the fuselage when charging.

  • Page 8: Our Guarantee

    FLYING THe MINI SCALe SeRIeS MuSTANG TeSTING THe CONTROL SuRFACeS When checking the operation of the control surfaces, make sure that nothing is in the way of the propeller and it is free to turn. Ensure that hands and clothing are kept away from the propeller. Move the throttle stick to its idle position. Switch on the transmitter. Connect the battery (there is no onboard switch). The model is ready to test. Check that the elevator and aileron servos are centred when the transmitter sticks and trims are at neutral. Check that the ailerons and elevators move in the...
