WATT AGE Super Impress II EP ARF Instructions For Final Assembly

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
The new Wattage Super Impress II EP ARF has pushed the performance envelope for the Impress lineage of model aircraft. This updated design
makes the Super Impress II EP ARF perfect for today's electric model enthusiast.
First, we made it lighter. Our factory has gone back to the drawing board to re-engineer the airframe from cowling to rudder, wing tip to wing tip.
More lightening holes, less wood overall, and balsa substituted for heavier woods, have produced a strong, but significantly lighter airframe. We
then complete the model with a lightweight proprietary covering material that provides a professional finish, yet retains the repairability you expect
from a wood airframe aircraft. We even include extra covering material for mishaps and dings from those less-than-friendly flying sites. The molded
cowling is prepainted and the molded wheel pants are prejoined. The windows are even molded and cut to shape for easy installation.
The Super Impress II EP ARF is accessorized with quality hardware and that you'd choose yourself for a model of this size. We use custom mini
control horns, adjustable clevises and matching threaded pushrods for convenience and easy adjustment. The main landing gear is now formed
aluminum instead of the older style metal rods.
In the air is where it really counts and the Super Impress II EP ARF is designed to "Impress" even the most experienced pilot. The range of motors
and performance available from the aircraft is staggering. With the Wattage 370 power system and a 5/4AAA NiMH flight battery, the Super
Impress II EP ARF makes a great aileron trainer and an easy Sunday-Flyer at a wing loading of under 10 ounces per square foot. This power
system is amazing for it's weight and size and it flies this 300 square inch-wing aircraft like a trainer! But, step up to a 480 brushless motor, larger
cells (or Lipo's) and matching propeller and ESC, then increase the control throws and watch out! Your friends will be amazed at the maneuverability
and performance of this beautiful aircraft. And, more importantly, you'll be having a blast flying battery after battery! From mild to wild, the Super
Impress II EP ARF will make an impression on you!
INSTRUCTIONS FOR FINAL ASSEMBLY
The Wattage Super Impress II EP ARF is distributed
exclusively by Global Hobby Distributors
18480 Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2004, Global Hobby
Distributors Version V1.0 August 2004
Super Impress II EP ARF Specifications:
Wing Span: 44.25 Inches
Wing Area: 310 Square Inches
Length: 32 Inches
Weight RTF: 23-29 Ounces (Depending On Equipment Used)
Wing Loading: 11-14 Ounces Per Square Foot
Functions: Ailerons, Elevator, Rudder & Throttle
Radio Required: 4Ch or More Micro w/3 Micro Servos
Minimum Suggested Motor: 370 w/3.67:1 Gear Box & 7.5 x 5 Prop
ESC Required for Motor Above: 15 Amp Micro
Battery Required for Motor Above: 8 Cell 5/4AAA 800mAH NiMH
Alternative Power Systems Described on Page # 4
1
Kit Product Number 128403
