Small Duct Heating, Cooling and Indoor Air Quality Systems
The
AirPurification System
Installation and Operation Manual
Manufactured By
www.hi-velocity.com
Module-HPS-Hi-Velocity-Air-Purification-System-Installation-Manual-050515-MERV-13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HE PS and is the answer not in the manual?

Questions and answers

Summary of Contents for Hi-Velocity HE PS

  • Page 1 Small Duct Heating, Cooling and Indoor Air Quality Systems AirPurification System Installation and Operation Manual Manufactured By www.hi-velocity.com Module-HPS-Hi-Velocity-Air-Purification-System-Installation-Manual-050515-MERV-13...
  • Page 2 Hi-Velocity Air Purification System Parts List - Visit www.hi-velocity.com to find a Distributor Item Shipping Weight Shipping Dimensions Part Number HE PS c/w MERV 13 Filter 21/29/11 20180100000 HE PS 1750 c/w MERV 13 Filter 23/32/14 20180101750 HE PS Replacement Parts...

  • Page 3: Installation

    HE PS-1750 Capacity 1.5-3 Tons 4-5 Tons Make sure to install the Hi-Velocity Air Purification System Dimensions ” W x 25” H x 10” D 21” W x 25” H x 10” D so that the inlet or return air enters the side containing the Flange 1/2”...
  • Page 4 Fig. 5 Block Air Flow Fig. 3 Vertical Installation Tape all seams between the air handler and the outlet side of the HE PS so there can be no air bypassing When installing the HE PS to a Hi-Velocity 50 or the system.

  • Page 5: Replacement Filters And Ultraviolet Lamps

    Operation The Hi-Velocity Air Purification System installs in the PRESS HERE air-inlet side of the Hi-Velocity unit up to five tons in size. TO RESET Only operation of the air-handler fan unit is required for air purification and sterilization to take place.

  • Page 6: Changing The Filter

    Changing the Filter NOTE! ENSURE FILTER AND PHOTOCATALYTIC MODULE ARE Unplug the power cord from the HE PS unit. INSTALLED IN PROPER AIR FLOW Unscrew the two locking knobs and remove the door SEQUENCE. (Fig. 6) Remove old filter and replace with new filter.
  • Page 7 WHITE BALLAST LAMP 120/220 V BLACK WHITE BALLAST LAMP 120/220 V BLACK BLUE BLUE Fig. 12 HE PS Electrical Diagram © 1995-2009 Energy Saving Products Ltd.

  • Page 8: Limited Lifetime Warranty

    Hi-Velocity Air Purification System. Warranty return shipping from the factory is prepaid for the first two years only. This warranty is provided to the original purchaser of the HE PS and may not be transferred, sold or bartered. This product is not warranted against freight damage, failure resulting from misuse, connection to incorrect voltage, or acts of God such as fires, earthquakes, or floods.
