- Page 1 E-Vision Laser 6500 Series Super High Brightness Digital Video Projector Important Information 117-856A Rev A April 2016...
-
Page 2: Digital Projection
Important Information Digital Projection E-Vision Laser 6500 Series Digital Projection Digital Projection Limited Digital Projection China Greenside Way, Middleton 中国 北京市 朝阳区 芍药居北里101号 Manchester M24 1XX, UK 世奥国际中心A座2006室(100029) Rm A2006 Registered in England No. 2207264 ShaoYaoJu 101 North Lane Registered Office: as above... -
Page 3: Table Of Contents
Digital Projection E-Vision Laser 6500 Series Important Information Super High Brightness Digital Video Projector Important Information Contents Symbols used in the User Manual ....................4 Electrical and physical specifications ..................5 Laser precautions ..........................5 Product labels ............................6 Location of laser aperture ......................7 Interlock switches ..........................7... -
Page 4: Symbols Used In The User Manual
Important Information Digital Projection E-Vision Laser 6500 Series Symbols used in the User Manual LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the instructions are closely followed. ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely followed. -
Page 5: Electrical And Physical Specifications
Digital Projection E-Vision Laser 6500 Series Important Information Electrical and physical specifications Main Voltage 100-240 VAC 50/60Hz single phase Operating Temperature 0°C to 40°C (32 to 104F) Storage Temperature -20°C to 60°C (-4 to 140F) Operating Humidity 10% to 85% non-condensing Weight 25 kg (55.1 lb) without lens... -
Page 6: Product Labels
Important Information Digital Projection E-Vision Laser 6500 Series Product labels Hazard Warning Symbol and Aperture Label Explanatory Label RISK GROUP 2 CAUTION ATTENTION Possibly hazardous optical radiation emitted Ce produit peut émettre des rayonnements Explanatory Label from this product. optiques dangereux. -
Page 7: Location Of Laser Aperture
Digital Projection E-Vision Laser 6500 Series Important Information Location of laser aperture The laser aperture is located as indicated below. Be careful not to expose the eye to direct laser light. Laser aperture Interlock switches Three interlock switches installed at the main frame, inside the cover, will power-off the system individually when activated. -
Page 8: General Precautions
Important Information Digital Projection E-Vision Laser 6500 Series General precautions The unit is never to be operated if the unit is defective or the cover or seal is damaged. No maintenance allowed by end user. Do not open the cabinet. There are no user serviceable parts inside. -
Page 9: Installation Precautions
Digital Projection E-Vision Laser 6500 Series Important Information Installation precautions Connect the LAN cable only to a computer LAN connection. Other similar connectors may have a dangerously high voltage source. The projector must be installed only by suitably qualified personnel, in accordance with local building codes. - Page 10 Important Information Digital Projection E-Vision Laser 6500 Series Place the projector in a dry area away from sources of dust, moisture, steam, smoke, sunlight or heat. The projector is heavy. Use safe handling techniques when lifting the projector. Do not drop or knock the projector.
-
Page 11: Operation And Configuration Precautions
Digital Projection E-Vision Laser 6500 Series Important Information Operation and configuration precautions Do not make changes to the networking configuration unless you understand what you are doing, or have taken advice from your Network Manager. If you make a mistake, it is possible that you will lose contact with the projector. -
Page 12: Compliance With International Standards
Important Information Digital Projection E-Vision Laser 6500 Series Compliance with international standards RF Interference The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by Digital Projection in this manual. Failure to comply with this government regulation could void your right to operate this equipment. -
Page 13: Basic Operation Instructions
Digital Projection E-Vision Laser 6500 Series Important Information Basic Operation Instructions Positioning the screen and projector Install the screen, ensuring that it is in the best position for viewing by your audience. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to fill the screen. -
Page 14: Connecting The Power Supply
Important Information Digital Projection E-Vision Laser 6500 Series Connecting the power supply Firmly push the mains connector into the socket as shown in the illustration. Use only the power cable provided. Ensure that the power outlet includes a ground connection as this equipment MUST be earthed. -
Page 15: Selecting An Input Signal
Digital Projection E-Vision Laser 6500 Series Important Information Selecting an input signal If more than one input source is connected, select the input you want to display. Press the Source button on the control panel and use the ▼ arrow buttons to scroll through the list of UP ▲... -
Page 16: Adjusting The Lens
Important Information Digital Projection E-Vision Laser 6500 Series Adjusting the lens Lens shift The lens shift function can be used to adjust the position of the projected image either horizontally or vertically. Use the vertical and horizontal lens shift knobs to move the image across the width or height of the screen. -
Page 17: Inserting A New Lens
Digital Projection E-Vision Laser 6500 Series Important Information Inserting a new lens Before changing the lens, always make sure the projector is switched off and fully disconnected from its power supply. When changing the lens, avoid using excessive force as this may damage the equipment. -
Page 18: Removing The Lens
Important Information Digital Projection E-Vision Laser 6500 Series Removing the lens Before changing the lens, always make sure the projector is switched off and fully disconnected from its power supply. When changing the lens, avoid using excessive force as this may damage the equipment. -
Page 19: Control Panel Reference
Digital Projection E-Vision Laser 6500 Series Important Information Control Panel Reference MENU Opens and exits OSD menus. Keystone LEFT Navigates and changes settings in the OSD. Adjusts Horizontal Keystone. Keystone UP Navigates and changes settings in the OSD. Adjusts Vertical Keystone. -
Page 20: Projector Indicators
Important Information Digital Projection E-Vision Laser 6500 Series Projector indicators Power LED Displays power on/off sequence status. Light source LED Displays light source status. Temp LED Displays thermal status. Filter LED Displays filter replacing warning message. Page 20 Rev A April 2016... -
Page 21: Remote Control Reference
Digital Projection E-Vision Laser 6500 Series Important Information Remote Control Reference Power ON Displays the PC source selection. HDMI Displays the HDMI 1 / HDMI 2 / DVI source selection (toggle). This button is not used in this configuration. Power OFF Turns the projector off. - Page 22 Important Information Digital Projection E-Vision Laser 6500 Series Remote Control reference continued... Keystone UP Navigates and changes settings in the OSD. Adjusts Vertical Keystone. MENU Opens the OSD. Keystone LEFT Navigates and changes settings in the OSD. Adjusts Horizontal Keystone.
- Page 23 Digital Projection E-Vision Laser 6500 Series Important Information Remote Control reference continued... Auto / ID input 0 Automatically adjusts frequency, phase and position. Use with to set the remote ID to Source / ID Source / ID Selects the next input source.
